The Jaguar F-Pace (X761) is a compact luxury crossover SUV manufactured by Jaguar Land Rover. It entered production with customer deliveries beginning in April 2016 in Europe and May 2016 in the United States. The F-Pace has been offered in multiple powertrain configurations across its production life, including turbocharged diesel, turbocharged petrol, plug-in hybrid, and mild-hybrid variants.
This guide provides year-by-year towing specifications, including maximum trailer weight, payload capacity, tongue weight limits, and hitch class. Towing capacity varies by engine configuration, drivetrain setup, and whether the factory tow package is fitted. Following manufacturer-rated towing limits protects the engine, transmission, braking system, and chassis integrity.
Quick Navigation
2026 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 (P250); 3.0L turbocharged I6 (P400); 5.0L supercharged V8 SVR 575 |
| Drivetrain | AWD (standard across all trims) |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,170 – 1,540 lbs / 531 – 698 kg (varies by trim) |
| Gross Combined Weight Rating (GCWR) | 10,845 – 11,020 lbs / 4,919 – 4,998 kg |
| Tongue Weight Limit | 529 lbs / 240 kg |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2026 Jaguar F-Pace offers a maximum towing capacity of 5,291 lbs (2,400 kg) across standard petrol and inline-six configurations when properly equipped with a tow package. The P250 trim provides the highest payload figure at 1,540 lbs, while the heavier SVR 575 variant carries a reduced payload of 1,170 lbs. Maintaining tongue weight within the rated limit preserves steering response and chassis stability during towing.
2025 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 (P250); 3.0L turbocharged I6 (P400); 2.0L I4 PHEV (P400e) |
| Drivetrain | AWD |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg (P250, P400); 4,409 lbs / 2,000 kg (P400e PHEV) |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg (P250, P400); 4,409 lbs / 2,000 kg (P400e) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,425 – 1,540 lbs / 646 – 698 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 – 11,020 lbs / 4,919 – 4,998 kg |
| Tongue Weight Limit | 529 lbs / 240 kg (braked trailer nose weight) |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2025 Jaguar F-Pace retains the same core towing architecture as prior model years. The plug-in hybrid P400e powertrain carries a reduced maximum towing rating of 4,409 lbs (2,000 kg) due to the additional weight of the battery pack. Petrol and diesel variants with the factory tow package support the full 2,400 kg braked trailer weight rating.
2024 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 (P250); 3.0L turbocharged I6 (P400); 2.0L I4 PHEV (P400e) |
| Drivetrain | AWD |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg (P250, P400); 4,409 lbs / 2,000 kg (P400e) |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg (P250, P400) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 – 1,540 lbs / 635 – 698 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 lbs / 4,919 kg |
| Tongue Weight Limit | 386 lbs / 175 kg (nose weight, varies by wheel fitment) |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2024 Jaguar F-Pace supports braked trailer towing up to 2,400 kg across its petrol and mild-hybrid configurations. The maximum nose weight (tongue weight) for the 2024 model is rated at up to 175 kg, and this figure varies depending on wheel specification fitted to the vehicle. The P400e PHEV variant remains limited to 2,000 kg maximum braked towing.
2023 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 (P250); 3.0L turbocharged I6 (P400); 2.0L I4 PHEV (P400e) |
| Drivetrain | AWD |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg (P250, P400); 4,409 lbs / 2,000 kg (P400e) |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 – 1,540 lbs / 635 – 698 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 lbs / 4,919 kg |
| Tongue Weight Limit | 386 lbs / 175 kg |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2023 Jaguar F-Pace towing capacity reaches 5,291 lbs (2,400 kg) when configured with standard petrol drivetrains and the optional tow package. The unbraked trailer limit across all configurations is 1,653 lbs (750 kg). Exceeding the unbraked limit requires the use of a trailer with its own overrun brake system.
2022 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 (P250, P340); 3.0L turbocharged I6 (P400); 2.0L I4 PHEV (P400e) |
| Drivetrain | AWD |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg (P250, P340, P400); 4,409 lbs / 2,000 kg (P400e) |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 lbs / 4,919 kg |
| Tongue Weight Limit | 386 lbs / 175 kg |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2022 Jaguar F-Pace towing capacity is rated at up to 5,291 lbs when properly equipped with petrol engine configurations. The P400e PHEV variant, introduced with the 2021 facelift and carried forward, is rated at 2,000 kg braked due to its increased kerb weight of approximately 2,230 kg. All variants are restricted to a 750 kg unbraked trailer limit.
2021 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 (P250, P340); 3.0L turbocharged I6 (P400); 2.0L I4 PHEV (P400e); 5.0L supercharged V8 SVR |
| Drivetrain | AWD |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg (P250, P340, P400, SVR); 4,409 lbs / 2,000 kg (P400e) |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 lbs / 4,919 kg |
| Tongue Weight Limit | 386 lbs / 175 kg |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2021 model year introduced the mid-cycle facelift to the F-Pace lineup, adding the 2.0L I4 plug-in hybrid (P400e) and 3.0L I6 mild-hybrid technology to the range. The P400e towing capacity is rated at 4,409 lbs (2,000 kg) braked, lower than the combustion-only variants. All petrol and mild-hybrid variants maintain the 5,291 lbs (2,400 kg) maximum braked towing rating.
2020 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 diesel/petrol (180D, 240D, P250, P300); 3.0L diesel V6 (300 Sport); 3.0L supercharged V6 petrol (S); 5.0L supercharged V8 (SVR) |
| Drivetrain | AWD (standard), RWD (select trims) |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 lbs / 4,919 kg |
| Tongue Weight Limit | 386 lbs / 175 kg |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2020 Jaguar F-Pace supports a maximum towing capacity of 5,291 lbs (2,400 kg) across all engine configurations. This model year retained the pre-facelift powertrain lineup including the 3.0L supercharged V6 petrol producing 380 hp and the 5.0L supercharged V8 SVR producing 550 hp. The towing specification is consistent across trim levels when the tow package is properly specified.
2019 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 diesel/petrol; 3.0L supercharged V6 (S); 5.0L supercharged V8 (SVR) |
| Drivetrain | AWD (standard), RWD (select base trims) |
| Maximum Towing Capacity | 5,290 lbs / 2,400 kg |
| Conventional Towing Capacity | 5,290 lbs / 2,400 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 lbs / 4,919 kg |
| Tongue Weight Limit | 386 lbs / 175 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2019 Jaguar F-Pace maximum towing capacity is rated at 5,290 lbs (2,400 kg) and applies uniformly across all available engine options. Standard AWD provides additional traction control benefits during trailer towing operations. A Class III receiver hitch is compatible with the 2019 model, rated to 6,000 lbs gross trailer weight.
2018 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 diesel/petrol; 3.0L turbocharged diesel V6; 3.0L supercharged V6 petrol; 5.0L supercharged V8 SVR |
| Drivetrain | AWD (standard), RWD (select variants) |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 lbs / 4,919 kg |
| Tongue Weight Limit | 386 lbs / 175 kg |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2018 Jaguar F-Pace braked towing capacity is rated at 2,400 kg across its full powertrain range. The SVR variant, powered by the 5.0L supercharged V8 producing 542 hp, maintains the same trailer weight rating as base models despite its significantly higher power output. Aftermarket Class III or Class IV hitches rated to 6,000 lbs GTW are available for the 2018 model year.
2017 Jaguar F-Pace Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L turbocharged I4 diesel (180D, 240D); 3.0L turbocharged diesel V6 (3.0D); 2.0L turbocharged I4 petrol (P250, P300); 3.0L supercharged V6 petrol (S) |
| Drivetrain | AWD (standard), RWD (select entry variants) |
| Maximum Towing Capacity | 5,291 lbs / 2,400 kg |
| Conventional Towing Capacity | 5,291 lbs / 2,400 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 10,845 lbs / 4,919 kg |
| Tongue Weight Limit | 386 lbs / 175 kg |
| Hitch Class | Class III / Class IV |
| Factory Tow Package | Optional |
The 2017 Jaguar F-Pace is the first model year offered to retail customers and carries a maximum towing capacity of 2,400 kg (5,291 lbs). The 3.0L diesel variant (3.0D S) was recognized for its towing performance, finishing at the top of its weight class in independent tow car evaluations. Class IV towbar fitments for the 2017 and later F-Pace are rated to match the full 2,400 kg tow rating.
Towing Equipment and Setup
Proper towing equipment is required to safely reach the rated maximum trailer weight for any F-Pace configuration.
Tow Package
The factory tow package includes an integrated or detachable towbar, 13-pin towing electrics, and a 50 mm tow ball. The fixed towbar nose weight limit is rated at up to 200 kg, while the detachable towbar variant supports up to 195 kg nose weight. The tow package also includes a trailer light test facility on factory-fitted Jaguar towbars.
Trailer Brake Controller
Any trailer exceeding 750 kg gross trailer weight requires a braked trailer setup with overrun brakes or an electronic brake controller. Australian regulations require a minimum tongue weight of 7% and a maximum of 10% of gross trailer weight. Trailer brake controllers improve braking distance and reduce trailer sway risk under heavy loads.
Weight-Distributing Hitch
The F-Pace does not support weight distribution kits on most aftermarket Class IV hitches. Weight distribution hardware is not applicable for this vehicle class. Ensure that trailer load distribution is managed by correctly positioning cargo within the trailer rather than using a weight-distribution system.
Normal Towing vs. Heavy Towing Setup
| Factor | Normal Towing (Under 1,500 kg) | Heavy Towing (1,500 – 2,400 kg) |
|---|---|---|
| Trailer Brakes | Overrun brakes recommended | Required |
| Tongue Weight | 7-10% of trailer weight | Must not exceed 175-200 kg rated limit |
| Tow Package | Recommended | Mandatory |
| Transmission Cooler | Not required | Recommended on extended trips |
| Tyre Inflation | Standard rated pressure | Verify load rating compliance |
| Trailer Sway Control | Optional | Strongly recommended |
Frequently Asked Questions
What is the maximum towing capacity of a Jaguar F-Pace?
The maximum towing capacity of the Jaguar F-Pace is 5,291 lbs (2,400 kg) for braked trailer towing. This applies to petrol and diesel-powered variants when fitted with the factory tow package. The unbraked trailer limit for all F-Pace variants is 750 kg (1,653 lbs).
How much can a Jaguar F-Pace tow with a tow package?
With the factory tow package fitted, the Jaguar F-Pace can tow up to 2,400 kg (5,291 lbs) on models with petrol or diesel combustion engines. The tow package includes a 50 mm tow ball, 13-pin electrics, and either a fixed or detachable towbar. Without the tow package, towing is not recommended by the manufacturer.
Does the Jaguar F-Pace P400e PHEV have a lower towing capacity?
Yes. The Jaguar F-Pace P400e plug-in hybrid carries a reduced towing rating of 4,409 lbs (2,000 kg) compared to the standard 2,400 kg for combustion variants. The reduction is attributed to the additional mass of the hybrid battery system, which raises the kerb weight to approximately 2,230 kg. This limits the available towing headroom relative to vehicle kerb weight.
What hitch class does the Jaguar F-Pace use?
The Jaguar F-Pace uses a Class III or Class IV receiver hitch with a 2-inch (50 mm) receiver opening. Aftermarket Class III hitches are rated to 6,000 lbs gross trailer weight (GTW) and 900 lbs tongue weight. Factory Jaguar towbars use a 50 mm tow ball compatible with European towing standards.
What is the tongue weight limit for the Jaguar F-Pace?
The maximum coupling point nose weight (tongue weight) for the Jaguar F-Pace is up to 175 kg with the factory towbar, depending on powertrain and wheel specification. The fixed towbar variant supports a slightly higher nose weight of up to 200 kg. Exceeding this limit places excessive load on the rear axle and reduces steering precision.
Do I need a weight-distributing hitch for the Jaguar F-Pace?
A weight-distributing hitch is not applicable or supported on the Jaguar F-Pace platform. Trailer load balance should be managed by ensuring cargo is positioned ahead of the trailer axle and that tongue weight remains within the manufacturer-stated limit. A correctly loaded trailer reduces sway risk without the need for a weight-distribution system.
Conclusion
The Jaguar F-Pace towing capacity ranges from 4,409 lbs (2,000 kg) on the P400e plug-in hybrid variant to 5,291 lbs (2,400 kg) on all standard petrol and diesel combustion-engine configurations. This rating has remained consistent across the model’s production years from 2017 through 2026 for non-hybrid variants. Engine configuration, tow package fitment, and wheel specification are the primary factors that determine the specific towing limits applicable to any individual vehicle.
The factory tow package is required to achieve the rated maximum trailer weight, and its specification differs between the fixed and detachable towbar options in terms of nose weight capacity. The P400e PHEV powertrain represents the sole exception to the 2,400 kg class limit, carrying a manufacturer-rated reduction due to battery system weight. Always verify specifications using the owner’s manual and vehicle-specific data before towing heavy loads.
