The Cadillac XT5 has been produced from 2017 to present with two primary engine options. Using the correct oil capacity, viscosity, and type is essential for maintaining performance and longevity. This guide lists all model years with full oil specifications and maintenance recommendations.
Proper engine oil ensures adequate lubrication, reduces friction, and protects internal components from wear. The XT5 requires dexos-certified full synthetic oil to meet General Motors engineering standards and maintain warranty coverage.
Quick Navigation
2025 Cadillac XT5 Engine Oil Capacity
2.0L Turbo I4 (LSY)
| Specification | Detail |
|---|---|
| Engine | 2.0L Turbo I4 (LSY) |
| Oil Capacity (with Filter) | 5.3 qt (5.0 L) |
| Oil Capacity (without Filter) | 5.0 qt (4.7 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | ACDelco PF66, Mobil 1 M1-110A, K&N HP-1017 |
The 2025 Cadillac XT5 with the 2.0L turbocharged engine requires 5.3 quarts of full synthetic oil with a filter change. Using SAE 0W-20 oil meeting dexos1 specifications provides optimal protection and fuel efficiency under normal driving conditions.
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2025 Cadillac XT5 with the 3.6L V6 engine requires 6.0 quarts of full synthetic oil with a filter change. SAE 5W-30 dexos1 oil ensures proper lubrication across the engine’s temperature range and cylinder deactivation system.
2024 Cadillac XT5 Engine Oil Capacity
2.0L Turbo I4 (LSY)
| Specification | Detail |
|---|---|
| Engine | 2.0L Turbo I4 (LSY) |
| Oil Capacity (with Filter) | 5.3 qt (5.0 L) |
| Oil Capacity (without Filter) | 5.0 qt (4.7 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | ACDelco PF66, Mobil 1 M1-110A, K&N HP-1017 |
The 2024 Cadillac XT5 with the 2.0L turbo engine requires 5.3 quarts of SAE 0W-20 full synthetic oil. This viscosity provides excellent cold-start protection and maintains proper oil pressure under all operating temperatures.
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2024 Cadillac XT5 equipped with the 3.6L V6 engine uses 6.0 quarts of SAE 5W-30 full synthetic oil. The engine features Active Fuel Management technology that requires dexos1-certified oil for proper operation.
2023 Cadillac XT5 Engine Oil Capacity
2.0L Turbo I4 (LSY)
| Specification | Detail |
|---|---|
| Engine | 2.0L Turbo I4 (LSY) |
| Oil Capacity (with Filter) | 5.3 qt (5.0 L) |
| Oil Capacity (without Filter) | 5.0 qt (4.7 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | ACDelco PF66, Mobil 1 M1-110A, K&N HP-1017 |
The 2023 Cadillac XT5 with the 2.0L turbocharged four-cylinder engine requires 5.3 quarts of SAE 0W-20 dexos1 oil. Full synthetic oil provides superior protection for turbocharged engines operating under high temperature and pressure conditions.
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2023 Cadillac XT5 with the 3.6L V6 engine requires 6.0 quarts of SAE 5W-30 full synthetic oil meeting dexos1 specifications. Proper oil viscosity ensures effective lubrication of the variable valve timing and cylinder deactivation systems.
2022 Cadillac XT5 Engine Oil Capacity
2.0L Turbo I4 (LSY)
| Specification | Detail |
|---|---|
| Engine | 2.0L Turbo I4 (LSY) |
| Oil Capacity (with Filter) | 5.3 qt (5.0 L) |
| Oil Capacity (without Filter) | 5.0 qt (4.7 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | ACDelco PF66, Mobil 1 M1-110A, K&N HP-1017 |
The 2022 Cadillac XT5 with the 2.0L turbo I4 engine uses 5.3 quarts of SAE 0W-20 dexos1 full synthetic oil. This oil specification ensures proper turbocharger lubrication and maximizes engine protection during cold starts.
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2022 Cadillac XT5 equipped with the 3.6L V6 engine requires 6.0 quarts of SAE 5W-30 dexos1 oil. Using manufacturer-approved oil maintains optimal performance of the direct injection fuel system and variable displacement technology.
2021 Cadillac XT5 Engine Oil Capacity
2.0L Turbo I4 (LSY)
| Specification | Detail |
|---|---|
| Engine | 2.0L Turbo I4 (LSY) |
| Oil Capacity (with Filter) | 5.3 qt (5.0 L) |
| Oil Capacity (without Filter) | 5.0 qt (4.7 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | ACDelco PF66, Mobil 1 M1-110A, K&N HP-1017 |
The 2021 Cadillac XT5 with the 2.0L turbocharged engine requires 5.3 quarts of SAE 0W-20 full synthetic oil. All 2021 models came standard with all-wheel drive, requiring consistent oil maintenance for optimal drivetrain performance.
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2021 Cadillac XT5 with the 3.6L V6 engine uses 6.0 quarts of SAE 5W-30 dexos1 oil. Regular oil changes using the correct specification help maintain the dual-pressure control variable-displacement oil pump efficiency.
2020 Cadillac XT5 Engine Oil Capacity
2.0L Turbo I4 (LSY)
| Specification | Detail |
|---|---|
| Engine | 2.0L Turbo I4 (LSY) |
| Oil Capacity (with Filter) | 5.3 qt (5.0 L) |
| Oil Capacity (without Filter) | 5.0 qt (4.7 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | ACDelco PF66, Mobil 1 M1-110A, K&N HP-1017 |
The 2020 Cadillac XT5 received a refresh that introduced the 2.0L turbocharged engine as the new base powerplant. This engine requires 5.3 quarts of SAE 0W-20 dexos1 full synthetic oil for proper operation.
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2020 Cadillac XT5 with the 3.6L V6 engine requires 6.0 quarts of SAE 5W-30 dexos1 oil. This engine produces 310 horsepower and requires proper oil maintenance to support its variable valve timing system.
2019 Cadillac XT5 Engine Oil Capacity
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2019 Cadillac XT5 was equipped exclusively with the 3.6L V6 engine producing 310 horsepower. This engine requires 6.0 quarts of SAE 5W-30 dexos1 full synthetic oil to ensure proper lubrication and protection.
2018 Cadillac XT5 Engine Oil Capacity
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2018 Cadillac XT5 uses the 3.6L V6 engine with Active Fuel Management cylinder deactivation technology. This engine requires 6.0 quarts of SAE 5W-30 dexos1 full synthetic oil for optimal performance.
2017 Cadillac XT5 Engine Oil Capacity
3.6L V6 (LGX)
| Specification | Detail |
|---|---|
| Engine | 3.6L V6 (LGX) |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Standard | dexos1 Gen 2 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | ACDelco UPF63R, Mobil 1 M1-110, K&N HP-1008 |
The 2017 Cadillac XT5 was the inaugural model year that replaced the SRX crossover. The 3.6L V6 engine requires 6.0 quarts of SAE 5W-30 dexos1 full synthetic oil for proper operation.
Oil Maintenance and Service Tips
Regular oil level checks should be performed every fuel fill-up or at least monthly to ensure proper engine lubrication. The Cadillac XT5 uses an oil life monitoring system that calculates oil change intervals based on driving conditions, engine temperature, and mileage.
When performing an oil change, always replace the oil filter along with the engine oil to ensure maximum filtration efficiency. Use only dexos-certified full synthetic oil to maintain warranty coverage and optimal engine protection. The oil drain plug should be torqued to manufacturer specifications to prevent leaks and ensure proper sealing.
Check the oil level when the engine is cold and on level ground for accurate readings. Add oil only when the level falls below the minimum mark on the dipstick. Severe driving conditions including frequent short trips, trailer towing, or dusty environments may require more frequent oil changes every 5,000 miles.
Frequently Asked Questions
What kind of oil does a Cadillac XT5 use?
The Cadillac XT5 requires dexos1 Gen 2 certified full synthetic oil. The 2.0L turbo engine uses SAE 0W-20 viscosity, while the 3.6L V6 engine uses SAE 5W-30 viscosity. Only dexos-certified oils meet General Motors engineering standards for protection and performance.
How much oil does a Cadillac XT5 take?
The Cadillac XT5 oil capacity depends on the engine type. The 2.0L turbocharged four-cylinder engine requires 5.3 quarts with a filter change, while the 3.6L V6 engine requires 6.0 quarts with a filter change. Always verify the correct capacity for your specific engine configuration before adding oil.
What is the recommended oil type for a Cadillac XT5?
Cadillac recommends full synthetic motor oil meeting dexos1 Gen 2 specifications for all XT5 models. The specific viscosity depends on engine type: 0W-20 for the 2.0L turbo and 5W-30 for the 3.6L V6. Using non-dexos oil can void warranty coverage and reduce engine protection.
What is the oil change interval for a Cadillac XT5?
The Cadillac XT5 oil change interval is every 7,500 miles or 12 months, whichever comes first, when using dexos-certified full synthetic oil. The vehicle’s oil life monitoring system calculates the optimal change interval based on actual driving conditions. Severe driving conditions may require more frequent changes every 5,000 miles.
Can I use 5W-30 oil in a Cadillac XT5 with a 2.0L turbo engine?
No, the 2.0L turbo engine requires SAE 0W-20 oil specifically. Using 5W-30 oil in place of the specified 0W-20 can affect fuel economy, cold-start protection, and may not provide adequate lubrication for the turbocharged engine. Always use the viscosity grade specified on the oil filler cap and owner’s manual.
What oil filter does a Cadillac XT5 use?
The Cadillac XT5 uses different oil filters depending on engine type. The 2.0L turbo engine uses ACDelco PF66, while the 3.6L V6 engine uses ACDelco UPF63R or PF63. Equivalent filters from Mobil 1, K&N, and other manufacturers are also compatible when they meet OEM specifications.
Conclusion
The Cadillac XT5 requires specific oil capacities and viscosities based on engine configuration: 5.3 quarts of SAE 0W-20 for the 2.0L turbo or 6.0 quarts of SAE 5W-30 for the 3.6L V6. All XT5 models require dexos1 Gen 2 certified full synthetic oil for proper protection and warranty compliance.
Using manufacturer-approved oil specifications and following recommended oil change intervals ensures optimal engine performance, fuel efficiency, and longevity. Regular oil maintenance protects critical engine components and maintains the advanced technologies found in modern Cadillac powertrains.
