The Chrysler Voyager has been produced in multiple generations from 1984 to 2003 and was reintroduced in 2020 as a minivan variant based on the Chrysler Pacifica platform. This guide provides complete engine oil capacity, type, and viscosity specifications for all Chrysler Voyager model years. Using the correct oil specifications ensures proper engine lubrication, optimal performance, and extended engine life.
The current Voyager generation (2020-2024) features a 3.6L Pentastar V6 engine requiring full synthetic 0W-20 oil with a capacity of 5 quarts. Earlier generations (2001-2003) offered multiple engine options including 2.4L inline-4, 3.3L V6, and 3.8L V6 powertrains with varying oil requirements.
Quick Navigation
2024 Chrysler Voyager Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 |
| Oil Capacity (with Filter) | 5.0 qt (4.7 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.3 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar 68191349AA, Mopar 68191349AB, Mobil 1 M1-110A, K&N HP-1017 |
The 2024 Chrysler Voyager uses a 3.6L Pentastar V6 engine that requires 5.0 quarts of full synthetic oil with the filter. Using SAE 0W-20 viscosity oil provides optimal protection and fuel efficiency under normal driving conditions.
2023 Chrysler Voyager Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 |
| Oil Capacity (with Filter) | 5.0 qt (4.7 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.3 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar 68191349AA, Mopar 68191349AB, Mobil 1 M1-110A, K&N HP-1017 |
The 2023 Chrysler Voyager is equipped with a 3.6L V6 engine requiring 5.0 quarts of 0W-20 full synthetic motor oil including the filter. This viscosity ensures proper engine protection across all operating temperatures.
2022 Chrysler Voyager Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 |
| Oil Capacity (with Filter) | 5.0 qt (4.7 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.3 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar 68191349AA, Mopar 68191349AB, Mobil 1 M1-110A, K&N HP-1017 |
The 2022 Chrysler Voyager features the 3.6L Pentastar V6 with a 5.0 quart oil capacity when using a new filter. Full synthetic 0W-20 oil is the manufacturer-recommended specification for this model year.
2021 Chrysler Voyager Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 |
| Oil Capacity (with Filter) | 5.0 qt (4.7 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.3 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar 68191349AA, Mopar 68191349AB, Mobil 1 M1-110A, K&N HP-1017 |
The 2021 Chrysler Voyager uses the 3.6L V6 engine that holds 5.0 quarts of synthetic motor oil with the oil filter replacement. The 0W-20 viscosity rating provides excellent cold-start protection and high-temperature performance.
2020 Chrysler Voyager Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.6L Pentastar V6 |
| Oil Capacity (with Filter) | 5.0 qt (4.7 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.3 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 10,000 miles or 12 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar 68191349AA, Mopar 68191349AB, Mobil 1 M1-110A, K&N HP-1017 |
The 2020 Chrysler Voyager debuted with the 3.6L Pentastar V6 engine requiring 5.0 quarts of 0W-20 full synthetic oil. This was the first year of the reintroduced Voyager nameplate based on the Pacifica platform.
2003 Chrysler Voyager Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 2.4L I4 EDZ / 3.3L V6 EGA / 3.8L V6 EGH |
| Oil Capacity (with Filter) | 4.5 qt (4.3 L) for 2.4L; 5.0 qt (4.7 L) for 3.3L/3.8L |
| Oil Capacity (without Filter) | 4.0 qt (3.8 L) for 2.4L; 4.5 qt (4.3 L) for 3.3L/3.8L |
| Recommended Oil Type | Conventional or Synthetic Blend |
| Viscosity | SAE 5W-30, SAE 10W-30 |
| Oil Change Interval | Every 3,000-5,000 miles or 6 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-090, Fram PH3593A, Purolator L14459 |
The 2003 Chrysler Voyager offered three engine options with different oil capacities depending on the powerplant. The 2.4L inline-4 required approximately 4.5 quarts while the V6 engines needed 5.0 quarts with a new oil filter.
2002 Chrysler Voyager Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 2.4L I4 EDZ / 3.3L V6 EGA / 3.8L V6 EGH |
| Oil Capacity (with Filter) | 4.5 qt (4.3 L) for 2.4L; 5.0 qt (4.7 L) for 3.3L/3.8L |
| Oil Capacity (without Filter) | 4.0 qt (3.8 L) for 2.4L; 4.5 qt (4.3 L) for 3.3L/3.8L |
| Recommended Oil Type | Conventional or Synthetic Blend |
| Viscosity | SAE 5W-30, SAE 10W-30 |
| Oil Change Interval | Every 3,000-5,000 miles or 6 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-090, Fram PH3593A, Purolator L14459 |
The 2002 Chrysler Voyager featured the same three engine choices as other fourth-generation models. Oil capacity ranged from 4.5 to 5.0 quarts depending on whether the vehicle had the 2.4L four-cylinder or one of the V6 options.
2001 Chrysler Voyager Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 2.4L I4 EDZ / 3.3L V6 EGA / 3.8L V6 EGH |
| Oil Capacity (with Filter) | 4.5 qt (4.3 L) for 2.4L; 5.0 qt (4.7 L) for 3.3L/3.8L |
| Oil Capacity (without Filter) | 4.0 qt (3.8 L) for 2.4L; 4.5 qt (4.3 L) for 3.3L/3.8L |
| Recommended Oil Type | Conventional or Synthetic Blend |
| Viscosity | SAE 5W-30, SAE 10W-30 |
| Oil Change Interval | Every 3,000-5,000 miles or 6 months |
| Oil Drain Plug Torque | 20 lb-ft (27 N·m) |
| Recommended Filters | Mopar MO-090, Fram PH3593A, Purolator L14459 |
The 2001 Chrysler Voyager marked the beginning of the fourth generation with multiple engine configurations. The 2.4L engine used 4.5 quarts while the 3.3L and 3.8L V6 engines required 5.0 quarts of engine oil with filter replacement.
Oil Maintenance & Service Tips
Regular oil changes are essential for maintaining your Chrysler Voyager engine performance and longevity. Modern Voyager models (2020-2024) with synthetic oil can operate safely for 10,000 miles between oil changes under normal driving conditions. Earlier models with conventional or synthetic blend oil should follow a 3,000 to 5,000 mile interval.
Always check your oil level monthly using the dipstick when the engine is cold and on level ground. The oil should appear amber to light brown in color and maintain a level between the minimum and maximum marks on the dipstick. When performing an oil change, always replace the oil filter to ensure proper filtration and engine protection.
Severe driving conditions require more frequent oil changes, typically reducing the interval by 30 to 50 percent. Severe conditions include frequent short trips under 5 miles, extensive idling, towing or hauling heavy loads, dusty environments, and extreme hot or cold temperatures. Always use the manufacturer-specified oil viscosity for your specific model year and engine type.
The oil drain plug should be tightened to the proper torque specification of 20 lb-ft to prevent leaks or damage to the oil pan threads. When adding oil, pour slowly and check the level frequently to avoid overfilling, which can cause engine damage.
FAQs
What kind of oil does a Chrysler Voyager use?
Current Chrysler Voyager models (2020-2024) require SAE 0W-20 full synthetic motor oil for the 3.6L V6 engine. Older Voyager models (2001-2003) typically used SAE 5W-30 or 10W-30 conventional or synthetic blend oil depending on the engine configuration.
How much oil does a Chrysler Voyager take?
The 2020-2024 Chrysler Voyager with the 3.6L Pentastar V6 engine takes 5.0 quarts of oil with a new filter. Earlier generation Voyagers required 4.5 to 5.0 quarts depending on the engine, with the 2.4L four-cylinder using 4.5 quarts and the 3.3L or 3.8L V6 engines requiring 5.0 quarts.
What is the recommended oil type for a Chrysler Voyager?
Chrysler recommends full synthetic 0W-20 motor oil for all current Voyager models equipped with the 3.6L V6 engine. Synthetic oil provides superior lubrication, better high-temperature stability, and improved cold-start protection compared to conventional oils. Older Voyager models can use conventional or synthetic blend oils meeting API service requirements.
What is the oil change interval for a Chrysler Voyager?
The 2020-2024 Chrysler Voyager has an oil change interval of 10,000 miles or 12 months when using full synthetic oil under normal driving conditions. Older Voyager models (2001-2003) should have oil changes every 3,000 to 5,000 miles or 6 months. Severe driving conditions may require more frequent oil changes for all model years.
What oil filter does a Chrysler Voyager use?
Modern Chrysler Voyager models (2020-2024) use the Mopar 68191349AA or 68191349AB oil filter as the OEM specification. Aftermarket equivalents include Mobil 1 M1-110A, K&N HP-1017, and Fram CH10358 filters. Earlier generation Voyagers used different filter part numbers such as Mopar MO-090 depending on the engine type.
Can I use 5W-30 oil in my Chrysler Voyager?
Using 5W-30 oil in a current Voyager (2020-2024) is not recommended as the 3.6L Pentastar engine is designed specifically for 0W-20 viscosity. Using incorrect viscosity can reduce fuel economy and may affect engine performance. However, 5W-30 was an acceptable viscosity for older Voyager models (2001-2003) equipped with the 2.4L, 3.3L, or 3.8L engines.
Conclusion
Understanding the correct engine oil capacity, type, and viscosity for your specific Chrysler Voyager model year ensures optimal engine performance and protection. Current Voyager models require 5.0 quarts of 0W-20 full synthetic oil, while earlier generations used 4.5 to 5.0 quarts of 5W-30 or 10W-30 oil depending on the engine.
Always use manufacturer-approved oil specifications and high-quality oil filters to maintain proper engine lubrication. Following the recommended oil change intervals based on your driving conditions helps prevent engine wear and extends the life of your Chrysler Voyager. Regular maintenance and using the correct oil specifications are essential for reliable performance and engine longevity.
