The Jeep Cherokee is a compact SUV produced by Jeep across multiple generations, spanning from 1984 to 2001 as the XJ and reintroduced in 2014 as the KL generation, which ran through 2023. The Cherokee nameplate returned again for 2026. Towing capacity varies considerably depending on model year, engine choice, drivetrain, and factory-installed equipment packages.
This guide provides year-by-year towing specifications for the Jeep Cherokee, including maximum trailer weight, tongue weight limits, payload capacity, and hitch class requirements by configuration. Following manufacturer-rated towing limits is required to protect the transmission, engine cooling system, and braking components from overload.
Quick Navigation
2026 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 1.3L Turbocharged I4 Plug-In Hybrid (PHEV) |
| Drivetrain | 4WD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,100 lbs (499 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,000 lbs (4,082 kg) |
| Tongue Weight Limit | 350 lbs (159 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2026 Jeep Cherokee is a reintroduced model featuring a plug-in hybrid electric powertrain rated at 38 combined miles per gallon. Maximum towing capacity for the 2026 model is rated at 3,500 lbs when properly equipped with the factory tow package. Staying within this limit maintains braking balance between the tow vehicle and trailer.
2023 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 2.0L Turbocharged I4 (270 hp, 295 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,000 lbs (1,814 kg) with 2.0L Turbo + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,000 lbs (1,814 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,250 lbs (567 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,500 lbs (4,309 kg) |
| Tongue Weight Limit | 400 lbs (181 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (2.0L Turbo w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2023 Jeep Cherokee is the final model year of the KL generation and is available with two engine options. The 2.0L turbocharged four-cylinder paired with the factory tow package delivers a maximum towing capacity of 4,000 lbs. The 3.2L V6 engine was discontinued for the 2023 model year; maximum towing capacity for the base 2.4L I4 configuration is 2,000 lbs.
2022 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft); 2.0L Turbocharged I4 (270 hp, 295 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 4,000 lbs (1,814 kg) with 2.0L Turbo + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,250 lbs (567 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 / 2.0T w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2022 Jeep Cherokee offers three engine options, with the 3.2L V6 providing the highest towing capacity at 4,500 lbs when paired with the factory tow package. Models equipped with the 2.0L turbocharged four-cylinder and tow package are rated at 4,000 lbs maximum trailer weight. The GVWR for the 2022 Cherokee is 5,500 lbs across all configurations.
2021 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft); 2.0L Turbocharged I4 (270 hp, 295 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 4,000 lbs (1,814 kg) with 2.0L Turbo + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,250 lbs (567 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 / 2.0T w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2021 Jeep Cherokee shares its powertrain lineup with the 2022 model, offering the 3.2L V6 as the highest-rated towing configuration at 4,500 lbs. The 2.0L turbocharged engine is rated at 4,000 lbs maximum towing capacity, which is 500 lbs lower than the V6 configuration. Curb weight for the 2021 Cherokee is approximately 4,250 lbs.
2020 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft); 2.0L Turbocharged I4 (270 hp, 295 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 4,000 lbs (1,814 kg) with 2.0L Turbo + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,250 lbs (567 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 / 2.0T w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2020 Jeep Cherokee maintains the same three-engine lineup introduced in the 2019 model year following the powertrain refresh. The 3.2L V6 engine with factory tow package produces the highest towing specification at 4,500 lbs (2,041 kg). GVWR remains at 5,500 lbs across all 2020 Cherokee configurations.
2019 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft); 2.0L Turbocharged I4 (270 hp, 295 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 4,000 lbs (1,814 kg) with 2.0L Turbo + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,250 lbs (567 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 / 2.0T w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2019 Jeep Cherokee received a powertrain update that introduced the 2.0L turbocharged four-cylinder engine as a third option alongside the existing 2.4L I4 and 3.2L V6. The 2.0L Turbo with tow package is rated at 4,000 lbs maximum towing capacity. GVWR is 5,500 lbs with a curb weight of approximately 4,250 lbs.
2018 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,275 lbs (578 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2018 Jeep Cherokee is available with two engine choices: the base 2.4L I4 and the optional 3.2L V6. The 3.2L V6 with tow package provides a maximum towing capacity of 4,500 lbs, while the base engine is limited to 2,000 lbs. Curb weight for the 2018 Cherokee is approximately 4,046 lbs depending on trim and drivetrain.
2017 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,275 lbs (578 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2017 Jeep Cherokee carries over the same powertrain specifications from 2016, with the 3.2L V6 delivering the highest towing rating in the KL lineup at 4,500 lbs when properly equipped. The base 2.4L I4 configuration carries a 2,000 lb trailer weight limit regardless of drivetrain selection. GVWR is 5,500 lbs across the 2017 Cherokee range.
2016 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,300 lbs (590 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2016 Jeep Cherokee maintains the same two-engine structure as earlier KL production years. Maximum towing capacity for a properly equipped 3.2L V6 model with factory tow package is 4,500 lbs (2,041 kg). The curb weight of the 2016 Cherokee is approximately 4,028 lbs.
2015 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,300 lbs (590 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2015 Jeep Cherokee is the second model year of the KL platform and shares towing specifications with the 2014 launch model. The 3.2L V6 with tow package delivers maximum towing of 4,500 lbs. GVWR is rated at 5,500 lbs with a curb weight of approximately 4,106 lbs.
2014 Jeep Cherokee Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I4 (180 hp, 171 lb-ft); 3.2L V6 (271 hp, 239 lb-ft) |
| Drivetrain | FWD / 4WD |
| Maximum Towing Capacity | 4,500 lbs (2,041 kg) with 3.2L V6 + Tow Package; 2,000 lbs (907 kg) with 2.4L I4 |
| Conventional Towing Capacity | 4,500 lbs (2,041 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,300 lbs (590 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 450 lbs (204 kg) max config; 200 lbs (91 kg) base config |
| Hitch Class | Class III (V6 w/ Tow Package); Class II (2.4L I4) |
| Factory Tow Package | Optional |
The 2014 Jeep Cherokee marked the reintroduction of the Cherokee nameplate in the United States after a 13-year absence, using the new KL unibody platform. Maximum towing capacity for the first KL year is 4,500 lbs with the 3.2L V6 and factory tow package, and 2,000 lbs for the standard 2.4L I4. GVWR is 5,500 lbs across all 2014 Cherokee configurations.
2001 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto; 1,000 lbs (454 kg) with 2.5L I4 Manual |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,514 lbs (687 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 2001 Jeep Cherokee XJ is the final year of the original XJ generation, available with the 4.0L inline-six or 2.5L four-cylinder engine. A properly equipped 4.0L I6 with automatic transmission and factory tow package achieves a maximum towing capacity of 5,000 lbs (2,268 kg). GVWR for the 2001 XJ is rated at 4,900 lbs.
2000 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,514 lbs (687 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 2000 Jeep Cherokee XJ shares its towing specifications with the final years of the XJ production run. The 4.0L I6 with automatic transmission and tow package allows a maximum trailer weight of 5,000 lbs. GVWR is 4,900 lbs and curb weight is approximately 3,386 lbs.
1999 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,720 lbs (780 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1999 Jeep Cherokee XJ is one of the lighter XJ years, with a curb weight of approximately 3,181 lbs and a GVWR of 4,901 lbs. Maximum towing capacity with the 4.0L I6, automatic transmission, and factory tow package is 5,000 lbs. The 2.5L I4 engine is limited to 2,000 lbs with automatic transmission.
1998 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1998 Jeep Cherokee XJ carries identical powertrain and towing specifications to the 1997-2001 late-XJ configuration. The 4.0L I6 with automatic transmission and tow package remains the only configuration rated for 5,000 lbs of trailer weight. Without a tow package, the same engine and transmission combination drops to 3,500 lbs maximum.
1997 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1997 Jeep Cherokee XJ received minor interior updates while retaining the same drivetrain and towing specifications as the rest of the late XJ production run. Towing specifications are unchanged: 5,000 lbs maximum with a properly equipped 4.0L I6 automatic with tow package. The 2.5L I4 with manual transmission is limited to 1,000 lbs.
1996 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1996 Jeep Cherokee XJ continues with the same engine and towing configuration established in earlier XJ production years. A 4.0L I6 automatic with factory tow package remains the configuration required for the 5,000 lb maximum towing rating. GVWR is 4,900 lbs across the 1996 XJ range.
1995 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1995 Jeep Cherokee XJ maintains unchanged towing specifications from the mid-production XJ years. Maximum towing capacity reaches 5,000 lbs with the 4.0L I6 automatic and factory tow package. Without the tow package, the same engine and transmission combination is limited to 3,500 lbs maximum trailer weight.
1994 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1994 Jeep Cherokee XJ retains the same engine options and maximum towing ratings in place since the 4.0L I6 introduction. Towing limits are consistent: 5,000 lbs maximum with 4.0L I6 automatic and tow package, 3,500 lbs without tow package, and 2,000 lbs for the 2.5L I4 automatic. GVWR is 4,900 lbs with a tongue weight limit of 500 lbs at maximum capacity.
1993 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1993 Jeep Cherokee XJ uses the same powertrain and towing configuration as the surrounding production years. Towing with the 4.0L I6, automatic transmission, and tow package reaches 5,000 lbs maximum. Transmission selection is a critical factor in determining towing limits for all XJ model years, with manual-equipped models rated significantly lower.
1992 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1992 Jeep Cherokee XJ maintains consistent towing specifications throughout this period of XJ production. The 4.0L I6 with automatic transmission and tow package remains the only configuration rated for 5,000 lbs of trailer weight. Without a tow package, the same engine and transmission combination drops to 3,500 lbs maximum.
1991 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (123 hp, 139 lb-ft); 4.0L I6 (190 hp, 235 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1991 Jeep Cherokee XJ retains the same engine options and maximum towing ratings in place since the 4.0L I6 fuel-injected engine introduction. Towing specifications are unchanged: 5,000 lbs maximum with 4.0L I6 automatic and tow package, 3,500 lbs without tow package, and 2,000 lbs for the 2.5L I4 automatic. Transmission cooler inclusion in the tow package directly enables the higher rating.
1990 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (121 hp, 141 lb-ft); 4.0L I6 (177 hp, 224 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1990 Jeep Cherokee XJ is part of the stable mid-generation XJ production period with consistent towing limits. Maximum towing capacity of 5,000 lbs applies to 4.0L I6 automatic models with the factory tow package installed. All XJ tow packages include a transmission oil cooler, which is required to support the higher trailer weight ratings.
1989 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (117 hp, 135 lb-ft); 4.0L I6 (177 hp, 224 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1989 Jeep Cherokee XJ maintains the towing capacity structure established after the 4.0L I6 engine introduction in 1987. Maximum towing with a fully equipped 4.0L I6 automatic is 5,000 lbs; unequipped I6 automatic models are rated at 3,500 lbs. The 2.5L I4 manual transmission configuration is the most limited, rated at just 1,000 lbs.
1988 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (117 hp, 135 lb-ft); 4.0L I6 (177 hp, 224 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1988 Jeep Cherokee XJ uses the same powertrain choices introduced in 1987, and towing ratings carry over unchanged. The 4.0L I6 became the dominant towing configuration across the XJ lineup from 1987 onward. Proper tow package fitment is required to unlock the 5,000 lb maximum capacity on any XJ model.
1987 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (117 hp, 135 lb-ft); 4.0L I6 (177 hp, 224 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with 4.0L I6 Auto + Tow Package; 3,500 lbs (1,588 kg) with 4.0L I6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,700 lbs (771 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 9,900 lbs (4,491 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) max config |
| Hitch Class | Class III (4.0L I6 w/ Tow Package); Class II (base configs) |
| Factory Tow Package | Optional |
The 1987 Jeep Cherokee XJ is the first model year to offer the 4.0L I6 engine, replacing the 2.8L V6 as the performance option. This powertrain introduction directly increased the available maximum towing capacity to 5,000 lbs for properly equipped models. The 2.5L I4 returned as the base engine with unchanged towing limits from prior years.
1986 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (105 hp, 132 lb-ft); 2.8L V6 (112 hp, 150 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) with 2.8L V6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto; 1,000 lbs (454 kg) with 2.5L I4 Manual |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,600 lbs (726 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 8,400 lbs (3,810 kg) |
| Tongue Weight Limit | 350 lbs (159 kg) max config |
| Hitch Class | Class II |
| Factory Tow Package | Optional |
The 1986 Jeep Cherokee XJ uses the early-generation engine pairing of the 2.5L I4 and 2.8L V6, which was phased out after this model year. The 2.8L V6 with automatic transmission provides the highest towing rating for this year at 3,500 lbs (1,588 kg). The 4.0L I6 and its higher 5,000 lb towing limit were not yet available for the 1986 model year.
1985 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (105 hp, 132 lb-ft); 2.8L V6 (112 hp, 150 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) with 2.8L V6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,600 lbs (726 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 8,400 lbs (3,810 kg) |
| Tongue Weight Limit | 350 lbs (159 kg) max config |
| Hitch Class | Class II |
| Factory Tow Package | Optional |
The 1985 Jeep Cherokee XJ is the second model year of the XJ platform and maintains the same powertrain and towing specifications as the 1984 launch model. Maximum towing capacity is 3,500 lbs with the 2.8L V6 and automatic transmission. The 4.0L I6 was not yet available for this model year.
1984 Jeep Cherokee Towing Capacity (XJ)
| Specification | Detail |
|---|---|
| Engine Options | 2.5L I4 (105 hp, 132 lb-ft); 2.8L V6 (112 hp, 150 lb-ft) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) with 2.8L V6 Auto; 2,000 lbs (907 kg) with 2.5L I4 Auto |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) max |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Est. 1,600 lbs (726 kg) |
| Gross Combined Weight Rating (GCWR) | Est. 8,400 lbs (3,810 kg) |
| Tongue Weight Limit | 350 lbs (159 kg) max config |
| Hitch Class | Class II |
| Factory Tow Package | Optional |
The 1984 Jeep Cherokee XJ is the first model year of the XJ generation and established the compact Cherokee platform used through 2001. The 2.8L V6 with automatic transmission provides the maximum towing capacity of 3,500 lbs for this inaugural year. The stronger 4.0L inline-six engine that later defined XJ towing capability was not introduced until the 1987 model year.
Towing Equipment and Setup
Selecting the correct towing equipment is as important as knowing the rated limits. Operating at or near maximum trailer weight without proper equipment increases braking distance, reduces steering control, and accelerates drivetrain wear.
Factory Tow Package
The factory tow package for the Jeep Cherokee typically includes a wiring harness, receiver hitch, and transmission cooler. On the KL generation, the tow package is required to achieve the upper towing limits with both the 3.2L V6 and 2.0L turbocharged engine. On the XJ, the tow package includes a transmission oil cooler that is directly responsible for the jump from 3,500 lbs to 5,000 lbs maximum capacity.
Trailer Brake Controller
A trailer brake controller is required on trailers over a certain weight threshold, which varies by state or country. For any trailer load above 3,000 lbs, an electric brake controller is strongly recommended to supplement the tow vehicle’s braking system. The Cherokee’s compact crossover braking system is not designed to decelerate combined loads near the GCWR limit without trailer brake assistance.
Weight-Distributing Hitch
A weight-distributing hitch is used when tongue weight exceeds the rear axle’s load tolerance. For KL Cherokee models towing near 4,000-4,500 lbs, tongue weight can reach 400-450 lbs, which shifts weight to the rear axle and reduces front axle load. A weight-distributing hitch redistributes that load more evenly across both axles, improving steering response and braking control.
Transmission Cooler
The factory tow package on both the XJ and KL generations includes a transmission oil cooler. Towing without an adequately cooled transmission leads to fluid degradation and eventual transmission failure. This is especially relevant on the XJ, where the 4.0L I6 maximum towing rating of 5,000 lbs depends entirely on the presence of the factory cooler.
Tire Load Ratings
Trailer towing increases the load on rear tires. Tires must be rated for the combined vehicle weight at the rear axle under maximum load conditions. Using tires below the vehicle’s load index rating while towing near maximum capacity is a safety risk and may void the manufacturer’s towing warranty.
Trailer Sway Control
Trailer sway becomes a risk when trailer weight exceeds 50 percent of tow vehicle weight. For the KL Cherokee with a curb weight near 4,200 lbs, a trailer above 2,100 lbs begins to require sway management equipment or electronic trailer sway correction. Several KL Cherokee trims include electronic stability control that provides basic sway mitigation.
Normal vs. Heavy Towing Setup
| Component | Normal Towing (Under 2,000 lbs) | Heavy Towing (2,000-4,500 lbs) |
|---|---|---|
| Hitch Class | Class II | Class III |
| Trailer Brake Controller | Not required | Recommended / Required |
| Weight-Distributing Hitch | Not required | Recommended above 3,500 lbs |
| Transmission Cooler | Standard cooling sufficient | Factory tow package required |
| Sway Control | Not required | Recommended above 2,500 lbs |
| Tire Inflation Check | Before each trip | Before each trip |
Frequently Asked Questions
What is the maximum towing capacity of a Jeep Cherokee?
The maximum towing capacity for the Jeep Cherokee varies by generation and configuration. The KL generation (2014-2022) reaches a maximum of 4,500 lbs with the 3.2L V6 engine and factory tow package. The XJ generation (1987-2001) reaches a maximum of 5,000 lbs with the 4.0L I6 automatic transmission and factory tow package.
How much can a Jeep Cherokee tow with a tow package?
With the factory tow package installed, towing capacity increases significantly over base configurations. On the KL Cherokee, the tow package enables the 3.2L V6 to reach 4,500 lbs and the 2.0L Turbo to reach 4,000 lbs. On the XJ, the tow package raises capacity from 3,500 lbs to 5,000 lbs for 4.0L I6 automatic models.
Does 4WD affect Jeep Cherokee towing capacity?
Drivetrain selection affects towing capacity on the XJ generation, where 4WD configurations support higher towing ratings than 2WD. On the KL Cherokee, both FWD and 4WD configurations are available with similar tow ratings depending on engine and equipment selection. Always consult the specific model year owner’s manual to confirm towing capacity for the exact drivetrain and engine combination in the vehicle.
What trailer weight is safe for a Jeep Cherokee?
Operating at 80 percent of the rated maximum towing capacity provides a margin for real-world variables including load distribution, terrain, heat, and driver experience. For a KL Cherokee rated at 4,500 lbs, a practical working load of 3,600 lbs reduces stress on the engine, transmission, and braking system. For a 2,000 lb rated base engine Cherokee, a trailer load of up to 1,600 lbs is a conservative and appropriate target.
Do I need a weight-distributing hitch for a Jeep Cherokee?
A weight-distributing hitch is not required for lighter trailers but is recommended when tongue weight exceeds 10-15 percent of the tow vehicle’s curb weight. For a KL Cherokee towing near 4,000-4,500 lbs, tongue weight can reach 400-450 lbs, which stresses the rear suspension and reduces front axle steering input. A weight-distributing hitch restores axle load balance and improves towing stability at those higher weights.
What hitch class does the Jeep Cherokee use?
KL Cherokee models equipped with the factory tow package use a Class III hitch receiver with a 2-inch square receiver tube. Base engine configurations without a tow package are typically rated for Class II use. XJ models with the 4.0L I6 and tow package also use a Class III hitch rated for 5,000 lbs gross trailer weight.
Conclusion
The Jeep Cherokee towing capacity ranges from 1,000 lbs at the lowest-rated XJ configuration to 5,000 lbs at the peak XJ specification and 4,500 lbs for the best-equipped KL generation models. Engine selection, transmission type, drivetrain, and factory tow package are all direct factors in determining the correct towing limit for any specific Cherokee configuration. The 3.2L V6 in the KL generation and the 4.0L I6 in the XJ generation represent the highest towing capacities within their respective platforms. The 2026 Cherokee reintroduction with a hybrid powertrain is rated at 3,500 lbs, which reflects the constraints of its PHEV drivetrain architecture. Always verify specifications using the owner’s manual or manufacturer specification sheet before connecting a trailer, as individual vehicle equipment and trim variations affect the final rated towing limit.
