The Kia Carnival is a full-size multi-purpose vehicle produced by Kia since 1999, spanning four generations across global markets. In North America, the Carnival nameplate replaced the Kia Sedona designation beginning with the 2022 model year; prior to that, the same platform was sold as the Sedona from 2002 through 2021. This guide covers towing capacity by model year and configuration, including maximum trailer weight, payload limits, tongue weight, and hitch requirements for each production year.
Towing capacity on the Kia Carnival is determined by the engine configuration, drivetrain, and factory equipment. Following manufacturer-rated limits protects the engine, transmission, and braking systems from overload and reduces the risk of trailer instability at highway speeds.
Quick Navigation
2026 Kia Carnival Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (288 hp, 260 lb-ft); 1.6L Turbocharged Hybrid (242 combined hp, 270 combined lb-ft) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) – V6; 3,000 lbs (1,361 kg) – HEV |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) – V6; 3,000 lbs (1,361 kg) – HEV |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,299 lbs (589 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,710 lbs (2,590 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 9,210 lbs (4,178 kg) – V6 |
| Tongue Weight Limit | 350 lbs (159 kg) |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional |
The 2026 Kia Carnival offers a maximum towing capacity of 3,500 lbs (1,588 kg) with the 3.5L V6 engine when properly equipped. The 2026 Carnival HEV, powered by the 1.6L turbocharged hybrid system, carries a reduced towing rating of 3,000 lbs (1,361 kg). Tongue weight on both variants must be maintained within rated limits to preserve vehicle stability and rear axle load distribution.
2025 Kia Carnival Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (290 hp, 262 lb-ft) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,299 lbs (589 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,710 lbs (2,590 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 9,210 lbs (4,178 kg) |
| Tongue Weight Limit | 350 lbs (159 kg) |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional |
The 2025 Kia Carnival is rated for a maximum towing capacity of 3,500 lbs (1,588 kg) across all trim levels, as the vehicle uses a single 3.5L V6 engine. The engine produces 290 horsepower and 262 lb-ft of torque, delivered through an 8-speed automatic transmission. Third-party Class III hitches for the 2025 Carnival are rated up to 4,000 lbs gross trailer weight; however, the vehicle manufacturer’s rating of 3,500 lbs governs, and that lower limit must be observed.
2024 Kia Carnival Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (290 hp, 262 lb-ft) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,299 lbs (589 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,710 lbs (2,590 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 9,210 lbs (4,178 kg) |
| Tongue Weight Limit | 350 lbs (159 kg) |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional |
The 2024 Kia Carnival maintains the same 3,500 lbs (1,588 kg) maximum towing capacity as the prior model years in the fourth generation. A tongue weight limit of 350 lbs (159 kg) applies for both dead-weight and weight-distributing hitch configurations. The maximum tongue weight applies equally regardless of whether a standard ball mount or a weight-distributing setup is used.
2023 Kia Carnival Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (290 hp, 262 lb-ft) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,299 lbs (589 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,710 lbs (2,590 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 9,210 lbs (4,178 kg) |
| Tongue Weight Limit | 350 lbs (159 kg) |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional |
The 2023 Kia Carnival carries a maximum towing capacity of 3,500 lbs (1,588 kg) and a maximum payload of 1,299 lbs (589 kg). Curb weight for the 2023 model is 4,411 lbs (2,001 kg), and the GVWR is 5,710 lbs (2,590 kg). The 2022-2023 Carnival tow hitch harness was subject to a Kia recall due to a potential electrical short; owners of those model years should verify the remedy status before towing.
2022 Kia Carnival Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 3.5L V6 (290 hp, 262 lb-ft) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,299 lbs (589 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,710 lbs (2,590 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 9,210 lbs (4,178 kg) |
| Tongue Weight Limit | 350 lbs (159 kg) |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional |
The 2022 Kia Carnival was the first year the Carnival nameplate returned to the North American market, replacing the Kia Sedona designation. Maximum towing capacity is 3,500 lbs (1,588 kg), maximum payload is 1,299 lbs (589 kg), and GVWR is 5,710 lbs (2,590 kg) across all 2022 trims. Because the 2022 model uses a single engine across all configurations, towing capacity does not vary by trim level.
2015-2021 Kia Carnival / Sedona Towing Capacity
The third-generation Carnival was produced from 2015 through 2021 and sold in North American markets as the Kia Sedona. In North America, Sedona models across this generation used a 3.3L V6 engine and a front-wheel-drive layout. Towing capacity remained consistent at 3,500 lbs (1,588 kg) across the 2015-2021 span.
| Specification | Detail |
|---|---|
| Engine Options | 3.3L V6 (276 hp); 3.3L V6 (282 hp, updated) |
| Drivetrain | FWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 3,500 lbs (1,588 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,526 lbs (692 kg) – 2015; 1,674 lbs (760 kg) – 2017; 1,642 lbs (745 kg) – 2021 |
| Gross Vehicle Weight Rating (GVWR) | 6,065 lbs (2,751 kg) – 2015; 6,085 lbs (2,760 kg) – 2017 |
| Tongue Weight Limit | 350 lbs (159 kg) |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional |
The 2015-2021 Kia Sedona (third-generation Carnival globally) maintained a 3,500 lbs (1,588 kg) towing limit throughout its production run. Maximum payload varied slightly across model years, ranging from 1,526 lbs (692 kg) on the 2015 up to approximately 1,674 lbs (760 kg) on the 2017. The higher GVWR on the third-generation models reflects their greater gross vehicle weight relative to the current fourth-generation Carnival.
2006-2014 Kia Carnival (Second Generation) Towing Capacity
The second-generation Kia Carnival was produced from 2006 through 2014, riding on the Hyundai Entourage platform. In global markets, powertrain options included 2.7L and 3.8L V6 petrol engines, along with a 2.9L turbodiesel four-cylinder. Towing specifications for this generation varied by market, and buyers should consult the owner’s manual or Kia dealer for region-specific ratings.
| Specification | Detail |
|---|---|
| Engine Options | 2.7L V6 (189 hp); 3.8L V6 (254 hp); 2.9L Turbodiesel (185 hp) |
| Drivetrain | FWD |
| Maximum Towing Capacity (Global Braked) | Up to 2,000 kg (4,409 lbs) depending on market and configuration |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Hitch Class | Class III |
| Factory Tow Package | Market-dependent |
The second-generation Carnival was available in short-wheelbase and long-wheelbase variants in some markets, with the long-wheelbase version marketed as the Grand Carnival. Towing capacity in Australian markets for braked trailers was rated at 2,000 kg (4,409 lbs) for applicable engine variants. Regional towing limits differ between North American, Australian, and European specifications, so regional owner’s manuals remain the primary reference for exact values.
1999-2006 Kia Carnival (First Generation) Towing Capacity
The first-generation Kia Carnival entered production in 1999 and continued through 2006. Engine options included a 2.5L V6 petrol producing 165 hp and a 2.9L four-cylinder turbodiesel producing 126 hp. This generation represented Kia’s entry into the multi-purpose vehicle segment.
| Specification | Detail |
|---|---|
| Engine Options | 2.5L V6 (165 hp); 2.9L Turbodiesel (126 hp) |
| Drivetrain | FWD |
| Maximum Towing Capacity (Global Braked) | Up to 2,000 kg (4,409 lbs) depending on market and variant |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Hitch Class | Class II / Class III depending on market fitment |
| Factory Tow Package | Market-dependent |
The first-generation Carnival had a production refresh in 2002. Towing specifications for the first generation were modest by current standards, reflecting the limited powertrain output of the 2.5L V6 and diesel engine variants available at the time. Owners of first-generation models should reference the specific model-year owner’s manual for verified towing limits applicable to their configuration.
Towing Equipment and Setup
Tow Package
A factory or dealer-installed tow package on the Kia Carnival typically includes a trailer wiring harness, reinforced hitch mounting points, and a trailer brake controller connection point. Installing a tow hitch on the Carnival without the appropriate wiring harness limits the operator to light-duty cargo carrier and bike rack use rather than trailer towing. The tow package is listed as optional across all 2022-2026 trim levels.
Trailer Brake Controller
Any trailer approaching or exceeding 1,500 lbs (680 kg) of gross trailer weight typically requires an integrated electric brake system. The Kia Carnival accommodates aftermarket and factory trailer brake controllers. Trailers near the Carnival’s maximum towing capacity of 3,500 lbs will require electric brakes on at least one trailer axle to maintain safe stopping distances.
Weight-Distributing Hitch
For the Kia Carnival, the tongue weight limit remains at 350 lbs (159 kg) regardless of whether a standard dead-weight hitch or a weight-distributing hitch is used. A weight-distributing hitch redistributes tongue weight across all four vehicle axles, reducing rear squat and improving steering response when towing near the rated limit.
Transmission Cooler
Towing increases transmission fluid operating temperature. An auxiliary transmission cooler is recommended for extended towing in high ambient temperatures or hilly terrain. Monitoring transmission fluid condition after regular towing cycles extends drivetrain service life.
Tire Load Ratings
Total vehicle and trailer tongue weight must remain within the tire load index ratings printed on the vehicle tire placard. Overloading rear tires increases blowout risk and degrades steering input.
Trailer Sway Control
The Kia Carnival includes electronic stability control systems that partially address trailer sway. The Trailer Stability Assist (TSA) system applies selective braking when sway is detected. Proper weight distribution on the trailer, with approximately 60 percent of cargo weight forward of the trailer axle, reduces the probability of sway at highway speeds.
Normal vs. Heavy Towing Setup
| Towing Condition | Equipment Requirements |
|---|---|
| Under 1,500 lbs (680 kg) | Basic Class III ball mount, 4-pin wiring harness |
| 1,500-2,500 lbs (680-1,134 kg) | Integrated trailer brakes, 7-pin wiring, sway bar |
| 2,500-3,500 lbs (1,134-1,588 kg) | Electric brake controller, transmission cooler, weight-distributing hitch, trailer stability monitoring |
Frequently Asked Questions
What is the maximum towing capacity of a Kia Carnival?
The maximum towing capacity of the current fourth-generation Kia Carnival is 3,500 lbs (1,588 kg) with the 3.5L V6 engine. Models equipped with the 1.6L turbocharged hybrid powertrain are rated for 3,000 lbs (1,361 kg). These ratings apply when the vehicle is properly equipped with the correct hitch class and trailer wiring.
How much can a Kia Carnival tow with a tow package?
With a factory or compatible aftermarket tow package installed, the Kia Carnival can tow up to 3,500 lbs (1,588 kg) for V6 models. The tow package includes the hitch receiver, wiring harness, and required electrical connections. Without the wiring harness, trailer brake lights and electronic sway control functions cannot operate correctly.
Does the Kia Carnival require a weight-distributing hitch?
The tongue weight limit is 350 lbs (159 kg) regardless of whether a standard dead-weight hitch or a weight-distributing hitch is used. A weight-distributing hitch is not strictly required but is recommended when towing near the maximum tongue weight limit to reduce rear axle squat and improve braking stability.
What trailer weight is safe for a Kia Carnival?
The manufacturer rates the Kia Carnival at a maximum of 3,500 lbs (1,588 kg) for V6 variants. The safe trailer weight depends on the total tongue weight, payload already in the vehicle, number of passengers, and cargo. The combined vehicle payload and tongue weight must not exceed the GVWR of 5,710 lbs (2,590 kg).
What hitch class does the Kia Carnival use?
The Kia Carnival uses a Class III hitch with a 2-inch by 2-inch square receiver. This is the standard receiver size for vehicles in the 3,500 lbs towing capacity range. Aftermarket Class III hitches for the Carnival are available from multiple manufacturers and typically do not require drilling for installation.
Do I need trailer brakes on a trailer towed by a Kia Carnival?
Trailer brakes are required or strongly recommended for trailers above approximately 1,500 lbs (680 kg) in most jurisdictions. For trailers approaching the Carnival’s 3,500 lbs (1,588 kg) limit, electric brakes on at least one trailer axle are necessary to maintain stopping distances within safe limits. Local regulations vary, and operators should confirm state or provincial requirements for trailer brake thresholds.
Conclusion
The Kia Carnival has maintained a consistent maximum towing capacity of 3,500 lbs (1,588 kg) for V6-equipped models across the fourth generation from 2022 through 2026. The introduction of the hybrid powertrain in the 2026 model year added a variant with a 3,000 lbs (1,361 kg) towing limit. For both the current generation and the prior third-generation Sedona platform, the 3,500 lbs figure remained constant across all model years from 2015 through 2025.
Towing capacity on the Carnival is consistent across trim levels because the vehicle uses a single engine option within each model year, removing configuration-based variability common in truck and SUV segments. Payload capacity and GVWR matter as much as the trailer weight rating; the total of occupants, cargo, and tongue weight must remain within the vehicle’s 5,710 lbs (2,590 kg) GVWR at all times. The 350 lbs (159 kg) tongue weight limit applies consistently across both standard and weight-distributing hitch setups.
