The GMC Yukon is a full-size, body-on-frame SUV produced by General Motors under the GMC brand. The Yukon has been in continuous production since 1991, with the current fifth generation introduced for the 2021 model year. It is available in standard (116-inch wheelbase) and extended (Yukon XL, 130-inch wheelbase) body configurations with multiple powertrain options.
This guide covers GMC Yukon towing capacity by model year from 2000 through 2024, including maximum trailer weight, payload limits, tongue weight, gross combined weight rating (GCWR), and hitch requirements for each year. Specifications vary by engine, drivetrain, axle ratio, and factory-installed equipment packages.
Operating within manufacturer-rated towing limits protects the engine, transmission, braking system, and chassis components from accelerated wear and potential failure during towing operations.
Quick Navigation
2024 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 (L84, 355 hp / 383 lb-ft); 6.2L V8 (L87, 420 hp / 460 lb-ft); 3.0L Turbodiesel I-6 (LM2, 277 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD (3.23 axle ratio) |
| Maximum Towing Capacity | 8,400 lbs / 3,810 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg (5.3L V8, RWD, no NHT) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,792 lbs / 813 kg |
| Gross Combined Weight Rating (GCWR) | 14,500 lbs / 6,577 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (NHT Max Trailering Package) |
The 2024 GMC Yukon reaches a maximum towing capacity of 8,400 lbs when equipped with the 5.3L V8, rear-wheel drive, and the optional NHT Max Trailering Package. The NHT package adds an enhanced cooling radiator, the ProGrade Trailering system, and an integrated trailer brake controller. Staying within rated tongue weight and GCWR limits maintains braking performance and drivetrain integrity.
2023 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 (355 hp / 383 lb-ft); 6.2L V8 (420 hp / 460 lb-ft); 3.0L Turbodiesel I-6 (277 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,400 lbs / 3,810 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg (5.3L V8, RWD, no NHT) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,890 lbs / 857 kg |
| Gross Combined Weight Rating (GCWR) | 14,500 lbs / 6,577 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (NHT Max Trailering Package) |
The 2023 GMC Yukon achieves its 8,400 lb maximum towing rating with the 5.3L V8, rear-wheel drive, and the NHT Max Trailering Package. Models equipped with the 6.2L V8 top out at 8,200 lbs, while the 3.0L Duramax diesel reaches 8,100 lbs maximum. Proper tongue weight distribution at or below 1,050 lbs reduces trailer sway and improves steering response.
2022 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 (L84, 355 hp / 383 lb-ft); 6.2L V8 (L87, 420 hp / 460 lb-ft); 3.0L Turbodiesel I-6 (LM2, 277 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,400 lbs / 3,810 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg (5.3L V8, RWD, no NHT) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,792 lbs / 813 kg |
| Gross Combined Weight Rating (GCWR) | 14,500 lbs / 6,577 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (NHT Max Trailering Package) |
The 2022 GMC Yukon shares towing specifications with the 2023 and 2024 models, with a maximum trailer weight of 8,400 lbs using the 5.3L V8, rear-wheel drive, and NHT package. The lowest-rated 2022 configuration is the 6.2L V8 with four-wheel drive, rated at 7,500 lbs. Selecting the NHT Max Trailering Package adds approximately 500 lbs to the towing rating across most configurations.
2021 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 (355 hp / 383 lb-ft); 6.2L V8 (420 hp / 460 lb-ft); 3.0L Turbodiesel I-6 (277 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,200 lbs / 3,720 kg |
| Conventional Towing Capacity | 7,700 lbs / 3,493 kg (5.3L V8, RWD, no NHT) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,790 lbs / 812 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,025 lbs / 465 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional (NHT Max Trailering Package) |
The 2021 GMC Yukon marked the introduction of the fifth generation, bringing independent rear suspension, a new 3.0L Duramax diesel engine option, and an updated 10-speed automatic transmission for all powerplants. Maximum towing for this first model year of the fifth generation reached 8,200 lbs with the NHT package properly installed. The 3.0L diesel option provided strong low-end torque for sustained trailer towing on grades.
2020 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 (355 hp / 383 lb-ft); 6.2L V8 (420 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,400 lbs / 3,810 kg |
| Conventional Towing Capacity | 8,400 lbs / 3,810 kg (6.2L V8, RWD) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs / 771 kg |
| Gross Combined Weight Rating (GCWR) | 14,900 lbs / 6,759 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2020 GMC Yukon is the final model year of the fourth generation and achieves a maximum towing capacity of 8,400 lbs with the 6.2L V8 and rear-wheel drive. The 6.2L V8 four-wheel-drive configuration is rated at 8,100 lbs. Proper use of a trailer brake controller and weight-distributing hitch is required when approaching maximum trailer weight ratings.
2019 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 EcoTec3 (355 hp / 383 lb-ft); 6.2L V8 EcoTec3 (420 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,300 lbs / 3,765 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs / 771 kg |
| Gross Combined Weight Rating (GCWR) | 15,000 lbs / 6,803 kg |
| Tongue Weight Limit | 1,062 lbs / 482 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2019 GMC Yukon retains the same 5.3L and 6.2L V8 EcoTec3 engines and eight-speed automatic transmission carried over from the 2017 update. Rear-wheel-drive models with the factory tow package reach 8,500 lbs maximum trailer weight. Four-wheel-drive configurations are rated approximately 300 lbs lower than their rear-wheel-drive counterparts.
2018 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 EcoTec3 (355 hp / 383 lb-ft); 6.2L V8 EcoTec3 (420 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,300 lbs / 3,765 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs / 771 kg |
| Gross Combined Weight Rating (GCWR) | 15,000 lbs / 6,803 kg |
| Tongue Weight Limit | 1,062 lbs / 482 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2018 GMC Yukon continues the fourth-generation platform with the eight-speed automatic transmission introduced during the generation refresh. Maximum towing capacity reaches 8,500 lbs with the rear-wheel-drive configuration and a factory tow package installed. Payload capacity is approximately 1,700 lbs depending on trim level and installed options.
2017 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 EcoTec3 (355 hp / 383 lb-ft); 6.2L V8 EcoTec3 (420 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,300 lbs / 3,765 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs / 771 kg |
| Gross Combined Weight Rating (GCWR) | 15,000 lbs / 6,803 kg |
| Tongue Weight Limit | 1,062 lbs / 482 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2017 GMC Yukon carries the same maximum towing capacity of 8,500 lbs as the updated fourth-generation platform, with consistent powertrain ratings across this model year. The 6.2L V8 is available exclusively on Denali trim levels and offers higher low-speed torque output. Engine cylinder deactivation operates automatically and does not reduce maximum trailer weight ratings.
2016 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 EcoTec3 (355 hp / 383 lb-ft); 6.2L V8 EcoTec3 (420 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,200 lbs / 3,720 kg (5.3L V8, 4WD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,530 lbs / 694 kg |
| Gross Combined Weight Rating (GCWR) | 14,900 lbs / 6,759 kg |
| Tongue Weight Limit | 1,062 lbs / 482 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2016 GMC Yukon rear-drive configuration is rated at 8,500 lbs maximum trailer weight, while four-wheel-drive models reach 8,200 lbs. Denali trim models with the 6.2L V8 are rated at 8,400 lbs in rear-wheel drive. The Yukon XL in this year is rated slightly lower at 8,300 lbs rear-drive and 8,000 lbs four-wheel drive.
2015 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 5.3L V8 EcoTec3 (355 hp / 383 lb-ft); 6.2L V8 EcoTec3 (420 hp / 460 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,300 lbs / 3,765 kg (SLT 4WD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,715 lbs / 778 kg |
| Gross Combined Weight Rating (GCWR) | 14,900 lbs / 6,759 kg |
| Tongue Weight Limit | 1,062 lbs / 482 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2015 GMC Yukon represents the first model year of the fourth generation, featuring an all-new EcoTec3 engine family with direct injection and cylinder deactivation. Maximum towing capacity with a properly equipped rear-wheel-drive model reaches 8,500 lbs. The fourth-generation redesign also introduced updated chassis tuning that improved towing stability compared to the outgoing model.
2014 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (295 hp / 305 lb-ft); 5.3L V8 (320 hp / 340 lb-ft); 6.2L V8 (Denali, 403 hp / 417 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,200 lbs / 3,720 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs / 680 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,062 lbs / 482 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2014 GMC Yukon is the final model year of the third generation and retains the 5.3L V8 as the primary towing engine with a maximum trailer weight of 8,500 lbs in rear-wheel-drive form. Denali models use the 6.2L V8 with a six-speed automatic and are rated slightly lower due to additional vehicle weight. The 4.8L V8 base engine was available in limited trims and provides a lower towing rating than the 5.3L option.
2013 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (295 hp / 305 lb-ft); 5.3L V8 (320 hp / 340 lb-ft); 6.2L V8 (Denali, 403 hp / 417 lb-ft) |
| Drivetrain | RWD / 4WD / AWD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,200 lbs / 3,720 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs / 680 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,062 lbs / 482 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2013 GMC Yukon maintains the third-generation platform with a maximum towing capacity of 8,500 lbs using the 5.3L V8, rear-wheel drive, and the factory tow package. All-wheel-drive models provide slightly reduced trailer weight ratings compared to two-wheel-drive configurations. Transmission cooler inclusion through the tow package is essential when towing near maximum capacity in high-temperature conditions.
2012 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (295 hp / 305 lb-ft); 5.3L V8 (320 hp / 340 lb-ft); 6.2L V8 (Denali, 403 hp / 417 lb-ft) |
| Drivetrain | RWD / 4WD / AWD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,000 lbs / 3,629 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs / 680 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,000 lbs / 454 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2012 GMC Yukon delivers a maximum trailer weight of 8,500 lbs in rear-wheel-drive configuration with the factory tow package installed. Weight-distributing hitch systems should be used when trailer weight exceeds 5,500 lbs per manufacturer guidelines. The six-speed automatic transmission in third-generation Yukons provides closer gear spacing for better engine load management during towing.
2011 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (295 hp / 305 lb-ft); 5.3L V8 (320 hp / 340 lb-ft); 6.2L V8 (Denali, 403 hp / 417 lb-ft) |
| Drivetrain | RWD / 4WD / AWD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,000 lbs / 3,629 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs / 680 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,000 lbs / 454 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2011 GMC Yukon continues the third-generation specifications with a maximum towing capacity of 8,500 lbs in the highest-rated configuration. The 5.3L V8 with flex-fuel capability was available and does not change the trailer weight ratings. Trailer sway control functions through the standard stability control system on all trim levels.
2010 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (295 hp / 305 lb-ft); 5.3L V8 (320 hp / 340 lb-ft); 6.2L V8 (Denali, 403 hp / 417 lb-ft) |
| Drivetrain | RWD / 4WD / AWD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,000 lbs / 3,629 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,490 lbs / 676 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,000 lbs / 454 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2010 GMC Yukon delivers a maximum towing capacity of 8,500 lbs with the 5.3L V8 and rear-wheel drive in a properly equipped configuration. The 6.2L V8 Denali configuration produces more total output but carries a slightly lower trailer weight limit because of the higher base vehicle weight. Recommended tongue weight remains between 10 and 15 percent of total trailer weight for all configurations.
2009 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (295 hp / 305 lb-ft); 5.3L V8 (315 hp / 335 lb-ft); 6.2L V8 (Denali, 403 hp / 417 lb-ft) |
| Drivetrain | RWD / 4WD / AWD |
| Maximum Towing Capacity | 8,400 lbs / 3,810 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,470 lbs / 667 kg |
| Gross Combined Weight Rating (GCWR) | 14,000 lbs / 6,350 kg |
| Tongue Weight Limit | 1,000 lbs / 454 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2009 GMC Yukon introduced the 6.2L V8 to the Denali lineup and continued with the 5.3L V8 as the standard towing engine for SLE and SLT trims. Maximum towing capacity for the 5.3L V8 rear-wheel-drive configuration reaches 8,400 lbs with the factory tow package. The 4.8L base engine is best suited for lighter trailer loads below 6,000 lbs.
2008 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (295 hp / 305 lb-ft); 5.3L V8 (315 hp / 335 lb-ft); 6.0L V8 (Denali, 367 hp / 375 lb-ft) |
| Drivetrain | RWD / 4WD / AWD |
| Maximum Towing Capacity | 7,900 lbs / 3,583 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,465 lbs / 665 kg |
| Gross Combined Weight Rating (GCWR) | 13,800 lbs / 6,259 kg |
| Tongue Weight Limit | 988 lbs / 448 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2008 GMC Yukon carries a maximum towing capacity of 7,900 lbs across available drivetrain configurations. The standard 5.3L V8 paired with the six-speed automatic transmission provides adequate reserve power for sustained uphill towing. Maximum payload is rated at 1,465 lbs and must be factored into total vehicle loading when calculating available trailer weight.
2007 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (295 hp / 305 lb-ft); 5.3L V8 (315 hp / 335 lb-ft); 6.0L V8 (Denali, 367 hp / 375 lb-ft) |
| Drivetrain | RWD / 4WD / AWD |
| Maximum Towing Capacity | 7,900 lbs / 3,583 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,465 lbs / 665 kg |
| Gross Combined Weight Rating (GCWR) | 13,800 lbs / 6,259 kg |
| Tongue Weight Limit | 988 lbs / 448 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2007 GMC Yukon marks the first year of the third generation with a six-speed automatic transmission standard on all configurations. Maximum towing capacity is rated at 7,900 lbs for the AWD configuration. The third-generation platform introduced new front independent suspension and an updated frame, which impacted the towing ratings relative to the second generation.
2006 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (275 hp / 295 lb-ft); 5.3L V8 (295 hp / 330 lb-ft); 6.0L V8 (Denali, 325 hp / 365 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 8,000 lbs / 3,629 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs / 771 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2006 GMC Yukon is the final model year of the second generation and retains towing capacity of up to 8,500 lbs in optimal configuration. The 4.8L V8 base engine produces adequate power for moderate towing but is best limited to trailers below 6,000 lbs for adequate reserve capacity. The four-speed automatic transmission in this generation requires a transmission oil temperature monitor when towing at or near maximum capacity.
2005 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (275 hp / 295 lb-ft); 5.3L V8 (295 hp / 330 lb-ft); 6.0L V8 (Denali, 325 hp / 365 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs / 771 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2005 GMC Yukon continues the second-generation specifications with a maximum towing capacity of 8,500 lbs in the highest-rated configuration. The 6.0L V8 in Denali models provides higher total output but does not add to the maximum trailer weight rating due to vehicle weight considerations. Operating the four-speed automatic near maximum load for extended periods requires a transmission cooler to prevent fluid degradation.
2004 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (275 hp / 295 lb-ft); 5.3L V8 (295 hp / 330 lb-ft); 6.0L V8 (Denali, 325 hp / 365 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs / 771 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2004 GMC Yukon maintains second-generation towing specifications consistent with the 2003 model. Maximum towing capacity of 8,500 lbs applies to the 5.3L V8 in rear-wheel drive with a factory tow package. Trailer brake controllers were not factory-integrated in this generation and required aftermarket installation for trailers with electric brakes.
2003 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (275 hp / 295 lb-ft); 5.3L V8 (295 hp / 330 lb-ft); 6.0L V8 (Denali, 325 hp / 365 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,500 lbs / 3,856 kg |
| Conventional Towing Capacity | 7,900 lbs / 3,583 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs / 771 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2003 GMC Yukon continues the second-generation towing ratings with a maximum trailer weight of 8,500 lbs for the best-equipped configuration. The Denali trim level with the 6.0L V8 was available and provides increased low-speed torque that benefits trailer control on grades. Rear-wheel-drive models consistently achieve higher trailer weight ratings than four-wheel-drive configurations in this generation.
2002 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (275 hp / 295 lb-ft); 5.3L V8 (285-295 hp / 325-330 lb-ft); 6.0L V8 (Denali, 325 hp / 365 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,600 lbs / 3,901 kg |
| Conventional Towing Capacity | 8,000 lbs / 3,629 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,720 lbs / 780 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,050 lbs / 476 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2002 GMC Yukon shares the second-generation platform with towing capacity reaching up to 8,600 lbs for rear-wheel-drive configurations with the 5.3L V8 and factory tow package. The 4.8L V8 base engine is rated for lighter loads and provides less reserve power than the 5.3L when towing on grades. Proper tire inflation and load-rated tires are required to maintain rated towing capacity.
2001 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (270 hp / 285 lb-ft); 5.3L V8 (285 hp / 325 lb-ft); 6.0L V8 (Denali, 325 hp / 365 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,700 lbs / 3,946 kg |
| Conventional Towing Capacity | 8,100 lbs / 3,674 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,730 lbs / 785 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,087 lbs / 493 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2001 GMC Yukon continues the second-generation platform introduced in 2000, with towing capacity reaching up to 8,700 lbs in the highest-rated rear-wheel-drive configuration. The 5.3L V8 replaced the older 5.7L as the primary towing engine and delivered improved output with lower fuel consumption. A factory tow package providing a transmission cooler and heavy-duty hitch receiver is required to achieve maximum ratings.
2000 GMC Yukon Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.8L V8 (270 hp / 285 lb-ft); 5.3L V8 (285 hp / 325 lb-ft) |
| Drivetrain | RWD / 4WD |
| Maximum Towing Capacity | 8,800 lbs / 3,992 kg |
| Conventional Towing Capacity | 8,200 lbs / 3,720 kg (5.3L V8, RWD, with tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,751 lbs / 795 kg |
| Gross Combined Weight Rating (GCWR) | 14,200 lbs / 6,441 kg |
| Tongue Weight Limit | 1,100 lbs / 499 kg |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2000 GMC Yukon marked the second-generation launch with a maximum towing capacity of 8,800 lbs using the 5.3L V8 in rear-wheel drive with a factory tow package. The 4.8L V8 provides adequate output for moderate towing but is not recommended for trailer loads approaching the maximum weight limit. Payload is rated at up to 1,751 lbs, which must be subtracted from the GCWR before determining the available trailer weight.
Towing Equipment and Setup
Tow Package
The factory tow package on the GMC Yukon adds critical hardware that enables the maximum trailer weight ratings. Without the package, towing capacity is reduced by up to 500 lbs depending on model year and configuration. The package typically includes a heavy-duty transmission cooler, integrated trailer brake controller (fifth-generation models), an enhanced radiator, and wiring harness.
Trailer Brake Controller
A trailer brake controller is required by most state regulations for trailers exceeding 3,000 lbs gross weight. Fifth-generation Yukon models (2021-2024) include an integrated trailer brake controller as part of the NHT Max Trailering Package. Earlier model years require an aftermarket unit mounted to the vehicle’s brake circuit.
Weight-Distributing Hitch
A weight-distributing hitch transfers tongue load from the rear axle to the front axle and trailer axle. This setup is recommended when tongue weight exceeds 10 to 15 percent of the tow vehicle’s rear axle rating. Using a weight-distributing hitch improves steering precision and reduces front axle lift during towing.
Transmission Cooler
Extended towing cycles at high trailer weights generate significant heat in the automatic transmission. The factory tow package on most Yukon model years includes an auxiliary transmission cooler for this purpose. Towing without an adequate cooler in high-temperature or mountainous conditions can shorten transmission service life.
Trailer Sway Control
Trailer sway control on the GMC Yukon operates through the integrated electronic stability control system. This feature applies selective braking to individual wheels when the system detects lateral oscillation of the trailer. Proper weight distribution and tongue weight within rated limits reduce the frequency of sway control activation.
Tire Load Ratings
Tires must be rated to support both the vehicle’s GVWR and the tongue weight load applied to the hitch. Factory tire specifications listed in the vehicle door placard reflect the maximum safe load for the vehicle’s rated payload. Replacing tires with a lower load rating than factory specification reduces the rated payload and towing capacity.
Normal Towing vs. Heavy Towing Setup
| Setup Element | Normal Towing (under 5,000 lbs) | Heavy Towing (over 5,000 lbs) |
|---|---|---|
| Hitch Type | Class III ball mount | Class IV weight-distributing hitch |
| Trailer Brakes | Not required in most jurisdictions | Required; integrated or aftermarket controller |
| Transmission Cooler | Factory cooler sufficient | Auxiliary cooler recommended |
| Tire Pressure | Standard recommended pressure | Maximum door placard pressure |
| Sway Control | Electronic stability system | Electronic sway control plus friction bar |
| Tow Package | Recommended | Required for maximum capacity ratings |
Frequently Asked Questions
What is the maximum towing capacity of a GMC Yukon?
The maximum towing capacity of the GMC Yukon is 8,800 lbs, achieved by early second-generation models from 2000 and 2001 in rear-wheel-drive form. Fifth-generation Yukons (2021-2024) reach a maximum of 8,400 lbs with the 5.3L V8, rear-wheel drive, and NHT Max Trailering Package. Fourth-generation models (2015-2020) with the 5.3L or 6.2L V8 in rear-wheel drive top out at 8,500 lbs.
How much can a GMC Yukon tow with a tow package?
The factory tow package increases maximum towing capacity by approximately 300 to 500 lbs over the base-equipped rating depending on model year. For the 2023-2024 Yukon with the 5.3L V8 and rear-wheel drive, the tow package raises the maximum from 7,900 lbs to 8,400 lbs. The NHT Max Trailering Package also adds a ProGrade trailering system with camera and monitoring features on fifth-generation models.
Does 4WD affect GMC Yukon towing capacity?
Four-wheel drive reduces the GMC Yukon’s maximum towing capacity by approximately 200 to 400 lbs compared to rear-wheel-drive configurations in the same model year. This reduction results from additional drivetrain component weight and transfer case heat management considerations. For example, the 2024 Yukon with 5.3L V8 and NHT is rated at 8,400 lbs in rear-wheel drive and 8,200 lbs in four-wheel drive.
What trailer weight is safe for a GMC Yukon?
The safe trailer weight for a GMC Yukon is any load at or below the manufacturer’s maximum trailer weight rating for the specific configuration. Real-world towing should account for loaded trailer weight, not dry weight, including fuel, water, gear, and occupants in the tow vehicle. Keeping the combined vehicle and trailer weight below the published GCWR is mandatory for safe operation.
Do I need a weight-distributing hitch for a GMC Yukon?
A weight-distributing hitch is recommended when towing trailers with tongue weight above 500 lbs or total trailer weight above 5,000 lbs. The GMC Yukon uses a Class IV receiver hitch on most model years and can physically accept a weight-distributing system without modification. Using a weight-distributing hitch within manufacturer-rated tongue weight limits improves handling, reduces rear squat, and extends rear suspension component life.
Is the 5.3L or 6.2L V8 better for towing a GMC Yukon?
The 5.3L V8 achieves a higher maximum trailer weight rating than the 6.2L V8 in the same Yukon configuration due to differences in axle loading and vehicle weight. For example, the 2024 Yukon with the 5.3L V8, RWD, and NHT package is rated at 8,400 lbs, while the 6.2L V8 equivalent is rated at 8,200 lbs. The 6.2L V8 offers higher total output and may be preferable for sustained high-speed towing, but does not add to the maximum trailer weight limit.
Conclusion
The GMC Yukon towing capacity ranges from 7,900 lbs in base third-generation configurations to 8,800 lbs in early second-generation rear-wheel-drive models. Fifth-generation Yukons (2021-2024) are rated at a maximum of 8,400 lbs with the 5.3L V8, rear-wheel drive, and NHT Max Trailering Package, making engine selection, drivetrain, and optional equipment the primary variables in determining the trailer weight limit. The factory tow package is consistently required across all model years to reach the manufacturer’s published maximum rating, as it supplies the necessary transmission cooling, hitch hardware, and wiring.
Payload capacity reduces the available towing reserve and must be calculated as part of total vehicle load before connecting a trailer. Using the owner’s manual and the vehicle’s specific tire and loading information label is the only reliable method for confirming maximum trailer weight for a given configuration.
