The Hyundai Palisade is a three-row midsize SUV produced by Hyundai Motor Company beginning with the 2020 model year. The Palisade is available in front-wheel drive and all-wheel drive configurations with a single V6 engine across the 2020 through 2025 model years. For 2026, Hyundai introduced a revised 3.5L V6 and the first-ever Palisade Hybrid alongside the updated ICE powertrain.
This guide covers year-by-year Hyundai Palisade towing specifications, including maximum trailer weight, payload capacity, tongue weight limits, and hitch class by configuration. Towing capacity varies by engine type, drivetrain, and installed equipment packages.
Quick Navigation
2026 Hyundai Palisade Towing Capacity
The 2026 model year marks a significant powertrain update for the Palisade lineup. Hyundai replaced the 3.8L V6 with a revised 3.5L V6 for standard ICE models and introduced the first-ever Palisade Hybrid. The two powertrains carry different maximum towing ratings.
2026 Hyundai Palisade V6 Specifications
| Specification | Detail |
|---|---|
| Engine Options | 3.5L Lambda II Atkinson Cycle GDI D-CVVT V6 (287 hp / 260 lb-ft) |
| Drivetrain | FWD (standard) / HTRAC AWD (optional) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with trailer brakes |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,500 lbs (680 kg); verify in owner’s manual |
| Gross Combined Weight Rating (GCWR) | Verify in owner’s manual |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard (Trailer Prep Package, integrated hitch, Tow Mode) |
2026 Hyundai Palisade Hybrid Specifications
| Specification | Detail |
|---|---|
| Engine Options | 2.5L Turbocharged GDI 4-cylinder Hybrid (329 system hp / 339 lb-ft) |
| Drivetrain | HTRAC AWD (standard) |
| Maximum Towing Capacity | 4,000 lbs (1,814 kg) with trailer brakes |
| Conventional Towing Capacity | 4,000 lbs (1,814 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Verify in owner’s manual |
| Gross Combined Weight Rating (GCWR) | Verify in owner’s manual |
| Tongue Weight Limit | 400 lbs (181 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard (integrated hitch, Tow Mode) |
The 2026 Hyundai Palisade V6 offers a maximum towing capacity of 5,000 lbs (2,268 kg) when equipped with a trailer brake controller. The Palisade Hybrid achieves a 4,000 lb (1,814 kg) maximum trailer weight rating with standard HTRAC AWD. Both powertrains include an available integrated tow hitch and standard Tow Mode for optimized trailer operations.
2025 Hyundai Palisade Towing Capacity
The 2025 Palisade retains the 3.8L Lambda II V6 as its sole powertrain option. Towing specifications carry over unchanged from the 2024 model year. The Trailer Prep Package remains standard on all trim levels, including SE, SEL, XRT Pro, Limited, and Calligraphy.
| Specification | Detail |
|---|---|
| Engine Options | 3.8L Lambda II Atkinson Cycle GDI D-CVVT V6 (287 hp / 260 lb-ft) |
| Drivetrain | FWD (standard) / HTRAC AWD (optional) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with trailer brakes |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,500 lbs (680 kg); verify in owner’s manual |
| Gross Combined Weight Rating (GCWR) | Verify in owner’s manual |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard (Trailer Prep Package, heavy-duty transmission oil cooler) |
The 2025 Hyundai Palisade delivers a maximum towing capacity of 5,000 lbs (2,268 kg) when properly equipped with trailer brakes. The HTRAC AWD system includes a dedicated Tow Mode that holds lower gears longer to improve towing stability on grades. Trailer sway control is standard on every 2025 trim level.
2024 Hyundai Palisade Towing Capacity
The 2024 Palisade carries over the same powertrain and towing specifications from the 2023 refreshed model. No changes were made to the towing system, hitch class, or trailer weight rating for this model year. All trim levels share the same 5,000 lb maximum towing limit.
| Specification | Detail |
|---|---|
| Engine Options | 3.8L Lambda II Atkinson Cycle GDI D-CVVT V6 (287 hp / 260 lb-ft) |
| Drivetrain | FWD (standard) / HTRAC AWD (optional) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with trailer brakes |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,500 lbs (680 kg); verify in owner’s manual |
| Gross Combined Weight Rating (GCWR) | Verify in owner’s manual |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard (Trailer Prep Package) |
The 2024 Hyundai Palisade maintains a maximum towing capacity of 5,000 lbs (2,268 kg) across all trim levels, from SE to Calligraphy. AWD-equipped models include Tow Mode to optimize transmission shift points during trailer operations. Conventional towing without trailer brakes is limited to 1,650 lbs (748 kg) on all configurations.
2023 Hyundai Palisade Towing Capacity
The 2023 model year introduced a mid-cycle refresh to the Palisade exterior and interior design. The powertrain and towing specifications remained unchanged from the pre-refresh model. The official Hyundai product specification sheet confirms the 5,000 lb maximum trailer weight continues for 2023.
| Specification | Detail |
|---|---|
| Engine Options | 3.8L Lambda II Atkinson Cycle GDI D-CVVT V6 (291 hp / 262 lb-ft) |
| Drivetrain | FWD (standard) / HTRAC AWD (optional) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with trailer brakes |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,500 lbs (680 kg) FWD; approx. 1,484 lbs (673 kg) AWD |
| Gross Combined Weight Rating (GCWR) | GVWR: 5,732 lbs FWD / 5,871 lbs AWD; verify GCWR in owner’s manual |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard (Trailer Prep Package) |
The 2023 Hyundai Palisade towing capacity reaches 5,000 lbs (2,268 kg) with trailer brakes, consistent with prior model years. The GVWR is officially rated at 5,732 lbs for FWD models and 5,871 lbs for AWD models per the Hyundai product specification sheet. Trailer sway control and pre-wired hitch connections are standard across all 2023 trim configurations.
2022 Hyundai Palisade Towing Capacity
The 2022 Palisade carries over the same drivetrain and towing specifications from 2021. No modifications were made to the towing system or engine configuration. A pre-wired tow hitch and heavy-duty transmission oil cooler remain standard across all trim levels.
| Specification | Detail |
|---|---|
| Engine Options | 3.8L Lambda II Atkinson Cycle GDI D-CVVT V6 (291 hp / 262 lb-ft) |
| Drivetrain | FWD (standard) / HTRAC AWD (optional) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with trailer brakes |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,500 lbs (680 kg) FWD; approx. 1,484 lbs (673 kg) AWD |
| Gross Combined Weight Rating (GCWR) | GVWR: 5,732 lbs FWD / 5,871 lbs AWD; verify GCWR in owner’s manual |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard (pre-wired hitch, heavy-duty transmission oil cooler) |
The 2022 Hyundai Palisade towing capacity is rated at 5,000 lbs (2,268 kg) when the heavy-duty transmission oil cooler and pre-wired tow hitch are installed. Maximum towing without trailer brakes is limited to 1,650 lbs (748 kg) for all configurations. The optional HTRAC AWD system improves stability when towing on grades or uneven terrain.
2021 Hyundai Palisade Towing Capacity
The 2021 model year added the Calligraphy trim level to the Palisade lineup. Towing specifications remained unchanged across all trim levels. The official 2021 product specification sheet confirms a 5,000 lb maximum trailer weight and a 1,650 lb limit without trailer brakes.
| Specification | Detail |
|---|---|
| Engine Options | 3.8L Lambda II Atkinson Cycle GDI D-CVVT V6 (291 hp / 262 lb-ft) |
| Drivetrain | FWD (standard) / HTRAC AWD (optional) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with trailer brakes |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,501 lbs (681 kg) FWD 7-seat; approx. 1,605 lbs (728 kg) FWD 8-seat |
| Gross Combined Weight Rating (GCWR) | GVWR: 5,732 lbs FWD / 5,871 lbs AWD; verify GCWR in owner’s manual |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard (Trailer Prep Package) |
The 2021 Hyundai Palisade towing capacity is rated at 5,000 lbs (2,268 kg) when properly equipped with trailer brakes. GVWR is 5,732 lbs for FWD models and 5,871 lbs for AWD models per the official 2021 specification sheet. The 7-seat and 8-seat configurations have slightly different curb weights, which affects available payload capacity.
2020 Hyundai Palisade Towing Capacity
The 2020 Palisade is the first model year of this nameplate. It launched with the 3.8L Lambda II V6 as the sole engine option, paired with an 8-speed automatic transmission. All 2020 trim levels share the same 5,000 lb maximum trailer weight rating.
| Specification | Detail |
|---|---|
| Engine Options | 3.8L Lambda II Atkinson Cycle GDI D-CVVT V6 (291 hp / 262 lb-ft) |
| Drivetrain | FWD (standard) / HTRAC AWD (optional) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with trailer brakes |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,501 lbs (681 kg) FWD 7-seat; approx. 1,605 lbs (728 kg) FWD 8-seat |
| Gross Combined Weight Rating (GCWR) | GVWR: 5,732 lbs FWD / 5,871 lbs AWD; verify GCWR in owner’s manual |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard (Trailer Prep Package) |
The 2020 Hyundai Palisade established its 5,000 lb (2,268 kg) maximum towing capacity from the first production year with trailer brakes installed. GVWR ratings of 5,732 lbs for FWD and 5,871 lbs for AWD apply to all 2020 configurations. Trailer sway control and pre-wired hitch connections are included across all trim levels from this initial model year.
Towing Equipment and Setup
Selecting the correct towing equipment is critical for safety and drivetrain reliability. The following considerations apply to all Hyundai Palisade model years.
Tow Package
The Hyundai Palisade includes a standard Trailer Prep Package across all trim levels and all model years. This package includes pre-wired hitch connections and a heavy-duty transmission oil cooler. Owners should confirm the Trailer Prep Package is active before exceeding 1,650 lbs of trailer weight.
Trailer Brake Controller
Trailer brakes are required to achieve the maximum 5,000 lb towing capacity rating on all Palisade V6 models from 2020 through 2026. Without trailer brakes, the rated limit drops to 1,650 lbs (748 kg) on all configurations. A proportional trailer brake controller is recommended for trailers approaching the maximum towing capacity.
Weight-Distributing Hitch
The Hyundai Palisade is a unibody-construction vehicle and is not rated for a fifth-wheel or gooseneck configuration. Standard Class III ball hitch connections are the rated hitch type for all model years. Owners should verify weight distribution hitch compatibility with the owner’s manual before adding aftermarket components.
Transmission Cooler
A heavy-duty transmission oil cooler is standard on the Palisade across all model years. This component helps manage transmission temperatures during extended towing, particularly on grades or in high ambient temperatures. Proper fluid levels should be confirmed before any towing operation.
Tire Load Ratings
Tire load ratings must be confirmed before towing at or near maximum trailer weight capacity. Underinflated or improperly rated tires reduce braking performance and increase the risk of tire failure under load. Tire pressure should be checked before every towing trip.
Trailer Sway Control
Trailer sway control is standard on all Hyundai Palisade trim levels and all model years. This system applies individual wheel braking to reduce trailer oscillation during towing operations. It functions automatically and does not require driver activation.
Normal Towing vs. Heavy Towing Setup
| Factor | Normal Towing (Under 3,500 lbs) | Heavy Towing (3,500 to 5,000 lbs) |
|---|---|---|
| Trailer Brake Controller | Not required | Required |
| Tow Mode | Recommended | Required for AWD models |
| Tongue Weight Range | 200-300 lbs (91-136 kg) | 400-500 lbs (181-227 kg) |
| Transmission Cooler | Standard equipment sufficient | Standard equipment sufficient |
| Tire Pressure Check | Before each trip | Before each trip |
| Trailer Sway Control | Active (standard) | Active (standard) |
FAQs
What is the maximum towing capacity of a Hyundai Palisade?
The maximum Hyundai Palisade towing capacity is 5,000 lbs (2,268 kg) for V6 models across all years from 2020 through 2026. This rating requires properly installed trailer brakes and the factory Trailer Prep Package. The 2026 Palisade Hybrid carries a lower maximum trailer weight of 4,000 lbs (1,814 kg).
How much can a Hyundai Palisade tow with a tow package?
With the factory Trailer Prep Package and trailer brake controller, the Palisade V6 can tow up to 5,000 lbs (2,268 kg). Without trailer brakes, the rated towing limit drops to 1,650 lbs (748 kg) on all configurations. The Trailer Prep Package is standard, not optional, across all model years.
Does AWD affect Hyundai Palisade towing capacity?
The maximum trailer weight rating of 5,000 lbs applies equally to both FWD and AWD Palisade V6 models. HTRAC AWD models include a dedicated Tow Mode that optimizes transmission shift points during trailer operations. GVWR is slightly higher for AWD models at 5,871 lbs compared to 5,732 lbs for FWD models.
What trailer weight is safe for a Hyundai Palisade?
Staying at or below the rated 5,000 lb maximum trailer weight is required for safety and mechanical protection. Tongue weight should not exceed 10 percent of total trailer weight, or approximately 500 lbs (227 kg) at maximum capacity. Exceeding either limit can stress the hitch, transmission, and braking systems.
Do I need a weight-distributing hitch for a Hyundai Palisade?
The Hyundai Palisade is not rated for a weight-distributing hitch system based on standard manufacturer specifications. A Class III ball hitch is the standard and recommended connection type for all Palisade model years. Owners should consult the owner’s manual before adding any aftermarket hitch configuration.
Does the 2026 Hyundai Palisade Hybrid have a lower towing capacity?
The 2026 Palisade Hybrid is rated at 4,000 lbs (1,814 kg) maximum towing capacity, compared to 5,000 lbs (2,268 kg) for the V6. The hybrid system uses a 2.5L turbocharged 4-cylinder engine and integrated electric motor producing 329 system horsepower. HTRAC AWD is standard on all Palisade Hybrid configurations.
Conclusion
The Hyundai Palisade has maintained a consistent maximum towing capacity of 5,000 lbs (2,268 kg) from its 2020 introduction through the 2026 V6 model. The 2026 model year introduced a hybrid powertrain alternative rated at 4,000 lbs (1,814 kg), the only deviation from the standard 5,000 lb limit across the production run. Towing capacity is identical across all trim levels for a given engine configuration and model year.
The factory Trailer Prep Package, including a pre-wired hitch and heavy-duty transmission oil cooler, is standard on all configurations regardless of trim level. Trailer brake installation is required to reach the maximum rated towing capacity on all V6 model years. Payload limits and GCWR values vary by drivetrain configuration and seating arrangement.
