The Chrysler Pacifica has been produced in two distinct generations: a crossover SUV from 2004 to 2008, and a minivan reintroduced for the 2017 model year and continuing through 2026.
Towing capacity varies depending on model year, engine configuration, drivetrain, and whether the factory Trailer Tow Group is installed.
This guide provides year-by-year towing specifications, including maximum trailer weight, payload limits, hitch class, and tow package requirements.
Following manufacturer-rated towing limits helps protect the engine, transmission, and braking systems from premature wear and potential failure.
Quick Navigation
2026 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp / 262 lb-ft); Plug-in Hybrid V6 (not rated for towing) |
| Drivetrain | FWD (standard); AWD (available on gas models only) |
| Maximum Towing Capacity | 3,600 lbs / 1,633 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,417 lbs / 643 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg (10% of trailer weight) |
| Hitch Class | Class III |
| Factory Tow Package | Optional (Trailer Tow Group) |
The 2026 Chrysler Pacifica reaches a maximum towing capacity of 3,600 lbs when equipped with the available Trailer Tow Group.
Models powered by the 3.6L Pentastar V6, paired with the nine-speed automatic transmission and upgraded cooling system, deliver the highest trailer weight rating in the minivan segment.
The Pacifica Hybrid variant is not recommended for towing.
2025 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp / 262 lb-ft); Plug-in Hybrid V6 (not rated for towing) |
| Drivetrain | FWD (standard); AWD (available on gas models only) |
| Maximum Towing Capacity | 3,600 lbs / 1,633 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,417 lbs / 643 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional (Trailer Tow Group) |
The 2025 Chrysler Pacifica gas model offers a maximum towing capacity of 3,600 lbs when the Trailer Tow Group is selected.
The Trailer Tow Group includes a Class III 2-inch hitch receiver, 4- and 7-pin wiring harness, trailer sway damping, heavy-duty radiator, and 220-amp alternator.
The Pacifica Hybrid trim level is not equipped with towing hardware and is not recommended for trailer use.
2024 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L V6 (287 hp, 9-speed automatic); Plug-in Hybrid V6 (not rated for towing) |
| Drivetrain | FWD (standard); AWD (available on gas models only) |
| Maximum Towing Capacity | 3,600 lbs / 1,633 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,417 lbs / 643 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 300 lbs / 136 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional (Trailer Tow Group on Touring Plus, Touring L, Limited) |
The 2024 Chrysler Pacifica supports a maximum towing capacity of 3,600 lbs on gas-powered configurations equipped with the Trailer Tow Group.
The tow package includes a Class III 2-inch hitch receiver, 4/7-pin wiring harness, trailer sway damping, heavy-duty radiator, and 220-amp alternator. All-wheel drive is available only on gas variants and is not offered on the hybrid powertrain.
2023 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp); Plug-in Hybrid V6 |
| Drivetrain | FWD (standard); AWD (available on gas models) |
| Maximum Towing Capacity | 3,600 lbs / 1,632 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional (Limited and Pinnacle trims factory-installed; others optional) |
The 2023 Chrysler Pacifica tows between 1,500 lbs and 3,600 lbs depending on tow package installation. All trim levels, including Touring, Touring L, Limited, and Pinnacle, are eligible for the Trailer Tow Group upgrade to reach maximum trailer weight. Without the tow package, the rated towing limit drops to 1,500 lbs across all trims.
2022 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp); Plug-in Hybrid V6 |
| Drivetrain | FWD (standard); AWD (available on gas models) |
| Maximum Towing Capacity | 3,600 lbs / 1,632 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2022 Chrysler Pacifica tows up to 3,600 lbs when the Trailer Tow Group is installed on gas-powered models. Models without the factory tow package are limited to 1,500 lbs of trailer weight. The Class III hitch receiver fitted to 2022 models accepts a standard 2-inch ball mount.
2021 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp); Plug-in Hybrid V6 |
| Drivetrain | FWD (standard); AWD (available on gas models) |
| Maximum Towing Capacity | 3,600 lbs / 1,632 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2021 Chrysler Pacifica carries a maximum towing capacity of 3,600 lbs on properly equipped gas variants. Selecting the Trailer Tow Group is required to achieve this maximum trailer weight rating. Without the package, towing is limited to 1,500 lbs for all configurations.
2020 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp); Plug-in Hybrid V6 |
| Drivetrain | FWD (standard); AWD (available on gas models) |
| Maximum Towing Capacity | 3,600 lbs / 1,632 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2020 Chrysler Pacifica gas model supports a maximum towing capacity of 3,600 lbs with the optional Trailer Tow Group installed. Without the tow package, the trailer weight limit is 1,500 lbs. Tow package availability on the 2020 model includes a 2-inch Class III hitch receiver, 7-pin and 4-pin wiring harness, and trailer sway damping.
2019 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp); Plug-in Hybrid V6 (not recommended for towing) |
| Drivetrain | FWD standard |
| Maximum Towing Capacity | 3,600 lbs / 1,632 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2019 Chrysler Pacifica tows up to 3,600 lbs on gas models with the Trailer Tow Group. The Hybrid model years 2017 through 2019 are not recommended for towing per Chrysler’s owner’s manual. Gas-powered trims without the tow package are limited to 1,500 lbs.
2018 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp); Plug-in Hybrid V6 (not recommended for towing) |
| Drivetrain | FWD standard |
| Maximum Towing Capacity | 3,600 lbs / 1,632 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2018 Chrysler Pacifica gas model delivers a maximum towing capacity of 3,600 lbs when the Trailer Tow Group is fitted. The 2018 Hybrid variant is not recommended by Chrysler for trailer use. Unequipped gas models carry the standard 1,500 lb trailer weight limit.
2017 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V6 (287 hp); Plug-in Hybrid V6 (not recommended for towing) |
| Drivetrain | FWD standard |
| Maximum Towing Capacity | 3,600 lbs / 1,632 kg |
| Conventional Towing Capacity | 1,500 lbs / 680 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,400 lbs / 635 kg |
| Gross Vehicle Weight Rating (GVWR) | 6,055 lbs / 2,747 kg |
| Tongue Weight Limit | 360 lbs / 163 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2017 model year marked the reintroduction of the Pacifica nameplate as a minivan, replacing the Town and Country. Gas-powered configurations with the Trailer Tow Group achieve the full 3,600 lb maximum towing capacity. The 2017 Hybrid is not recommended for towing per manufacturer guidance.
Production Gap: 2009-2016
The Chrysler Pacifica was not produced between 2009 and 2016. No towing capacity data exists for these model years.
2008 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (250 hp) / 4.0L V6 (255 hp, available) |
| Drivetrain | FWD or AWD |
| Maximum Towing Capacity | 3,500 lbs / 1,588 kg (with engine cooler) |
| Conventional Towing Capacity | Not recommended without engine cooler |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,000 lbs / 454 kg |
| Gross Vehicle Weight Rating (GVWR) | Approx. 5,500 lbs / 2,495 kg |
| Tongue Weight Limit | 350 lbs / 159 kg |
| Hitch Class | Class III |
| Factory Tow Package | Optional (engine cooler required) |
The 2008 Chrysler Pacifica supports up to 3,500 lbs of trailer weight only when an engine cooler is installed. Without the engine cooler, Chrysler does not recommend towing with the 2008 model. This is the final model year of the first-generation crossover-based Pacifica.
2007 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.8L V6 (200 hp, FWD base) / 4.0L V6 (255 hp, other trims) |
| Drivetrain | FWD or AWD |
| Maximum Towing Capacity | 3,500 lbs / 1,588 kg |
| Conventional Towing Capacity | 3,500 lbs / 1,588 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,000 lbs / 454 kg |
| Gross Vehicle Weight Rating (GVWR) | Approx. 5,500 lbs / 2,495 kg |
| Tongue Weight Limit | 350 lbs / 159 kg |
| Hitch Class | Class III |
| Factory Tow Package | Standard on equipped trims |
The 2007 Chrysler Pacifica received a powertrain update, replacing the 3.5L V6 with a 4.0L V6 on most trims. Maximum towing capacity held at 3,500 lbs across all trim levels. The 4.0L engine paired with a 6-speed automatic transmission provided the most capable towing configuration in this generation.
2006 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (250 hp) – sole engine for 2006 |
| Drivetrain | FWD or AWD |
| Maximum Towing Capacity | 3,500 lbs / 1,588 kg |
| Conventional Towing Capacity | 3,500 lbs / 1,588 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,000 lbs / 454 kg |
| Gross Vehicle Weight Rating (GVWR) | Approx. 5,500 lbs / 2,495 kg |
| Tongue Weight Limit | 350 lbs / 159 kg |
| Hitch Class | Class III |
| Factory Tow Package | Standard on equipped trims |
The 2006 Chrysler Pacifica used a single 3.5L V6 engine across all trims, as Chrysler dropped the 3.8L base engine that year. Maximum towing capacity remained at 3,500 lbs for all configurations. Curb weight on the 2006 model was 4,639 lbs, which directly affects gross combined weight calculations.
2005 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (250 hp) standard; 3.8L V6 (210 hp) on base FWD |
| Drivetrain | FWD or AWD |
| Maximum Towing Capacity | 3,500 lbs / 1,588 kg |
| Conventional Towing Capacity | 3,500 lbs / 1,588 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,000 lbs / 454 kg |
| Gross Vehicle Weight Rating (GVWR) | Approx. 5,500 lbs / 2,495 kg |
| Tongue Weight Limit | 350 lbs / 159 kg |
| Hitch Class | Class III |
| Factory Tow Package | Standard on equipped trims |
The 2005 Chrysler Pacifica introduced a 3.8L V6 on the base front-wheel-drive trim, while higher configurations used the 3.5L V6 with 250 hp. Maximum towing capacity was rated at 3,500 lbs. The 3.5L engine offered improved torque characteristics better suited for maintaining consistent trailer weight under load.
2004 Chrysler Pacifica Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (250 hp / 250 lb-ft) |
| Drivetrain | FWD or AWD |
| Maximum Towing Capacity | 3,500 lbs / 1,588 kg |
| Conventional Towing Capacity | 3,500 lbs / 1,588 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,000 lbs / 454 kg |
| Gross Vehicle Weight Rating (GVWR) | Approx. 5,500 lbs / 2,495 kg |
| Tongue Weight Limit | 350 lbs / 159 kg |
| Hitch Class | Class III |
| Factory Tow Package | Standard on equipped trims |
The 2004 Chrysler Pacifica was the first model year, launched as a crossover SUV with a 3.5L V6 producing 250 hp. Maximum towing capacity was rated at 3,500 lbs for all configurations. The 2004 model had a curb weight of 4,675 lbs on AWD trims, making proper GCWR calculations essential for safe towing.
Towing Equipment and Setup
Proper towing equipment ensures safe and legal operation within the manufacturer-rated towing limits. Below is a comparison of standard versus heavy towing setups for the Chrysler Pacifica.
Standard vs. Heavy Towing Setup
| Component | Standard Towing Setup | Recommended Heavy Towing Setup |
|---|---|---|
| Hitch Class | Class III (2-inch receiver) | Class III (2-inch receiver) |
| Wiring Harness | 4-pin flat connector | 7-pin round connector |
| Trailer Brakes | Not required under 1,500 lbs | Required for loads over 1,500 lbs |
| Weight Distribution | Not required | Recommended near maximum GCWR |
| Transmission Cooler | Stock (without tow package) | Upgraded (included in tow package) |
| Radiator | Stock | Heavy-duty (included in tow package) |
| Sway Control | Not included | Trailer sway damping (tow package) |
| Alternator | Standard | 220-amp (included in tow package) |
Tow Package
The factory Trailer Tow Group is the single most important component for maximizing the Chrysler Pacifica towing capacity. It includes a Class III 2-inch hitch receiver, 4- and 7-pin wiring harness, trailer sway damping, heavy-duty radiator, and 220-amp alternator. Without the tow package, the maximum rated trailer weight is 1,500 lbs on minivan-generation models.
Trailer Brake Controller
A trailer brake controller is required whenever the trailer exceeds 1,500 lbs (unbraked limit). Trailer brakes allow the trailer to slow itself during deceleration, which reduces stopping distance and lowers strain on the Pacifica’s brake system. Most states require trailer brakes on trailers exceeding 3,000 lbs gross trailer weight.
Weight-Distributing Hitch
A weight-distributing hitch uses spring bars to redistribute tongue weight across the front and rear axles of the tow vehicle. This is relevant for Pacifica owners towing near the 3,600 lb maximum trailer weight, as tongue weight can cause rear suspension sag. Note that the factory Class III hitch receiver on the Pacifica has limitations with weight distribution systems; consult the owner’s manual before use.
Tongue Weight
Tongue weight should equal 10 to 15 percent of gross trailer weight. For a trailer at the maximum 3,600 lb towing capacity, tongue weight should not exceed 360 lbs. Excessive tongue weight overloads the rear axle and negatively affects steering control and front-wheel traction.
Tire Load Ratings
Tires must be rated to carry the loaded vehicle weight plus tongue weight. Underinflated or improperly rated tires degrade handling and increase the risk of blowouts when towing near capacity.
Frequently Asked Questions
What is the maximum towing capacity of a Chrysler Pacifica?
The maximum towing capacity of a Chrysler Pacifica is 3,600 lbs on minivan-generation models (2017-2026) equipped with the factory Trailer Tow Group. First-generation crossover models (2004-2008) had a maximum towing capacity of 3,500 lbs. These figures apply only to gas-powered configurations; the Hybrid variant is not rated for towing on early model years.
How much can a Chrysler Pacifica tow with a tow package?
With the Trailer Tow Group installed, the Chrysler Pacifica gas model can tow up to 3,600 lbs. The tow package includes a Class III 2-inch hitch receiver, 4/7-pin wiring harness, trailer sway damping, heavy-duty radiator, and 220-amp alternator. Without the tow package, the trailer weight limit drops to 1,500 lbs.
Does AWD affect Chrysler Pacifica towing capacity?
AWD is available only on gas-powered Pacifica models from the minivan generation onward. Both FWD and AWD gas models share the same 3,600 lb maximum towing capacity when the Trailer Tow Group is fitted. AWD improves traction on wet boat ramps or loose surfaces during trailer hookup, but does not increase the rated maximum trailer weight.
What trailer weight is safe for a Chrysler Pacifica?
Following the 80/20 towing rule, operators should not exceed 80 percent of the manufacturer-rated towing capacity on a regular basis. For a Pacifica rated at 3,600 lbs, the practical safe trailer weight is 2,880 lbs under full passenger and cargo load. Total payload (passengers, cargo, tongue weight) must not exceed the vehicle’s rated payload capacity, typically around 1,400 lbs on minivan-generation models.
Do I need a weight-distributing hitch for a Chrysler Pacifica?
A weight-distributing hitch is not required for light trailer loads well below maximum capacity. For trailers approaching 3,600 lbs, tongue weight management becomes important to prevent rear-end sag and maintain front-axle steering response. The factory Class III hitch has specific limitations; verify compatibility with any weight-distribution system in the owner’s manual before installation.
Does the Chrysler Pacifica Hybrid have towing capacity?
The Pacifica Hybrid is not recommended for towing in model years 2017, 2018, and 2019 per Chrysler’s owner’s manuals. From 2020 onward, some Hybrid configurations carry a 1,500 lb to 3,600 lb towing rating depending on equipment, though Chrysler generally advises against heavy trailer use on Hybrid trims. Gas-powered models are the correct choice for any regular or near-maximum towing applications.
Conclusion
The Chrysler Pacifica towing capacity ranges from 3,500 lbs on first-generation crossover models (2004-2008) to 3,600 lbs on second-generation minivan models (2017-2026) when properly equipped. The factory Trailer Tow Group is required to reach the 3,600 lb maximum trailer weight on minivan-generation gas models; without it, the limit is 1,500 lbs. Engine configuration, drivetrain, and tow package selection are the primary factors that determine actual towing capacity for any given model year. The Hybrid powertrain carries significant towing restrictions and is not the recommended configuration for trailer use.
Always verify towing specifications in the vehicle’s owner’s manual before towing heavy loads.
