The Dodge Journey is a mid-size crossover SUV produced from 2009 to 2020. It was offered in front-wheel drive and all-wheel drive configurations with several engine options across its production run.
This guide covers Dodge Journey towing capacity by model year and configuration, including maximum trailer weight, payload limits, tongue weight, GCWR, and hitch requirements.
Following manufacturer-rated towing limits helps protect the engine, transmission, suspension, and braking system.
Quick Navigation
2020 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) |
| Conventional Towing Capacity | 1,000 lbs (453 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,000 lbs (453 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 5,700 lbs (2,585 kg) |
| Tongue Weight Limit | 100 lbs (45 kg) |
| Hitch Class | Class II or Class III |
| Factory Tow Package | Optional |
The 2020 Dodge Journey offers a maximum towing capacity of 1,000 lbs when properly equipped. Only the 2.4L four-cylinder engine was available for this model year, so all trims carry the same trailer weight limit.
2019 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2019 Dodge Journey reaches a maximum towing capacity of 2,500 lbs with the 3.6L V6 and factory tow package. Models with the 2.4L engine are limited to 1,000 lbs.
2018 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2018 Dodge Journey max towing capacity is 2,500 lbs when equipped with the 3.6L V6 and factory tow package. Four-cylinder models are limited to light-duty towing at 1,000 lbs.
2017 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2017 Dodge Journey towing capacity reaches 2,500 lbs on V6-equipped models with the factory tow package. Four-cylinder trims remain limited to 1,000 lbs.
2016 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2016 Dodge Journey offers up to 2,500 lbs of towing capacity with the 3.6L V6 and tow package. The 2.4L engine keeps the trailer weight limit at 1,000 lbs.
2015 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2015 Dodge Journey offers a maximum towing capacity of 2,500 lbs on V6-equipped models with the tow package. Four-cylinder versions are limited to 1,000 lbs.
2014 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2014 Dodge Journey towing capacity peaks at 2,500 lbs with the 3.6L V6 and trailer tow package. Passenger and cargo weight must still be considered within the GCWR.
2013 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2013 Dodge Journey max towing capacity is 2,500 lbs on V6 models with the factory tow package. The four-cylinder configuration remains rated for 1,000 lbs.
2012 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2012 Dodge Journey towing capacity tops out at 2,500 lbs on 3.6L V6 models with the tow package. The 2.4L engine retains the 1,000 lb limit.
2011 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.6L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 2,500 lbs (1,134 kg) with 3.6L |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 lbs (1,134 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 7,000 lbs (3,175 kg) with 3.6L |
| Tongue Weight Limit | 100 lbs (45 kg) with 2.4L; 250 lbs (113 kg) with 3.6L |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2011 Dodge Journey towing capacity is 2,500 lbs on V6-equipped trims with the factory tow package. This was the first year the 3.6L Pentastar V6 appeared in the Journey.
2010 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 3.5L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 3,500 lbs (1,588 kg) with 3.5L and tow package |
| Conventional Towing Capacity | 1,000 lbs (453 kg); 2,500 to 3,500 lbs (1,134 to 1,588 kg) with tow package |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 8,300 lbs (3,765 kg) with 3.5L and tow package |
| Tongue Weight Limit | Up to 350 lbs (159 kg) with tow package |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2010 Dodge Journey reaches a maximum towing capacity of 3,500 lbs with the 3.5L V6 and factory trailer tow prep package. The 2.4L engine remains capped at 1,000 lbs.
2009 Dodge Journey Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4; 2.7L V6; 3.5L V6 |
| Drivetrain | FWD; AWD |
| Maximum Towing Capacity | 1,000 lbs (453 kg) with 2.4L; 3,000 lbs (1,361 kg) with 2.7L and tow package; 3,500 lbs (1,588 kg) with 3.5L and tow package |
| Conventional Towing Capacity | 1,000 to 3,500 lbs (453 to 1,588 kg) depending on engine and equipment |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Varies by trim and load |
| Gross Combined Weight Rating (GCWR) | Approx. 8,300 lbs (3,765 kg) with 3.5L and tow package |
| Tongue Weight Limit | 100 to 400 lbs (45 to 181 kg) depending on engine and package |
| Hitch Class | Class II; Class III |
| Factory Tow Package | Optional |
The 2009 Dodge Journey max towing capacity is 3,500 lbs on 3.5L V6 models equipped with the factory trailer tow package. The 2.7L V6 can tow up to 3,000 lbs when properly equipped.
Towing Equipment & Setup Tips
Tow Package
The tow package is the main requirement for reaching the highest Dodge Journey towing capacity. It typically adds the necessary hitch hardware, wiring provisions, and related towing equipment needed for rated trailer weights.
Trailer Brake Controller
A trailer brake controller is recommended when trailer weight approaches the upper end of the vehicle’s towing limits. Trailer brakes help reduce stopping distance and improve control during downhill braking.
Weight-Distributing Hitch
A weight-distributing hitch helps balance tongue weight across the front and rear axles. This setup can improve steering response and braking stability when towing a heavier trailer.
Transmission Cooler
A transmission cooler helps manage heat when towing near the maximum trailer weight limit. Lower transmission temperatures support durability during repeated towing use.
Tire Load Ratings
Tire load ratings must support the combined vehicle load, passengers, cargo, and trailer tongue weight. Under-rated tires can affect stability and braking performance.
Trailer Sway Control
Trailer sway control improves stability when crosswinds or steering inputs disturb the trailer. Proper tongue weight, correct tire pressure, and balanced loading also reduce sway.
| Normal Towing Setup | Heavy Towing Setup |
|---|---|
| Light trailer weight, standard hitch, basic wiring | Tow package, trailer brakes, Class III hitch, cooling support |
FAQs
What is the maximum towing capacity of a Dodge Journey?
The maximum Dodge Journey towing capacity is 3,500 lbs (1,588 kg). That rating applies to certain 2009 and 2010 models with the 3.5L V6 and factory tow package.
How much can a Dodge Journey tow with a tow package?
A Dodge Journey with the factory tow package can tow up to 2,500 lbs on 2011 to 2019 V6 models. Certain 2009 and 2010 V6 models can tow up to 3,500 lbs when properly equipped.
Does AWD affect Dodge Journey towing capacity?
AWD does not directly increase towing capacity by itself. Engine configuration and tow package equipment are the main factors, although AWD is commonly paired with higher-capacity V6 models.
What trailer weight is safe for a Dodge Journey?
A safe trailer weight stays at or below the manufacturer-rated limit for the exact model year and configuration. Tongue weight, payload capacity, and GCWR must also remain within specification.
Do I need a weight-distributing hitch for a Dodge Journey?
A weight-distributing hitch is not required for every trailer. It becomes useful when towing closer to the vehicle’s upper towing limits and when tongue weight approaches the maximum allowed value.
What hitch class does the Dodge Journey use?
The Dodge Journey commonly uses a Class III hitch on V6 models with higher towing limits. Lower-capacity configurations may use a Class II hitch for lighter trailers.
Conclusion
Dodge Journey towing capacity ranges from 1,000 lbs (453 kg) to 3,500 lbs (1,588 kg) depending on model year, engine, drivetrain, and tow package. Early V6 models provide the highest maximum trailer weight, while later four-cylinder models are limited to light towing.
Configuration is critical when reviewing Dodge Journey towing specifications by year. Engine choice, payload capacity, tongue weight, hitch class, and GCWR all affect safe towing limits. Always verify specifications using the owner’s manual before towing heavy loads.
