The Chrysler Pacifica has been produced in two distinct generations: the crossover wagon from 2004 to 2008 and the minivan from 2017 to present. Using the correct oil capacity, viscosity, and type is essential for maintaining engine performance and longevity. This guide lists all model years with full oil specifications and maintenance recommendations.
Quick Navigation
2026 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (ERC) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2026 Chrysler Pacifica uses a 3.6L Pentastar V6 engine that requires 5 quarts of full synthetic oil with filter. Using SAE 0W-20 oil provides the right balance of protection and efficiency under normal driving conditions.
2025 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (ERC) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2025 Chrysler Pacifica requires 5 quarts of 0W-20 full synthetic motor oil for its 3.6L V6 engine. The oil change indicator system will remind drivers when scheduled maintenance is due.
2024 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (ERC) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2024 Chrysler Pacifica uses 5 quarts of 0W-20 full synthetic oil for optimal engine protection. The 3.6L Pentastar V6 produces 287 horsepower and 262 lb-ft of torque.
2023 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (ERC) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2023 Chrysler Pacifica requires 5 quarts of 0W-20 full synthetic motor oil. Oil that meets Chrysler MS-6395 specification is recommended for proper engine protection.
2022 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (ERC/ERC Flex/EH3) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2022 Chrysler Pacifica uses a 3.6L Pentastar V6 with 5 quarts oil capacity. Both the standard and hybrid models require 0W-20 full synthetic oil.
2021 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (ERC/ERC Flex/EH3 Hybrid) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2021 Chrysler Pacifica requires 5 quarts of 0W-20 synthetic oil for all engine variants. The hybrid model uses the same oil capacity and type as the gasoline version.
2020 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (EH3/ERC/ERC Flex/ERF Flex) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2020 Chrysler Pacifica uses 5 quarts of 0W-20 full synthetic motor oil. Multiple engine codes are available but all share the same oil specifications.
2019 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (EH3/ERC/ERC Flex/ERF Flex) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2019 Chrysler Pacifica requires 5 quarts of 0W-20 synthetic oil for optimal performance. Both standard and hybrid models use the same oil capacity and viscosity.
2018 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (EH3/ERC/ERC Flex/ERF Flex) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Fram CH11665, WIX 57060 |
The 2018 Chrysler Pacifica uses 5 quarts of 0W-20 full synthetic oil. The oil filter is located in a housing that requires a 24mm socket for removal.
2017 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 (EH3/ERC/ERC Flex/ERF Flex) |
| Oil Capacity (with Filter) | 5 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 to 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-349, K68191349AC, Mahle OX787D, Fram CH11665 |
The 2017 Chrysler Pacifica was the first year of the minivan generation and requires 5 quarts of 0W-20 synthetic oil. This model replaced the Town and Country minivan.
2008 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.8L V6 or 4.0L V6 |
| Oil Capacity (with Filter) | 5.5 quarts (5.2 liters) |
| Oil Capacity (without Filter) | 5.0 quarts (4.7 liters) |
| Recommended Oil Type | Conventional or Synthetic Blend |
| Viscosity | SAE 5W-30 or 10W-30 |
| Oil Change Interval | Every 3,000 to 5,000 miles or 6 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Fram PH3614, Mopar 4105409AC, WIX 51515 |
The 2008 Chrysler Pacifica crossover uses either a 3.8L or 4.0L V6 engine with 5.5 quarts oil capacity. The 4.0L V6 produces 256 horsepower.
2007 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.8L V6 or 4.0L V6 |
| Oil Capacity (with Filter) | 5.5 quarts (5.2 liters) |
| Oil Capacity (without Filter) | 5.0 quarts (4.7 liters) |
| Recommended Oil Type | Conventional or Synthetic Blend |
| Viscosity | SAE 5W-30 or 10W-30 |
| Oil Change Interval | Every 3,000 to 5,000 miles or 6 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Fram PH3614, Mopar 4105409AC, WIX 51515 |
The 2007 Chrysler Pacifica requires 5.5 quarts of 5W-30 or 10W-30 motor oil. Both 3.8L and 4.0L V6 engines were available this year.
2006 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L V6 or 3.8L V6 |
| Oil Capacity (with Filter) | 5.5 quarts (5.2 liters) |
| Oil Capacity (without Filter) | 5.0 quarts (4.7 liters) |
| Recommended Oil Type | Conventional or Synthetic Blend |
| Viscosity | SAE 5W-30 or 10W-30 |
| Oil Change Interval | Every 3,000 to 5,000 miles or 6 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Fram PH3614, Mopar 4105409AC, WIX 51515 |
The 2006 Chrysler Pacifica uses 5.5 quarts of motor oil for both available engines. The 3.5L V6 produces 253 horsepower.
2005 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L V6 or 3.8L V6 |
| Oil Capacity (with Filter) | 5.5 quarts (5.2 liters) |
| Oil Capacity (without Filter) | 5.0 quarts (4.7 liters) |
| Recommended Oil Type | Conventional or Synthetic Blend |
| Viscosity | SAE 5W-30 or 10W-30 |
| Oil Change Interval | Every 3,000 to 5,000 miles or 6 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Fram PH3614, Mopar 4105409AC, WIX 51515 |
The 2005 Chrysler Pacifica requires 5.5 quarts of 5W-30 or 10W-30 motor oil. The crossover was available with front-wheel drive or all-wheel drive.
2004 Chrysler Pacifica Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L V6 or 3.8L V6 |
| Oil Capacity (with Filter) | 5.5 quarts (5.2 liters) |
| Oil Capacity (without Filter) | 5.0 quarts (4.7 liters) |
| Recommended Oil Type | Conventional or Synthetic Blend |
| Viscosity | SAE 5W-30 or 10W-30 |
| Oil Change Interval | Every 3,000 to 5,000 miles or 6 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Fram PH3614, Mopar 4105409AC, WIX 51515 |
The 2004 Chrysler Pacifica was the first model year of the crossover and uses 5.5 quarts of motor oil. Both 3.5L and 3.8L V6 engines require the same oil capacity and viscosity.
Oil Maintenance & Service Tips
Regular oil changes are critical for maintaining engine health and preventing premature wear. The 2017 and newer Chrysler Pacifica models feature an automatic oil change indicator system that monitors engine conditions and notifies drivers when service is due.
For normal driving conditions, synthetic oil change intervals can extend to 7,500 to 10,000 miles or 12 months. However, severe driving conditions require more frequent oil changes. Severe conditions include frequent short trips, extensive idling, towing, dusty environments, or extreme temperatures.
| Driving Condition | Oil Change Interval |
|---|---|
| Normal Driving (2017-2026) | 7,500 to 10,000 miles or 12 months |
| Severe Driving (2017-2026) | 5,000 to 7,500 miles or 6 months |
| Normal Driving (2004-2008) | 3,000 to 5,000 miles or 6 months |
| Severe Driving (2004-2008) | 3,000 miles or 3 months |
When changing oil, always replace the oil filter with a quality part that meets OEM specifications. Torque the oil drain plug to the specified 20 lb-ft to prevent leaks or damage. Use only oil that meets Chrysler MS-6395 specification for 2017 and newer models.
Check oil level regularly between changes using the dipstick. The oil should be between the minimum and maximum marks when the engine is cold and on level ground. Overfilling can cause oil foaming and reduced lubrication.
FAQs
What kind of oil does a Chrysler Pacifica use?
The 2017-2026 Chrysler Pacifica uses SAE 0W-20 full synthetic motor oil that meets Chrysler MS-6395 specification. The 2004-2008 Pacifica crossover uses SAE 5W-30 or 10W-30 conventional or synthetic blend oil.
How much oil does a Chrysler Pacifica take?
The 2017-2026 Chrysler Pacifica takes 5 quarts (4.7 liters) of oil with filter. The 2004-2008 Pacifica crossover requires 5.5 quarts (5.2 liters) of oil with filter. Both generations require slightly less oil when changing without replacing the filter.
What is the recommended oil type for a Chrysler Pacifica?
The recommended oil type for 2017-2026 models is full synthetic 0W-20 oil. For 2004-2008 models, conventional or synthetic blend 5W-30 or 10W-30 oil is recommended. Always use oil that meets the manufacturer specifications for your specific model year.
What is the oil change interval for a Chrysler Pacifica?
The oil change interval for 2017-2026 models is every 7,500 to 10,000 miles or 12 months under normal driving conditions. For severe driving conditions, change oil every 5,000 to 7,500 miles. The 2004-2008 models require oil changes every 3,000 to 5,000 miles.
Can I use 5W-30 instead of 0W-20 in my Chrysler Pacifica?
Using 5W-30 instead of the specified 0W-20 oil in 2017-2026 models is not recommended. The 0W-20 viscosity is specifically engineered for the modern Pentastar V6 engine to provide optimal fuel economy and protection. Using incorrect viscosity can negatively impact engine performance and potentially void warranty coverage.
What oil filter should I use for a Chrysler Pacifica?
The recommended oil filter for 2017-2026 Chrysler Pacifica models is Mopar MO-349 or K68191349AC. Alternative quality filters include Fram CH11665, WIX 57060, and Mahle OX787D. For 2004-2008 models, use Fram PH3614, Mopar 4105409AC, or WIX 51515.
Conclusion
The Chrysler Pacifica requires different oil specifications depending on the generation and model year. Modern minivan models (2017-2026) use 5 quarts of 0W-20 full synthetic oil, while the earlier crossover generation (2004-2008) uses 5.5 quarts of 5W-30 or 10W-30 oil. Always use manufacturer-approved oil that meets the required specifications for your specific model year. Following proper oil change intervals and using quality oil filters ensures optimal engine protection and longevity.
