The GMC Yukon XL is a full-size, body-on-frame SUV produced by General Motors under the GMC brand.
It has been offered continuously since the 2000 model year, built on extended-wheelbase platforms across multiple generations and powertrain configurations.
This guide covers GMC Yukon XL towing capacity by model year, including maximum trailer weight, payload limits, GCWR, tongue weight, and hitch class for each generation.
Specifications vary by engine selection, drivetrain layout, and optional tow packages.
Staying within manufacturer-rated towing limits helps protect the engine, transmission, braking system, and chassis from premature wear or failure.
Quick Navigation
2026 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L EcoTec3 V8 (355 hp); 6.2L EcoTec3 V8 (420 hp); Duramax 3.0L Turbo-Diesel I6 (305 hp) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 8,200 lbs (3,719 kg) |
| Conventional Towing Capacity | 7,700 lbs (3,493 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 2,070 lbs (939 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,600 lbs (3,447 kg) |
| Tongue Weight Limit | ~820 lbs (372 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (Max Trailering Package NHT) |
The 2026 GMC Yukon XL offers a maximum towing capacity of 8,200 lbs (3,719 kg) when properly equipped with the Max Trailering Package.
The 5.3L V8 in 2WD configuration rates up to 7,800 lbs, the 6.2L V8 up to 7,500 lbs, and the Duramax diesel up to 7,900 lbs in standard 2WD trim.
Adding the NHT tow package raises ratings across all powertrain variants.
2025 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L EcoTec3 V8 (355 hp); 6.2L EcoTec3 V8 (420 hp); Enhanced Duramax 3.0L Turbo-Diesel I6 (305 hp) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 8,300 lbs (3,765 kg) |
| Conventional Towing Capacity | 7,700 lbs (3,493 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,977 lbs (897 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,700 lbs (3,493 kg) |
| Tongue Weight Limit | ~830 lbs (376 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (Max Trailering Package NHT) |
The 2025 GMC Yukon XL reaches a maximum towing capacity of 8,300 lbs (3,765 kg) with the 5.3L V8 engine in 2WD trim and the NHT Max Trailering Package installed. The diesel AT4 variant is rated for up to 7,700 lbs in standard configuration. Drivetrain selection between 2WD and 4WD affects the final trailer weight rating across all three engine options.
2024 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L EcoTec3 V8 L84 (355 hp); 6.2L EcoTec3 V8 L87 (420 hp); Duramax 3.0L Turbo-Diesel I6 LM2 (277 hp) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 8,300 lbs (3,765 kg) |
| Conventional Towing Capacity | 7,800 lbs (3,538 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,792 lbs (813 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,700 lbs (3,493 kg) |
| Tongue Weight Limit | ~830 lbs (376 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (Max Trailering Package NHT) |
The 2024 GMC Yukon XL achieves a maximum towing capacity of 8,300 lbs (3,765 kg) when configured with 2WD, the 5.3L V8, and the NHT Max Trailering Package. Without the NHT package, the 5.3L 2WD variant is rated at 7,800 lbs, the 6.2L 2WD at 7,600 lbs, and the diesel 2WD at 7,800 lbs. The 4WD configuration reduces ratings by approximately 200 to 300 lbs across all three engines.
2023 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L EcoTec3 V8 (355 hp); 6.2L EcoTec3 V8 (420 hp); Duramax 3.0L Turbo-Diesel I6 (277 hp) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 8,400 lbs (3,810 kg) |
| Conventional Towing Capacity | 7,900 lbs (3,583 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | ~1,800 lbs (816 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,700 lbs (3,493 kg) |
| Tongue Weight Limit | ~840 lbs (381 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (Max Trailering Package NHT) |
The 2023 GMC Yukon XL carries a maximum towing capacity of 8,400 lbs (3,810 kg), achieved with the 6.2L V8 engine in 2WD configuration and the NHT package installed. Without the Max Trailering Package, the 5.3L 2WD variant is rated at 7,900 lbs, while the diesel reaches 8,100 lbs in rear-wheel drive form. The diesel engine provides competitive trailer weight ratings without requiring the optional tow package upgrade.
2022 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L EcoTec3 V8 (355 hp); 6.2L EcoTec3 V8 (420 hp); Duramax 3.0L Turbo-Diesel I6 (277 hp) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 8,300 lbs (3,765 kg) |
| Conventional Towing Capacity | 7,800 lbs (3,538 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | ~1,800 lbs (816 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,700 lbs (3,493 kg) |
| Tongue Weight Limit | ~830 lbs (376 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (Max Trailering Package NHT) |
The 2022 GMC Yukon XL shares its towing platform with the second year of the T1-generation body and is rated to tow up to 8,300 lbs (3,765 kg) with the NHT Max Trailering Package. The 5.3L V8 in 2WD delivers the highest rating in this generation, while the 4WD configuration reduces the ceiling to 8,000 lbs. Engine and axle ratio selection remain the primary variables determining the final towing specification.
2021 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L EcoTec3 V8 L84 (355 hp); 6.2L EcoTec3 V8 L87 (420 hp); Duramax 3.0L Turbo-Diesel I6 LM2 (277 hp) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 8,300 lbs (3,765 kg) |
| Conventional Towing Capacity | 7,800 lbs (3,538 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | ~1,800 lbs (816 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,700 lbs (3,493 kg) |
| Tongue Weight Limit | ~830 lbs (376 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (Max Trailering Package NHT) |
The 2021 GMC Yukon XL marks the debut of the T1-generation platform, which increased standard towing ratings by 1,400 to 1,500 lbs over the 2015-2020 generation. The maximum towing capacity of 8,300 lbs (3,765 kg) applies to the 5.3L V8 with 2WD and the NHT package; without the package, the standard 2WD 5.3L rating is 7,800 lbs. The 6.2L V8 delivers a standard 2WD rating of 7,600 lbs and a maximum of 8,100 lbs with the NHT package installed.
2015-2020 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L EcoTec3 V8 L83 (355 hp); 6.2L EcoTec3 V8 L86 (420 hp) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 8,300 lbs (3,765 kg) |
| Conventional Towing Capacity | 6,000-6,300 lbs (2,722-2,858 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | ~1,700-1,800 lbs (771-816 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,400-7,500 lbs (3,357-3,402 kg) |
| Tongue Weight Limit | ~700-830 lbs (318-376 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (Max Trailering Package) |
The 2015-2020 GMC Yukon XL is rated for a maximum towing capacity of 8,300 lbs (3,765 kg) with the 5.3L V8 in 2WD and the optional Max Trailering Package. Standard towing without the package in 2WD with the 5.3L engine is 6,300 lbs, rising significantly versus the 2021 generation’s baseline. The 2015 model specifically uses a 3.42 rear axle ratio to achieve maximum tow ratings, while later years transitioned to a 3.23 ratio. The 2015 Yukon XL 1500 carries a GVWR of 7,500 lbs and a curb weight of approximately 5,981 lbs.
2009-2014 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L Vortec V8 (320 hp); 6.2L Vortec V8 (403 hp) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 7,900 lbs (3,583 kg) |
| Conventional Towing Capacity | 6,200-7,500 lbs (2,812-3,402 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | ~1,650-1,750 lbs (748-794 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,400 lbs (3,357 kg) |
| Tongue Weight Limit | ~700-790 lbs (318-358 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2009-2014 GMC Yukon XL 1500 is rated for a maximum towing capacity of 7,900 lbs (3,583 kg) across most configurations. GVWR holds at 7,400 lbs throughout this generation, and curb weight ranges from approximately 5,863 lbs to 6,069 lbs depending on trim and drivetrain. Towing ratings were consistent across 2009 through 2014, with configuration and axle ratio determining the final trailer weight limit.
2007-2008 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L Vortec V8; 6.0L Vortec V8 |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 7,900 lbs (3,583 kg) |
| Conventional Towing Capacity | 6,000-7,500 lbs (2,722-3,402 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | ~1,600-1,700 lbs (726-771 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,400 lbs (3,357 kg) |
| Tongue Weight Limit | ~700-790 lbs (318-358 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2007 and 2008 GMC Yukon XL 1500 carry maximum towing capacities of 7,900 lbs and 7,800 lbs respectively, within the GMT900 platform generation. The 2007 model is rated at the full 7,900 lbs, while the 2008 model is slightly lower at 7,800 lbs, both sharing a GVWR of 7,400 lbs and a curb weight of approximately 5,838 lbs. Engine and rear axle ratio selection remain the primary variables affecting the trailer weight limit for this generation.
2000-2006 GMC Yukon XL Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L Vortec V8; 6.0L Vortec V8 (2000 XL 2500: 8.1L Vortec V8) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 8,800 lbs (3,992 kg) (2000-2001); 8,400 lbs (3,810 kg) (2002-2004); 7,900 lbs (3,583 kg) (2005-2006) |
| Conventional Towing Capacity | 6,000-7,500 lbs (2,722-3,402 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A (XL 2500 variant capable of higher ratings) |
| Maximum Payload Capacity | ~1,600-1,800 lbs (726-816 kg) |
| Gross Vehicle Weight Rating (GVWR) | 7,000-7,200 lbs (3,175-3,266 kg) |
| Tongue Weight Limit | ~700-880 lbs (318-399 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2000 and 2001 GMC Yukon XL 1500 are rated for a maximum towing capacity of 8,800 lbs (3,992 kg), the highest ratings in this era of the nameplate. Models from 2002 through 2004 carry an 8,400 lb rating, while 2005 and 2006 models are rated at 7,900 lbs. The Yukon XL 2500 variant, available during this period, offered even higher towing limits up to 10,100 lbs (4,581 kg) due to its heavier-duty frame and powertrain.
Towing Equipment and Setup
Proper towing equipment is as important as the vehicle’s rated capacity. Using an underpowered hitch or missing a brake controller when towing heavier loads creates measurable safety risks.
Factory Tow Package
The GMC Yukon XL’s available Max Trailering Package (RPO code NHT) adds an extra-capacity cooling system, transmission cooler, and the ProGrade Trailering System. The ProGrade system includes a trailer brake controller, hitch guidance with hitch view, and an in-vehicle trailering app. Without this package, standard towing ratings are 400 to 1,500 lbs lower depending on the generation and engine combination.
Weight-Distributing Hitch
A weight-distributing hitch spreads tongue weight across all axles rather than concentrating it at the rear hitch point. The 2024 Yukon XL allows a maximum trailer weight of 7,800 lbs under a weight-distributing hitch configuration versus 5,000 lbs with a dead-weight hitch. Using a weight-distributing setup on trailers above 5,000 lbs gross weight is strongly recommended.
Normal Towing vs. Heavy Towing Equipment
| Equipment Item | Normal Towing (Under 5,000 lbs) | Heavy Towing (5,000 – 8,300 lbs) |
|---|---|---|
| Hitch Type | Dead-weight Class III/IV | Weight-distributing Class IV |
| Trailer Brake Controller | Not required | Required (electric or proportional) |
| Transmission Cooler | Standard cooler sufficient | Add-on or NHT package cooler required |
| Sway Control | Not required | Trailer sway control recommended |
| Tire Load Rating | Standard vehicle tires | Verify load index against GVWR |
| Axle Ratio | Standard | 3.23 or 3.42 recommended |
Trailer Sway Control
Trailer sway control is either integrated into the vehicle’s stability system or added via the weight-distributing hitch head unit. On Yukon XL models equipped with the NHT package, the factory ProGrade system supports trailer sway detection. For trailers exceeding 50 percent of tow vehicle weight, an aftermarket sway bar or friction sway control device adds an additional layer of stability.
Frequently Asked Questions
What is the maximum towing capacity of a GMC Yukon XL?
The maximum towing capacity of a GMC Yukon XL is 8,300 lbs (3,765 kg) for 2021 and newer models equipped with the 5.3L V8 in 2WD and the NHT Max Trailering Package. Earlier 2023 configurations with the 6.2L engine reached 8,400 lbs in certain trim configurations. For 2000-2001 models, the maximum was 8,800 lbs with appropriate engine and axle configuration.
How much can a GMC Yukon XL tow with the factory tow package?
With the Max Trailering Package (NHT), the 2024 GMC Yukon XL can tow up to 8,300 lbs (3,765 kg) in 2WD with the 5.3L V8. Without this package, the same drivetrain configuration is rated at 7,800 lbs. The NHT package adds a transmission cooler, auxiliary engine cooler, and integrated trailer brake controller.
Does 4WD affect GMC Yukon XL towing capacity?
Yes. Selecting 4WD reduces the maximum towing capacity by approximately 200 to 300 lbs compared to 2WD on the same model year and engine. For example, the 2024 Yukon XL 5.3L with the NHT package is rated at 8,300 lbs in 2WD and 8,000 lbs in 4WD. The weight difference of the 4WD components reduces available payload and towing headroom.
What trailer weight is safe for a GMC Yukon XL?
The generally accepted safe practice is to stay within 80 percent of the rated maximum towing capacity. On a 2024 Yukon XL rated to 8,300 lbs, this places the practical working limit at approximately 6,640 lbs. Payload capacity must also be calculated separately, as tongue weight counts against the vehicle’s maximum payload rating.
Do I need a weight-distributing hitch for a GMC Yukon XL?
A weight-distributing hitch is recommended when the trailer’s gross weight exceeds 5,000 lbs, as the dead-weight hitch limit for the Yukon XL is rated at 5,000 lbs. Trailers above this threshold connected to a standard ball mount concentrate excessive load on the rear axle, reducing front steering and braking effectiveness. A weight-distributing hitch restores level vehicle attitude and maintains rated towing limits.
What hitch class does the GMC Yukon XL use?
The GMC Yukon XL uses a Class IV trailer hitch with a 2-inch square receiver as standard for most towing applications. Some aftermarket and heavy-duty configurations use a Class V receiver for higher gross trailer weight ratings. The factory receiver and hitch ball mount must be rated to at least the vehicle’s maximum tongue weight limit.
Conclusion
The GMC Yukon XL towing capacity ranges from 7,800 lbs in base configurations to 8,800 lbs in early model years, with 2021 and newer models rated up to 8,300 lbs when properly equipped. Engine selection between the 5.3L V8, 6.2L V8, and 3.0L diesel inline-six, combined with drivetrain choice and the NHT Max Trailering Package, determines the final trailer weight limit for each specific build. Payload capacity is a separate and equally critical specification; tongue weight loads reduce available cargo and passenger capacity below the GVWR ceiling. All towing specifications listed in this guide apply to the Yukon XL 1500 variant unless otherwise noted; the Yukon XL 2500, offered in earlier generations, carries substantially higher trailer weight limits.
Always verify towing specifications using the owner’s manual before towing heavy loads.
