Chevrolet Equinox Towing Capacity (All Years 2005-2026)

The Chevrolet Equinox is a compact crossover SUV produced by General Motors under the Chevrolet brand.

It has been in continuous production since the 2005 model year, with two major generational changes significantly altering its powertrain lineup and towing specifications.

This guide covers Chevrolet Equinox towing capacity by model year, including maximum trailer weight, payload capacity, GCWR, tongue weight, hitch class, and tow package availability for each configuration.

Towing specifications vary primarily by engine and drivetrain selection.

Exceeding manufacturer-rated towing limits stresses the engine, transmission, braking system, and chassis structure, increasing the risk of component failure and loss of vehicle control.

2026 Chevrolet Equinox Towing Capacity

The 2026 Chevrolet Equinox retains the same towing limits as the 2025 model, with AWD variants rated at 1,500 lbs (680 kg) and FWD variants rated at 800 lbs (363 kg). For 2026, Chevrolet introduced an optional trailering package (RPO SDE) priced at $1,095, available on LT, Activ, and RS trims. AWD configuration remains the recommended choice for owners who need the maximum trailer weight rating.

2025 Chevrolet Equinox Towing Capacity

The 2025 Chevrolet Equinox introduced a new generation platform with revised axle ratios: AWD models use a 3.47 axle ratio, while FWD models use a 5.81 axle ratio. The maximum towing capacity of 1,500 lbs (680 kg) applies exclusively to AWD-equipped variants. FWD models are rated at a lower 800 lbs (363 kg), a notable reduction compared to prior-generation FWD ratings.

2024 Chevrolet Equinox Towing Capacity

The 2024 Chevrolet Equinox carries a uniform maximum towing capacity of 1,500 lbs (680 kg) across all trim levels and both FWD and AWD configurations. Towing figures are unchanged from the 2023 model year, and no dedicated trailering package was available for this generation. Trailering provisions including hitch wiring are included as standard equipment on all 2024 trims.

2023 Chevrolet Equinox Towing Capacity

The 2023 Chevrolet Equinox introduced the updated 1.5L LSD turbocharged engine, replacing the earlier LYX unit and adding 5 horsepower while retaining the same 203 lb-ft torque rating. Maximum towing capacity held at 1,500 lbs (680 kg) across all trims and drivetrain configurations. Trailers over 1,000 lbs require a functioning trailer brake system in many jurisdictions.

2022 Chevrolet Equinox Towing Capacity

The 2022 Chevrolet Equinox was offered exclusively with the 1.5L turbocharged engine, as the 2.0L and 1.6L diesel options were discontinued after 2020. Maximum towing capacity for the 2022 model year is 1,500 lbs (680 kg). Tongue weight should be maintained at approximately 10 percent of the maximum trailer weight to preserve steering control and braking performance.

2021 Chevrolet Equinox Towing Capacity

The 2021 Chevrolet Equinox also dropped the 2.0L engine option, limiting the powertrain lineup to the 1.5L turbocharged four-cylinder. Maximum towing capacity is rated at 1,500 lbs (680 kg) for properly equipped units. Owners should note the lower towing limits compared to 2018-2020 models equipped with the 2.0L engine.

2020 Chevrolet Equinox Towing Capacity

The 2020 Chevrolet Equinox is the final model year to offer the 2.0L turbocharged engine, which delivers the highest towing capacity in the third-generation lineup at 3,500 lbs (1,588 kg). Models equipped with the 1.5L or 1.6L diesel engine are limited to 1,500 lbs (680 kg). Engine selection is the single most important variable determining trailer weight limits on 2018-2020 models.

2019 Chevrolet Equinox Towing Capacity

The 2019 Chevrolet Equinox shares the same three-engine configuration as the 2018 and 2020 model years. Maximum towing capacity of 3,500 lbs (1,588 kg) is achieved only with the 2.0L turbocharged engine and proper tow equipment installation. The 1.6L turbodiesel option, while fuel-efficient, is limited to the same 1,500 lb (680 kg) trailer weight limit as the base 1.5L engine.

2018 Chevrolet Equinox Towing Capacity

The 2018 model year marked the launch of the third-generation Chevrolet Equinox with a fully revised powertrain lineup. Models with the 2.0L engine and factory tow package installed reach a maximum towing capacity of 3,505 lbs (1,590 kg). Manufacturer guidelines recommend no towing for the first 500 miles on new vehicles and limited speeds during the initial break-in towing period.

2017 Chevrolet Equinox Towing Capacity

The 2017 Chevrolet Equinox is the final year of the second-generation body style, offering 2.4L four-cylinder and 3.6L V6 engine options. The 3.6L V6 configuration delivers the maximum towing capacity of 3,500 lbs (1,588 kg) for this generation. The 2.4L engine is limited to 1,500 lbs (680 kg), making engine selection a critical factor in towing decisions.

2016 Chevrolet Equinox Towing Capacity

The 2016 Chevrolet Equinox towing specifications remain consistent with the broader second-generation lineup. The maximum towing capacity of 3,500 lbs (1,588 kg) is achievable only with the 3.6L V6 engine and appropriate towing equipment. Owners with the 2.4L four-cylinder engine are limited to 1,500 lbs (680 kg) regardless of drivetrain configuration.

2015 Chevrolet Equinox Towing Capacity

The 2015 Chevrolet Equinox carries the same engine lineup and towing specifications as the 2013-2017 generation. The V6 configuration remains the only path to the 3,500 lb (1,588 kg) maximum towing capacity in this model year. Tongue weight must not exceed 350 lbs (159 kg) on V6 models and 150 lbs (68 kg) on four-cylinder models.

2014 Chevrolet Equinox Towing Capacity

The 2014 Chevrolet Equinox towing capacity follows the same pattern as the full second-generation range. The 3.6L V6 engine provides the maximum trailer weight rating of 3,500 lbs (1,588 kg) when the proper tow equipment is installed. Passenger load directly affects available towing capacity, since combined weight must not exceed the vehicle’s GCWR.

2013 Chevrolet Equinox Towing Capacity

The 2013 Chevrolet Equinox towing capacity is rated at a maximum of 3,500 lbs (1,588 kg) for V6-equipped configurations. The 2.4L engine option caps maximum trailer weight at 1,500 lbs (680 kg). Towing specifications are consistent across both FWD and AWD variants when the same engine is used.

2012 Chevrolet Equinox Towing Capacity

The 2012 Chevrolet Equinox was offered with the 3.0L V6 rather than the 3.6L used in later years, though the maximum towing capacity of 3,500 lbs (1,588 kg) remains the same. The 2.4L four-cylinder is rated at 1,500 lbs (680 kg). Trailer brakes are required in most U.S. states for trailers exceeding 1,000 lbs.

2011 Chevrolet Equinox Towing Capacity

The 2011 Chevrolet Equinox shares its powertrain and towing specifications with the 2010 and 2012 models. Maximum towing capacity on the 3.0L V6 configuration is 3,500 lbs (1,588 kg). The 2.4L engine limits trailer weight to 1,500 lbs (680 kg).

2010 Chevrolet Equinox Towing Capacity

The 2010 Chevrolet Equinox marked the beginning of the second generation with an all-new body and updated powertrain options. The maximum towing capacity for V6 models is 3,500 lbs (1,588 kg), consistent with other second-generation V6 variants. Four-cylinder models are limited to 1,500 lbs (680 kg).

2009 Chevrolet Equinox Towing Capacity

The 2009 Chevrolet Equinox was offered with two V6 engine options, both rated at the same maximum towing capacity of 3,500 lbs (1,588 kg). This is the final model year of the first-generation Equinox body style. Passenger count on first-generation models affects available tow capacity: full five-passenger loading reduces the rated capacity from 3,500 lbs to approximately 2,900 lbs on applicable configurations.

2008 Chevrolet Equinox Towing Capacity

The 2008 Chevrolet Equinox maximum towing capacity is rated at 3,500 lbs (1,588 kg), consistent across both the 3.4L and 3.6L V6 engines. The Sport trim introduced the more powerful 3.6L V6 in the first-generation lineup during this period. Tongue weight must be kept at or below 350 lbs (159 kg) to maintain proper vehicle handling and braking performance.

2007 Chevrolet Equinox Towing Capacity

The 2007 Chevrolet Equinox was powered solely by the 3.4L V6 engine. Maximum towing capacity is 3,500 lbs (1,588 kg) for all configurations. Trailer brake systems are required for any trailer exceeding 1,000 lbs in most U.S. states.

2006 Chevrolet Equinox Towing Capacity

The 2006 Chevrolet Equinox uses the 3.4L V6 engine across all trims, rated at a maximum towing capacity of 3,500 lbs (1,588 kg). Maximum payload is rated at 1,157 lbs (525 kg). Both FWD and AWD configurations carry the same trailer weight limit for this model year.

2005 Chevrolet Equinox Towing Capacity

The 2005 Chevrolet Equinox is the first production year, launched exclusively with AWD and the 3.4L V6 engine. Maximum towing capacity is 3,500 lbs (1,588 kg), and maximum payload is 1,157 lbs (525 kg). Curb weight for the 2005 model is approximately 3,776 lbs (1,713 kg), which must be factored into GCWR calculations.

Towing Equipment and Setup

Selecting the correct towing equipment is as important as understanding towing capacity ratings. Using undersized or improperly installed equipment can result in trailer separation, brake failure, or loss of vehicle control.

Tow Package

The factory tow package provides engineered components specific to the vehicle’s towing limits. For the 2026 Equinox, the optional trailering package (RPO SDE) includes the factory hitch receiver and trailer lighting wiring harness, priced at $1,095. Aftermarket Class III hitches rated for 4,500 lbs GTW are available for second-generation Equinox models from suppliers such as CURT and Draw-Tite.

Towing Setup Comparison

Trailer Brake Controller

A trailer brake controller synchronizes the trailer’s electric brakes with the tow vehicle’s braking system. Trailer brakes are legally required in most U.S. states for trailers exceeding 1,000 lbs. Without a functioning trailer brake controller, stopping distances increase substantially, particularly on grades.

Weight-Distributing Hitch

A weight-distributing hitch redistributes tongue weight across all axles of the tow vehicle and trailer. This is recommended for trailers approaching the upper towing limits of any Equinox configuration. It restores proper steering geometry and reduces rear axle squat during towing.

Tire Load Ratings

Trailer tires must be rated for the loaded trailer weight, not the tow vehicle’s tire rating. Under-rated trailer tires are a common cause of blowouts during sustained highway towing. Check the tire sidewall for the load rating before each tow.

Transmission Cooler

Sustained towing generates heat in the automatic transmission. An auxiliary transmission cooler reduces operating temperatures and extends fluid life during repeated or long-distance towing. This is especially relevant for 2.0L-equipped third-generation Equinox models used near maximum capacity.

Trailer Sway Control

Trailer sway occurs when rear-mounted trailer weight exceeds tongue weight tolerance. Electronic stability control systems in current-generation Equinox models provide a basic level of sway management. For heavier trailers, an aftermarket sway control bar provides additional stability.

Frequently Asked Questions

What is the maximum towing capacity of a Chevrolet Equinox?

The maximum towing capacity of a Chevrolet Equinox is 3,500 lbs (1,588 kg). This figure applies to first-generation models (2005-2009) and select second-generation and third-generation models equipped with V6 or 2.0L turbocharged engines. Current-generation models (2025-2026) are limited to a maximum of 1,500 lbs (680 kg).

How much can a Chevrolet Equinox tow with a tow package?

With the factory tow package or a properly installed aftermarket hitch, a 2.0L-equipped 2018-2020 Equinox can tow up to 3,505 lbs (1,590 kg). Models equipped with the 1.5L engine and tow package remain limited to 1,500 lbs (680 kg), as the tow package does not override the powertrain-based rating. Always confirm the rated capacity for the specific model year and engine.

Does AWD affect Chevrolet Equinox towing capacity?

In most model years, AWD and FWD configurations share the same maximum towing capacity when using the same engine. The exception is the 2025 and 2026 model years, where AWD units are rated at 1,500 lbs (680 kg) and FWD units are limited to 800 lbs (363 kg). This difference is tied to the axle ratio configuration, not AWD mechanical advantage alone.

What trailer weight is safe for a Chevrolet Equinox?

A safe trailer weight must account for the vehicle’s current payload (passengers and cargo) and the GCWR. For third-generation 1.5L models, a fully loaded trailer should not exceed 1,500 lbs (680 kg). First-generation and V6-equipped second-generation models may safely tow up to 3,500 lbs (1,588 kg) when vehicle loading allows.

Do I need a weight-distributing hitch for a Chevrolet Equinox?

A weight-distributing hitch is not required to achieve the manufacturer-rated towing capacity on any Equinox configuration. However, it is recommended when towing trailers that approach the upper towing limit of V6 or 2.0L-equipped models. First-generation owner manuals confirm that standard tongue weight ratings can be met without a weight distribution system.

What hitch class fits a Chevrolet Equinox?

Third-generation Equinox models (2018-present) use Class II hitches rated at 1,500 lbs GTW for the factory tow package configuration. Aftermarket Class III hitches rated up to 4,500 lbs GTW and 675 lbs tongue weight are available for 2018-2019 models from manufacturers such as Draw-Tite and CURT. First and second-generation models support Class II or Class III hitches depending on engine and tow package specifications.

Conclusion

The Chevrolet Equinox towing capacity ranges from 800 lbs (363 kg) on current FWD-equipped models to 3,500 lbs (1,588 kg) on first-generation and V6-equipped second-generation configurations. Engine selection is the primary determinant of maximum trailer weight in all generations. The 2.0L turbocharged engine in 2018-2020 models and the V6 engines in all earlier generations provide the highest towing capacity ratings available for this vehicle.

Tow package availability, drivetrain type, and axle ratio further influence towing limits, particularly in 2025 and 2026 model years where FWD and AWD ratings diverge significantly. Payload capacity, passenger count, and cargo weight directly reduce the available towing limit below the published maximum. Always verify specifications using the owner’s manual or the vehicle certification label before towing heavy loads.
