The Jeep Patriot is a compact SUV produced by Jeep from 2007 through 2017. It was sold as a five-door crossover utility vehicle across multiple trim levels, including Sport, Latitude, Limited, and High Altitude. This guide covers towing capacity by model year, including maximum trailer weight, tongue weight, and hitch requirements for each configuration.
The Patriot was offered with two engine options throughout its production run: a 2.0-liter and a 2.4-liter four-cylinder. Towing capacity depended primarily on whether a factory tow package was installed, not on engine displacement alone. Respecting manufacturer-rated towing limits is essential for protecting the engine, transmission, braking system, and drivetrain components.
Quick Navigation
2017 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AHC or AWL package) |
The 2017 Jeep Patriot delivers a maximum towing capacity of 2,000 lbs (907 kg) when equipped with the factory Trailer Tow Prep Package (AHC) or the Freedom Drive II Off-Road Package (AWL). Models without a tow package are rated at 1,000 lbs (454 kg) regardless of engine choice. Installing a factory tow package, which includes an engine oil cooler and trailer wiring harness, is required to achieve the higher trailer weight rating.
2016 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AHC or AWL package) |
The 2016 Jeep Patriot shares the same towing specifications as the 2017 model, with a maximum trailer weight of 2,000 lbs (907 kg) when properly equipped. Base configurations without either optional package are limited to 1,000 lbs (454 kg) of maximum trailer weight. Tongue weight must not exceed 200 lbs (91 kg) with a tow package installed.
2015 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AHC or AWL package) |
The 2015 Jeep Patriot carries a maximum towing capacity of 2,000 lbs (907 kg) with the optional tow package fitted. Without either factory package, all 2015 trims are rated at 1,000 lbs (454 kg) regardless of engine or drivetrain configuration. Confirming the presence of the engine oil cooler and factory trailer wiring harness is necessary before towing at maximum capacity.
2014 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AHC or AWL package) |
The 2014 Jeep Patriot is rated at 1,000 lbs (454 kg) in base configuration and up to 2,000 lbs (907 kg) when equipped with the Trailer Tow Prep or Freedom Drive II Off-Road Package. The 2.4L engine paired with the off-road package provides the maximum trailer weight rating for this model year. Standard tongue weight limits apply at 100 lbs (45 kg) without the package and 200 lbs (91 kg) with it.
2013 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AWL Off-Road package for 2.4L only) |
The 2013 Jeep Patriot towing capacity tops out at 2,000 lbs (907 kg), but the higher rating was available only on the 2.4L engine with the Freedom Drive II Off-Road Package. The 2.0L engine was limited to 1,000 lbs (454 kg) in all configurations for this model year. Trailer tongue weight must remain at or below 200 lbs (91 kg) when towing at maximum capacity.
2012 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AWL Off-Road package for 2.4L only) |
The 2012 Jeep Patriot follows the same specifications as the 2013 model, with a maximum towing capacity of 2,000 lbs (907 kg) limited to the 2.4L engine with the off-road package. Base models with the 2.0L engine are rated at 1,000 lbs (454 kg) maximum trailer weight. Tongue weight limits remain 100 lbs (45 kg) without a package and 200 lbs (91 kg) with one.
2011 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AWL Off-Road package for 2.4L only) |
The 2011 Jeep Patriot maximum towing capacity is 2,000 lbs (907 kg) on 2.4L models equipped with the Freedom Drive II Off-Road Package. All other configurations, including all 2.0L variants, carry a 1,000 lb (454 kg) trailer weight limit. The Class III hitch receiver, available for this generation, supports the rated gross trailer weight when paired with a factory-installed tow package.
2010 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AWL Off-Road package for 2.4L only) |
The 2010 Jeep Patriot carries the same towing limits as other vehicles in the 2010-2013 generation group, with a maximum of 2,000 lbs (907 kg) under specific engine and package conditions. Class III hitch hardware is compatible with this model year, supporting trailer connections up to the rated weight limit. GVWR and GCWR values are located on the driver-side door jamb certification label.
2009 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L I4 / 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 150 lbs (68 kg) |
| Tongue Weight Limit (with tow package) | 250 lbs (113 kg) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (AWL Off-Road package for 2.4L only) |
The 2009 Jeep Patriot is notable for having higher tongue weight limits than surrounding model years, with 150 lbs (68 kg) in the base configuration and 250 lbs (113 kg) when the off-road package is installed. Maximum trailer weight ratings remain consistent with adjacent model years at 1,000 lbs (454 kg) without a package and 2,000 lbs (907 kg) with one. This model year was available only with the 2.4L engine to achieve the upper towing limit.
2008 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II |
| Factory Tow Package | Optional (AHC Trailer Tow Prep Package) |
The 2008 Jeep Patriot was offered exclusively with the 2.4L four-cylinder engine, with a maximum towing capacity of 2,000 lbs (907 kg) when the Trailer Tow Prep Package was installed. Base models without the tow package carry a 1,000 lb (454 kg) trailer weight limit and a 100 lb (45 kg) tongue weight limit. The AHC package for this model year included an engine oil cooler, full-size spare tire, and trailer wiring harness.
2007 Jeep Patriot Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity (with tow package) | 2,000 lbs (907 kg) |
| Conventional Towing Capacity (without tow package) | 1,000 lbs (454 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | See door jamb certification label |
| Gross Combined Weight Rating (GCWR) | See door jamb certification label |
| Tongue Weight Limit (without tow package) | 100 lbs (45 kg) |
| Tongue Weight Limit (with tow package) | 200 lbs (91 kg) |
| Hitch Class | Class II |
| Factory Tow Package | Optional (AHC Trailer Tow Prep Package) |
The 2007 Jeep Patriot is the first model year of the Patriot lineup and carries a maximum trailer weight of 2,000 lbs (907 kg) with the factory tow package. Without the package, the standard towing limit for all 2007 models is 1,000 lbs (454 kg) with a tongue weight not to exceed 100 lbs (45 kg). A Class II hitch is appropriate for this model year given the vehicle’s rated towing specifications.
Towing Equipment and Setup
Proper towing equipment is critical for safe operation within the Jeep Patriot’s rated towing limits. The factory tow package includes an engine oil cooler, trailer wiring harness, and full-size spare tire, all of which are required to achieve the 2,000 lb (907 kg) maximum trailer weight rating. Aftermarket hitch hardware does not substitute for factory-installed packages, as the manufacturer warranties only factory components.
Factory Tow Packages
The Jeep Patriot offered two factory tow-related packages:
- AHC (Trailer Tow Prep Package): Includes engine oil cooler, full-size spare tire, and trailer wiring harness
- AWL (Freedom Drive II Off-Road Package): Includes all AHC components plus skid plates, all-terrain tires, and additional off-road hardware for 4WD-capable configurations
Trailer Brakes
Jeep’s guidelines recommend trailer brakes for trailers weighing between 1,000 and 1,999 lbs, and require trailer brakes for any trailer at or above 2,000 lbs. State and local regulations may impose lower thresholds for trailer brake requirements, so checking applicable laws before towing is necessary.
Towing Setup Reference
| Component | Standard Setup (up to 1,000 lbs) | Maximum Capacity Setup (up to 2,000 lbs) |
|---|---|---|
| Hitch Class | Class II | Class II / Class III |
| Factory Tow Package | Not required | Required (AHC or AWL) |
| Engine Oil Cooler | Not required | Required |
| Trailer Wiring Harness | Recommended | Required |
| Trailer Brakes | Not required | Recommended to Required |
| Full-Size Spare Tire | Not required | Required (part of tow package) |
| Tongue Weight Limit | 100 lbs (45 kg) | 200 lbs (91 kg) |
The tongue weight must not exceed the limits listed in the owner’s manual, as excess tongue weight stresses the rear axle and compromises front-axle steering control. A weight-distributing hitch is not recommended for the Patriot given its light-duty towing specifications. Verifying proper tire load ratings and maintaining correct tire inflation is essential when towing near maximum limits.
Frequently Asked Questions
What is the maximum towing capacity of a Jeep Patriot?
The maximum towing capacity for a Jeep Patriot is 2,000 lbs (907 kg) across all model years from 2007 to 2017. This rating requires the factory Trailer Tow Prep Package (AHC) or Freedom Drive II Off-Road Package (AWL) to be installed. Without either package, the maximum trailer weight limit is 1,000 lbs (454 kg).
How much can a Jeep Patriot tow with a tow package?
A Jeep Patriot equipped with the factory tow package can tow up to 2,000 lbs (907 kg) gross trailer weight. The package must include an engine oil cooler and factory-installed trailer wiring harness to achieve this rating. Tongue weight in this configuration is limited to 200 lbs (91 kg) for most model years.
Does 4WD or AWD affect Jeep Patriot towing capacity?
Drivetrain configuration does not directly determine the Patriot’s towing capacity rating; the presence of a factory tow package is the primary determining factor. However, the Freedom Drive II Off-Road Package, which unlocks the 2,000 lb (907 kg) rating on 2010-2013 models with the 2.4L engine, is tied to the AWD drivetrain system. The 2014-2017 model years allow the higher towing capacity on both FWD and AWD configurations with the appropriate package.
What trailer weight is safe for a Jeep Patriot?
A trailer weight at or below 1,000 lbs (454 kg) is within the base rated limit for all Patriot model years without a tow package. For Patriot models with a factory tow package, trailers up to 2,000 lbs (907 kg) are within the manufacturer-rated towing limit. Total towing loads must account for passengers, cargo, and equipment weight relative to the Gross Combined Weight Rating on the door jamb label.
Do I need a weight-distributing hitch for a Jeep Patriot?
A weight-distributing hitch is not necessary or recommended for the Jeep Patriot given its light-duty towing capacity range of 1,000 to 2,000 lbs. The Class II hitch receiver with a standard ball mount is appropriate for this vehicle’s rated specifications. Always match the hitch class and ball mount rating to the actual trailer weight being towed.
Do I need trailer brakes when towing with a Jeep Patriot?
Trailer brakes are recommended by Jeep for trailers weighing between 1,000 and 1,999 lbs when towing with a Patriot. Trailer brakes are required for trailers at or above 2,000 lbs, which represents the Patriot’s maximum towing capacity. Individual state laws may require trailer brakes at lower weight thresholds, so verifying local requirements before towing is important.
Conclusion
The Jeep Patriot towing capacity ranges from 1,000 lbs (454 kg) to 2,000 lbs (907 kg) across all model years from 2007 through 2017. The factory Trailer Tow Prep Package (AHC) or Freedom Drive II Off-Road Package (AWL) is the primary variable that determines whether a given Patriot can reach the upper towing limit. Engine displacement had minimal impact on the towing rating; the presence of the oil cooler, wiring harness, and supporting equipment within the factory package defines the vehicle’s towing capability. Towing capacity specifications did not change significantly across the production run, making the Patriot a consistent, predictable light-duty tow vehicle within its rated limits. Always verify towing specifications against the owner’s manual and door jamb certification label before towing any load.
