The Ford Transit Connect is a compact commercial van produced by Ford Motor Company.
The North American market model was sold from 2010 through 2023, spanning two distinct generations.
This guide covers towing capacity by model year and configuration, including maximum trailer weight, payload limits, hitch class, and tow package requirements. Specifications vary by engine, drivetrain, and installed equipment.
Following manufacturer-rated towing limits protects the engine, transmission, and braking systems from overload damage.
Quick Navigation
2023 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L GDI I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,550 lbs (703 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 7,420 lbs (3,366 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2023 Ford Transit Connect offers a maximum towing capacity of 2,000 lbs (907 kg) when equipped with the Trailer Tow Prep Package.
The 2.0L GDI I4 engine and FWD configuration are the only powertrain options available for this final North American model year.
Staying within manufacturer-specified towing limits preserves drivetrain reliability and braking control.
2022 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L GDI I4; 2.5L Duratec I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,550 lbs (703 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 7,420 lbs (3,366 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2022 Ford Transit Connect supports a maximum towing capacity of 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package installed. Both the 2.0L GDI and 2.5L Duratec four-cylinder engines are available in this model year. Tongue weight must not exceed 200 lbs (91 kg) under any configuration.
2021 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L GDI I4 (162 hp); 2.5L Duratec I4 (169 hp) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,550 lbs (703 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,420 lbs (2,459 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2021 Ford Transit Connect delivers a maximum towing capacity of 2,000 lbs (907 kg) when properly equipped with the Trailer Tow Prep Package. The 2.5L Duratec engine produces 169 horsepower and 171 lb-ft of torque, while the 2.0L GDI produces 162 horsepower and 144 lb-ft. GVWR reaches 5,420 lbs (2,459 kg) on this model year.
2020 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L GDI I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,500 lbs (680 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 7,420 lbs (3,366 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2020 Ford Transit Connect carries a maximum towing capacity of 2,000 lbs (907 kg) with the Trailer Tow Prep Package and is rated for up to 1,500 lbs (680 kg) of payload in cargo van configuration. Maximum trailer weight ratings remain consistent across 2019-2020 models due to unchanged powertrain specifications. Tongue weight must stay at or below 200 lbs (91 kg) to remain within rated towing limits.
2019 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L GDI I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,550 lbs (703 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 7,420 lbs (3,366 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I / Class II (aftermarket) |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2019 Ford Transit Connect supports a maximum towing capacity of 2,000 lbs (907 kg) when the Trailer Tow Prep Package is installed. The second-generation Transit Connect continued with front-wheel drive and the 2.0L GDI engine as the primary powertrain. Aftermarket Class II hitches rated to 3,500 lbs gross trailer weight are also available for this year, though vehicle towing limits still govern the maximum trailer weight.
2018 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.5L Duratec I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,550 lbs (703 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 7,420 lbs (3,366 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Required (Class I Trailer Tow Package, Option Code 53T) |
The 2018 Ford Transit Connect is rated for a maximum towing capacity of 2,000 lbs (907 kg), which requires the Class I Trailer Tow Package (Option Code 53T) for trailers over 1,500 lbs. The 2.5L Duratec I4 engine powers the FWD drivetrain for this model year. Maximum tongue weight is limited to 200 lbs (91 kg).
2017 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.5L Duratec I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,550 lbs (703 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 7,420 lbs (3,366 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2017 Ford Transit Connect maintains a maximum towing capacity of 2,000 lbs (907 kg) when equipped with the factory tow package. The 2.5L Duratec I4 engine and FWD drivetrain carried over unchanged from the previous model year. Exceeding the 200 lbs tongue weight limit can cause rear suspension and steering degradation during towing.
2016 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.5L Duratec I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,550 lbs (703 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,020 lbs (2,277 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2016 Ford Transit Connect offers a maximum towing capacity of 2,000 lbs (907 kg) with the optional tow package. GVWR is rated at 5,020 lbs (2,277 kg) for this model year. The 2.5L Duratec I4 engine with a 6-speed SelectShift automatic transmission handles the load.
2015 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.5L Duratec I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,560 lbs (708 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,020 lbs (2,277 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2015 Ford Transit Connect carries a maximum towing capacity of 2,000 lbs (907 kg) and a GVWR of 5,020 lbs (2,277 kg). Maximum payload capacity reaches 1,560 lbs (708 kg) on select configurations. The 6-speed SelectShift automatic transmission is the sole gearbox option.
2014 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.5L Duratec I4 |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,550 lbs (703 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 7,020 lbs (3,185 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2014 Ford Transit Connect is rated to tow 2,000 lbs (907 kg) with the Trailer Tow Prep Package installed. This year marked the introduction of the second-generation Transit Connect for North America, featuring a redesigned body and updated powertrain. The 2.5L Duratec engine with FWD became the standard drivetrain for the new generation.
2013 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 (136 hp) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,600 lbs (726 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,005 lbs (2,270 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional |
The 2013 Ford Transit Connect was the final year of the first-generation design, retaining a maximum towing capacity of 2,000 lbs (907 kg). GVWR is rated at 5,005 lbs (2,270 kg) for this generation. The 2.0L four-cylinder engine with 136 horsepower and a four-speed automatic transmission powered the FWD platform.
2012 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 (136 hp) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,600 lbs (726 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,005 lbs (2,270 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional |
The 2012 Ford Transit Connect carries a maximum towing capacity of 2,000 lbs (907 kg) using the first-generation platform and 2.0L I4 engine. Payload capacity reaches up to 1,600 lbs (726 kg) on cargo-configured models. Specifications for 2012 are consistent with other first-generation Transit Connect years.
2011 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 (136 hp) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,600 lbs (726 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,005 lbs (2,270 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional |
The 2011 Ford Transit Connect retains the first-generation towing capacity of 2,000 lbs (907 kg). This year added a new XLT Premium trim level and expanded powertrain options, including natural gas and propane configurations in select markets. Standard FWD and the 2.0L I4 engine remain consistent with the rest of the first generation.
2010 Ford Transit Connect Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 (136 hp, 128 lb-ft torque) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 2,000 lbs (907 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Up to 1,600 lbs (726 kg) |
| Gross Vehicle Weight Rating (GVWR) | 4,965 lbs (2,252 kg) |
| Tongue Weight Limit | 200 lbs (91 kg) |
| Hitch Class | Class I |
| Factory Tow Package | Optional |
The 2010 Ford Transit Connect is the first North American model year, offering a maximum towing capacity of 2,000 lbs (907 kg). The 2.0L I4 engine produces 136 horsepower and 128 lb-ft of torque. Maximum payload capacity is rated at 1,600 lbs (726 kg), and GVWR is 4,965 lbs (2,252 kg).
Towing Equipment and Setup
Importance of the Tow Package
The Ford Transit Connect requires the factory Trailer Tow Prep Package to achieve its rated 2,000 lbs maximum towing capacity for loads over 1,500 lbs. The tow package includes the necessary wiring harness and receiver hitch mounting provisions. Without it, towing heavier loads risks electrical and structural damage.
Trailer Brake Controller
The Transit Connect does not have a built-in brake controller due to its Class I tow rating. Trailers at or near 2,000 lbs that have electric brakes require an aftermarket brake controller installed in the cab. Unbraked trailer weight should be kept well below the vehicle’s rated maximum to maintain safe stopping distances.
Hitch Class and Receiver Size
The Transit Connect’s factory tow package supports a Class I hitch with a 1-1/4-inch receiver. Aftermarket Class II hitches with 1-1/4-inch receivers rated to 3,500 lbs gross trailer weight are available from third-party manufacturers, but the vehicle’s rated towing limit still governs the maximum trailer weight. Class III hitches with 2-inch receivers are also sold for the Transit Connect but are used primarily for hitch-mounted cargo accessories.
Weight-Distributing Hitch
Weight-distributing hitches are compatible with Class II and III receiver hitches on the Transit Connect. A weight-distributing hitch improves steering and suspension load distribution when towing near maximum capacity. Vehicle towing limits remain the binding constraint regardless of hitch rating.
Transmission Cooler and Tire Load Ratings
The factory Trailer Tow Prep Package on the Transit Connect includes a supplemental transmission cooler in applicable configurations. Proper tire load ratings must be verified against the combined weight of the vehicle, cargo, passengers, and trailer tongue weight before towing. Exceeding tire load ratings causes heat buildup and increases blowout risk during towing operations.
Normal vs. Heavy Towing Setup
| Component | Light Towing (Under 1,000 lbs) | Near-Maximum Towing (1,500-2,000 lbs) |
|---|---|---|
| Hitch Class | Class I (1-1/4 in.) | Class I or II (1-1/4 in.) |
| Trailer Brakes | Not required | Recommended |
| Transmission Cooler | Standard cooling | Factory tow package required |
| Tongue Weight | Up to 100 lbs | Up to 200 lbs |
| Tow Package | Optional | Required |
| Tire Inflation | Standard | Verify load rating |
Frequently Asked Questions
What is the maximum towing capacity of a Ford Transit Connect?
The Ford Transit Connect has a maximum towing capacity of 2,000 lbs (907 kg) across all North American model years from 2010 to 2023. This rating applies when the vehicle is properly equipped with the factory Trailer Tow Prep Package. Tongue weight must not exceed 200 lbs (91 kg).
How much can a Ford Transit Connect tow with a tow package?
With the factory Trailer Tow Prep Package installed, the Ford Transit Connect can tow up to 2,000 lbs (907 kg). Without the tow package, trailer weight should remain below 1,500 lbs (680 kg) to stay within safe operating limits. The tow package includes the wiring harness and structural provisions necessary for rated trailer weight operation.
Does 4WD affect Ford Transit Connect towing capacity?
The Ford Transit Connect is available only in front-wheel drive (FWD) for the North American market. There is no 4WD or AWD option, so drivetrain selection does not affect towing capacity on this vehicle. All towing specifications apply to the standard FWD configuration.
What trailer weight is safe for a Ford Transit Connect?
The manufacturer-rated safe trailer weight is 2,000 lbs (907 kg) maximum with the tow package. For trailers without electric brakes, a lower limit in the range of 1,000 to 1,500 lbs provides greater braking safety margin. Always confirm tongue weight stays within the 200 lbs (91 kg) rated limit.
Do I need a weight-distributing hitch for a Ford Transit Connect?
A weight-distributing hitch is not required within the Transit Connect’s rated 2,000 lbs towing limit but can improve trailer sway control near maximum capacity. The vehicle’s 2,000 lbs towing limit remains the governing constraint regardless of hitch class.
Which Ford Transit Connect engine provides the best towing performance?
For 2019-2023 model years, the 2.0L GDI I4 engine provides the primary towing configuration. For 2010-2018 and 2021-2022 model years, the 2.5L Duratec I4 engine is rated for the same 2,000 lbs maximum trailer weight. Towing capacity does not differ between the two engine options; both require the Trailer Tow Prep Package to reach the 2,000 lbs maximum.
Conclusion
The Ford Transit Connect maintains a consistent maximum towing capacity of 2,000 lbs (907 kg) across all North American model years from 2010 through 2023. Towing specifications do not vary significantly by engine or trim level, but reaching the maximum trailer weight limit requires the factory Trailer Tow Prep Package on all configurations. Payload capacity ranges from approximately 1,500 lbs to 1,610 lbs depending on model year and body configuration, which must be accounted for alongside trailer tongue weight.
The vehicle’s Class I hitch rating and FWD drivetrain define its towing envelope, making it suitable for light-duty trailers, small utility loads, and compact boat trailers within the rated limit. Always verify towing specifications using the model-year owner’s manual and the Ford Trailer Towing Selector before towing any load.
