The Jeep Compass is a compact crossover SUV produced by Jeep since 2007. It spans two generations and is available in front-wheel drive (FWD) and four-wheel drive (4WD) configurations with multiple engine and transmission options across its production run through 2026.
This guide covers Jeep Compass towing capacity by model year from 2007 through 2026, including maximum trailer weight ratings, payload estimates, hitch class requirements, and tow package details for every production year. Operating within manufacturer-rated towing limits protects the engine, transmission, brake system, and chassis components from premature stress or failure.
Quick Navigation
2026 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (200 hp / 221 lb-ft) |
| Drivetrain | 4×4 |
| Maximum Towing Capacity | 2,000 lbs / 907 kg |
| Conventional Towing Capacity | 2,000 lbs / 907 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Consult owner’s manual |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer-Tow Group) |
The 2026 Jeep Compass offers a maximum towing capacity of 2,000 lbs when equipped with the available Trailer-Tow Group. Power comes from a 2.0-liter turbocharged four-cylinder engine delivering 200 horsepower and 221 lb-ft of torque paired with an 8-speed automatic transmission. Trailer sway damping is included as part of the tow package to improve stability under load.
2025 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (200 hp / 221 lb-ft) |
| Drivetrain | 4×4 |
| Maximum Towing Capacity | 2,000 lbs / 907 kg |
| Conventional Towing Capacity | 2,000 lbs / 907 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Consult owner’s manual |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer-Tow Group) |
The 2025 Jeep Compass carries a maximum towing capacity of 2,000 lbs with the available tow package installed. The powertrain consists of a 2.0L turbocharged I-4 engine, 8-speed automatic transmission, and standard 4×4 drivetrain. Tongue weight must not exceed 200 lbs when operating at the maximum rated trailer weight.
2024 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (200 hp / 221 lb-ft) |
| Drivetrain | 4×4 |
| Maximum Towing Capacity | 2,000 lbs / 907 kg |
| Conventional Towing Capacity | 2,000 lbs / 907 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Consult owner’s manual |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2024 Jeep Compass introduced a redesigned turbocharged powertrain, replacing the previous 2.4L naturally aspirated engine. Maximum towing capacity remains at 2,000 lbs when properly equipped, consistent with prior model years. The 8-speed automatic transmission and 4×4 drivetrain are standard across all 2024 trim levels.
2023 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (177 hp / 172 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg |
| Conventional Towing Capacity | 2,000 lbs / 907 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,100 lbs / 499 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,750 lbs / 3,062 kg |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2023 Jeep Compass achieves a maximum towing capacity of 2,000 lbs across all trim levels, including Sport, Latitude, Altitude, Latitude Lux, Limited, Trailhawk, (RED), and High Altitude. All trims use the 2.4L I-4 engine rated at 177 horsepower and 172 lb-ft of torque. Tongue weight must not exceed 200 lbs regardless of trim configuration.
2022 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (177 hp / 172 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg |
| Conventional Towing Capacity | 2,000 lbs / 907 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,117 lbs / 507 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,750 lbs / 3,062 kg |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2022 Jeep Compass supports a maximum trailer weight of 2,000 lbs when equipped with a properly rated hitch. The GVWR for the 2022 model is 4,750 lbs, with a curb weight of 3,633 lbs, yielding an estimated payload capacity of approximately 1,117 lbs. All trim levels share the same 2,000 lb towing limit for this model year.
2021 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (180 hp / 175 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (9-speed automatic only) |
| Conventional Towing Capacity | 2,000 lbs / 907 kg (9-speed automatic only) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,067 lbs / 484 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,700 lbs / 3,039 kg |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2021 Jeep Compass can tow up to 2,000 lbs only when equipped with the 9-speed automatic transmission. Models fitted with the 6-speed automatic transmission are not rated for towing by the manufacturer. The GVWR is 4,700 lbs with a curb weight of 3,633 lbs, producing an estimated payload capacity of 1,067 lbs.
2020 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (180 hp / 175 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (9-speed auto or 4WD manual) |
| Conventional Towing Capacity | 2,000 lbs / 907 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,067 lbs / 484 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,700 lbs / 3,039 kg |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2020 Jeep Compass towing capacity depends on both transmission and drivetrain configuration. The 9-speed automatic in any drivetrain and the manual transmission in 4WD configuration both support a 2,000 lb trailer weight limit. The 6-speed automatic and FWD manual configurations are not rated for towing by the manufacturer in this model year.
2019 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (180 hp / 175 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (9-speed automatic only) |
| Conventional Towing Capacity | 2,000 lbs / 907 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,067 lbs / 484 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,700 lbs / 3,039 kg |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2019 Jeep Compass achieves its maximum trailer weight rating of 2,000 lbs exclusively with the 9-speed automatic transmission. Both the 6-speed automatic and manual transmission configurations are not rated for towing by Jeep for this model year. The 2.4L engine produces 180 horsepower and 175 lb-ft of torque across all 2019 trims.
2018 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (180 hp / 175 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (9-speed automatic only) |
| Conventional Towing Capacity | 2,000 lbs / 907 kg |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Consult owner’s manual |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs / 91 kg |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2018 Jeep Compass launched the second generation and adopted a new 9-speed automatic transmission as the key enabler for towing. The 2,000 lb maximum towing capacity is available only with the 9-speed automatic, while the 6-speed automatic and manual transmission versions are not rated for towing. The second-generation Compass standardized on the 2.4L I-4 engine, dropping the 2.0L option offered in prior years.
2017 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (180 hp / 170 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,230 lbs / 558 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package or Freedom Drive II Off Road Package) |
The 2017 Jeep Compass towing capacity ranges from 1,000 lbs to 2,000 lbs depending on engine and tow package selection. Models with the 2.4L engine and either the Trailer Tow Prep Package or the Freedom Drive II Off Road Package achieve the 2,000 lb maximum. The 2.0L engine is limited to 1,000 lbs regardless of optional equipment.
2016 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,230 lbs / 558 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package or Freedom Drive II Off Road Package) |
The 2016 Jeep Compass reaches 2,000 lbs maximum towing capacity only with the 2.4L engine and an applicable tow package installed. Without the Trailer Tow Prep Package or Freedom Drive II Off Road Package, the trailer weight limit drops to 1,000 lbs. The 2.0L engine configuration is capped at 1,000 lbs in all equipment configurations for this year.
2015 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,230 lbs / 558 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package or Freedom Drive II Off Road Package) |
The 2015 Jeep Compass towing capacity follows the same engine-and-package structure as other first-generation models. The 2.4L engine with the Trailer Tow Prep Package or Freedom Drive II Off Road Package is required to reach the 2,000 lb maximum. The GVWR of 4,575 lbs applies to all 2015 Compass configurations.
2014 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,230 lbs / 558 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package or Freedom Drive II Off Road Package) |
The 2014 Jeep Compass requires the Trailer Tow Prep Package or Freedom Drive II Off Road Package on 2.4L models to achieve the 2,000 lb trailer weight limit. The standard 2.4L configuration without these packages achieves only 1,000 lbs. Both engine options share the same GVWR of 4,575 lbs for this model year.
2013 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,250 lbs / 567 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2013 Jeep Compass maximum towing capacity of 2,000 lbs requires the 2.4L engine combined with the Trailer Tow Prep Package. Without the package, the 2.4L engine is limited to 1,000 lbs. The 2.0L engine is not rated above 1,000 lbs in any 2013 configuration.
2012 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,250 lbs / 567 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2012 Jeep Compass retains the same towing specifications as the surrounding 2011 and 2013 model years. The Trailer Tow Prep Package is required for the 2.4L engine to reach 2,000 lbs, while the 2.0L engine remains at 1,000 lbs in all configurations. The GVWR of 4,575 lbs and curb weight of approximately 3,325 lbs apply to both engine options.
2011 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,250 lbs / 567 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2011 Jeep Compass towing capacity follows the same engine-and-package dependency as other first-generation models. The 2.4L engine paired with the Trailer Tow Prep Package delivers the 2,000 lb maximum trailer weight rating. Curb weight for the 2011 model is approximately 3,325 lbs with a GVWR of 4,575 lbs.
2010 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,246 lbs / 565 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2010 Jeep Compass maintains the same towing structure as surrounding model years in the first generation. The 2.4L engine with the Trailer Tow Prep Package is required for the 2,000 lb rating; without the package, the limit drops to 1,000 lbs. The curb weight is approximately 3,329 lbs against a GVWR of 4,575 lbs.
2009 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (2.4L engine with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (2.4L without package or 2.0L engine) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,246 lbs / 565 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional (Trailer Tow Prep Package) |
The 2009 Jeep Compass towing capacity is determined by engine selection and tow package installation. Selecting the 2.4L engine and the Trailer Tow Prep Package is required to achieve the 2,000 lb maximum towing capacity. The 2.0L engine in any configuration is limited to 1,000 lbs, consistent with all first-generation Compass models.
2008 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,246 lbs / 565 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,575 lbs / 2,982 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2008 Jeep Compass requires an installed tow package to reach its maximum trailer weight limit of 2,000 lbs. Without the tow package, all 2008 Compass configurations are rated for 1,000 lbs. The curb weight of 3,329 lbs and GVWR of 4,575 lbs result in an estimated payload capacity of approximately 1,246 lbs.
2007 Jeep Compass Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L I-4 (172 hp / 165 lb-ft); 2.0L I-4 (158 hp / 141 lb-ft) |
| Drivetrain | FWD or 4WD |
| Maximum Towing Capacity | 2,000 lbs / 907 kg (with tow package) |
| Conventional Towing Capacity | 1,000 lbs / 454 kg (without tow package) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,212 lbs / 550 kg |
| Gross Combined Weight Rating (GCWR) | Approx. 6,435 lbs / 2,919 kg |
| Tongue Weight Limit | 200 lbs / 91 kg (with package); 100 lbs / 45 kg (without) |
| Hitch Class | Class II / Class III |
| Factory Tow Package | Optional |
The 2007 Jeep Compass was the first model year, featuring a lower GVWR of 4,435 lbs compared to later first-generation models. Maximum towing capacity of 2,000 lbs is achievable with the tow package installed, while all configurations without the package are limited to 1,000 lbs. The curb weight of 3,223 lbs for the 2007 model is lower than all subsequent first-generation years.
Towing Equipment and Setup Tips
Proper towing setup is required to achieve and safely operate within the Jeep Compass maximum towing capacity of 2,000 lbs. The vehicle’s towing rating assumes all factory-specified components are correctly installed and functional. Using non-rated equipment or exceeding tongue weight limits can compromise braking distance and towing stability.
Tow Package
The Jeep Compass does not include a factory-installed hitch receiver on base configurations. A Trailer Tow Prep Package, Trailer-Tow Group, or Freedom Drive II Off Road Package may be required depending on the model year to unlock the 2,000 lb trailer weight rating. For model years 2007 through 2017, the presence or absence of the tow package directly determines the maximum rated towing capacity.
Trailer Brake Controller
A trailer brake controller activates the trailer’s electric brakes in proportion to vehicle deceleration. For any trailer equipped with electric brakes, a compatible controller is required by law in most jurisdictions and reduces stopping distance under load. This also reduces heat buildup in the Jeep Compass braking system during trailer towing.
Weight-Distributing Hitch
The Jeep Compass is rated for conventional trailer towing only. A weight-distributing hitch is generally not required at the Compass’s 2,000 lb towing limit, but careful attention to tongue weight distribution improves handling near the maximum rated capacity. Tongue weight must remain at or below 200 lbs in all properly equipped Compass towing configurations.
Transmission Cooler
Towing places additional thermal load on the automatic transmission, particularly during sustained grades or operation in high ambient temperatures. For model years 2018 through 2023, the 9-speed automatic is both required for towing and the most susceptible to heat buildup under sustained towing loads. Some Compass tow packages include an auxiliary transmission cooler as part of the tow prep equipment.
Tire Load Ratings
Tires must carry the combined weight of the vehicle, all occupants, cargo, and tongue weight transferred from the trailer. The tire placard on the driver door jamb lists the maximum load rating per tire and the correct inflation pressure for loaded operation. Under-inflated tires under towing loads increase heat buildup and reduce handling stability.
Trailer Sway Control
Trailer sway damping is included with the tow package on Compass models from 2018 onward and on select earlier configurations. This system automatically adjusts engine output and applies selective individual wheel braking to counteract trailer sway. It functions only within the manufacturer’s rated towing limits and does not enable towing beyond the specified maximum trailer weight.
Normal Towing vs. Heavy Towing Setup
| Component | Normal Towing (Under 1,000 lbs) | Heavy Towing (1,000-2,000 lbs) |
|---|---|---|
| Hitch Class | Class II (1-1/4-inch receiver) | Class III (2-inch receiver) |
| Trailer Brakes | Not required | Recommended above 1,500 lbs |
| Transmission Cooler | Typically not required | Recommended |
| Sway Control | Not required | Recommended |
| Weight Distribution | Not required | Monitor tongue weight closely |
| Tow Package | Optional | Required for full 2,000 lb rating |
Frequently Asked Questions
What is the maximum towing capacity of a Jeep Compass?
The maximum towing capacity of the Jeep Compass is 2,000 lbs / 907 kg when properly equipped. This figure applies to equipped models across all production years from 2007 through 2026, though the required equipment varies by model year. Without the applicable tow package, many model years are limited to 1,000 lbs.
How much can a Jeep Compass tow with a tow package?
A Jeep Compass equipped with the applicable tow package can tow up to 2,000 lbs / 907 kg. For model years 2007 through 2017, the Trailer Tow Prep Package or Freedom Drive II Off Road Package is required on 2.4L models to reach this limit. For model years 2018 through 2023, both the tow package and the 9-speed automatic transmission are required.
Does 4WD affect Jeep Compass towing capacity?
For most model years, 4WD does not increase the maximum towing capacity beyond 2,000 lbs. However, for the 2020 model year specifically, 4WD is required when using a manual transmission to achieve a 2,000 lb tow rating. FWD models with a manual transmission in 2020 are not rated for towing by the manufacturer.
What trailer weight is safe for a Jeep Compass?
The manufacturer-rated maximum of 2,000 lbs is the upper legal limit for the Jeep Compass. Operating at or below 80 percent of rated capacity, approximately 1,600 lbs, reduces drivetrain stress during sustained or uphill towing. Tongue weight must remain at or below 200 lbs in all properly equipped towing configurations to maintain stability.
Do I need a weight-distributing hitch for a Jeep Compass?
A weight-distributing hitch is not required for towing with the Jeep Compass given its 2,000 lb maximum trailer weight limit. Weight-distributing systems are typically recommended for trailers exceeding 5,000 lbs, which is well beyond the Compass’s rated capacity. A standard ball mount compatible with a Class II or Class III receiver is sufficient for all Compass towing applications.
What hitch class does the Jeep Compass use?
The Jeep Compass uses a Class II or Class III frame-mounted trailer hitch depending on the aftermarket receiver selected. A Class III hitch with a 2-inch receiver is rated for up to 4,000 to 6,000 lbs gross trailer weight, providing a margin above the Compass’s 2,000 lb limit. The Compass does not support bumper towing and requires a frame-mounted receiver hitch for all towing applications.
Conclusion
The Jeep Compass towing capacity ranges from 1,000 lbs to 2,000 lbs across all model years from 2007 to 2026, with the maximum trailer weight of 2,000 lbs dependent on engine selection, transmission type, and factory tow package installation. No Jeep Compass model year has ever been rated above 2,000 lbs for conventional trailer towing.
First-generation models from 2007 through 2017 require the 2.4L engine combined with the Trailer Tow Prep Package or Freedom Drive II Off Road Package to reach 2,000 lbs, while the 2.0L engine is limited to 1,000 lbs in all configurations. Second-generation models from 2018 through 2023 require the 9-speed automatic transmission, and the 6-speed automatic is not rated for any towing use by the manufacturer. Third-generation models from 2024 onward pair a 2.0L turbocharged I-4 with a standard 4×4 drivetrain and 8-speed automatic to maintain the 2,000 lb maximum.
Engine configuration and transmission selection have the greatest impact on Jeep Compass towing capacity across all generations. Always verify specifications in the owner’s manual for the specific model year before towing any load.
