The Kia Tasman is a mid-size pickup truck manufactured by Kia since February 2025. It is the brand’s first body-on-frame pickup, built on an all-new ladder-frame platform. The Tasman competes directly with the Toyota Hilux, Ford Ranger, Isuzu D-Max, and Mitsubishi Triton in markets across Asia, Australia, the Middle East, and Africa. The vehicle is not sold in North America or Europe.
Towing capacity for the Kia Tasman reaches 3,500 kg (7,716 lbs) braked and 750 kg (1,653 lbs) unbraked across all model years and configurations to date. This guide provides year-by-year towing specifications, payload limits, gross combined mass ratings, and equipment requirements. Operating within manufacturer-specified limits protects the drivetrain, braking system, and chassis from premature wear and failure.
Quick Navigation
2026 Kia Tasman Towing Capacity
The 2026 Kia Tasman carries forward the same towing specifications established at launch. Two engine options serve different markets. A trailer brake controller is standard equipment on every trim level.
| Specification | Detail |
|---|---|
| Engine Options | 2.2L turbo-diesel 4-cylinder (154 kW / 440 Nm); 2.5L turbo-petrol 4-cylinder (207 kW / 421 Nm) |
| Drivetrain | 2WD (rear-wheel drive) or part-time 4WD with 2H, 4A, 4H, 4L |
| Maximum Towing Capacity | 3,500 kg (7,716 lbs) braked |
| Conventional Towing Capacity | 3,500 kg (7,716 lbs) braked; 750 kg (1,653 lbs) unbraked |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,017–1,195 kg (2,242–2,634 lbs) depending on configuration |
| Gross Combined Weight Rating (GCWR) | 6,200 kg (13,669 lbs) |
| Tongue Weight Limit | 350 kg (772 lbs) |
| Hitch Class | Class IV (50 mm tow ball, 350 kg maximum download) |
| Factory Tow Package | Standard on all models (Integrated Trailer Brake Controller, Trailer Stability Assist, Tow Mode) |
The 2026 Kia Tasman maintains a maximum braked towing capacity of 3,500 kg when properly equipped. All variants include an integrated trailer brake controller and trailer stability assist as standard. Actual towing capacity depends on payload carried in the tub, as the Gross Combined Mass of 6,200 kg must not be exceeded.
2025 Kia Tasman Towing Capacity
The 2025 Kia Tasman launched globally in the first half of 2025 following an October 2024 reveal. Initial production began in February 2025 at Kia’s South Korean manufacturing facility. The 2025 model year established the towing specifications that carry forward unchanged.
| Specification | Detail |
|---|---|
| Engine Options | 2.2L turbo-diesel 4-cylinder (154 kW / 441 Nm); 2.5L turbo-petrol 4-cylinder (207 kW / 421 Nm) |
| Drivetrain | 2WD (rear-wheel drive) or part-time 4WD with 2H, 4A, 4H, 4L |
| Maximum Towing Capacity | 3,500 kg (7,716 lbs) braked |
| Conventional Towing Capacity | 3,500 kg (7,716 lbs) braked; 750 kg (1,653 lbs) unbraked |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,017–1,195 kg (2,242–2,634 lbs) |
| Gross Combined Weight Rating (GCWR) | 6,200 kg (13,669 lbs) |
| Tongue Weight Limit | 350 kg (772 lbs) |
| Hitch Class | Class IV (50 mm tow ball) |
| Factory Tow Package | Standard on all models |
The 2025 Kia Tasman achieved a 3,500 kg braked towing capacity across all trim grades including S, SX, SX+, X-Line, and X-Pro. The diesel engine produces 441 Nm of torque from 1,750 rpm, providing a broad torque curve for towing. The 2.5L turbo-petrol delivers 421 Nm with a higher peak horsepower rating of 207 kW for markets preferring gasoline power.
Towing Equipment and Setup Requirements
The Kia Tasman includes a standard factory tow package across all trim levels. No additional towing preparation package is required. Understanding each component helps ensure safe towing within rated limits.
Integrated Trailer Brake Controller (ITBC)
Every Tasman comes equipped with an ITBC mounted in the dashboard. The system automatically applies trailer brakes in proportion to vehicle brake pressure. Drivers can fine-tune braking force using positive and negative adjustment buttons on the controller. This system is compatible with electric trailer brakes commonly found on caravans and heavy work trailers in Australia, New Zealand, and similar markets. The controller also features a manual override function for added control during descents.
Trailer Stability Assist
The Tasman’s electronic stability control system includes trailer-specific programming. When trailer sway is detected, the system selectively applies individual wheel brakes and adjusts engine torque to bring the trailer back into line. This feature operates automatically and requires no driver intervention.
Tow Mode
Selecting Tow Mode adjusts the transmission shift mapping to hold gears longer under load. This reduces unnecessary gear hunting on inclines and provides more consistent engine braking on descents. Tow Mode also modifies throttle response for smoother acceleration when a trailer is connected.
Weight-Distributing Hitch
Kia does not specify a mandatory weight-distributing hitch for the Tasman at its rated 3,500 kg capacity. However, a weight-distributing hitch is strongly recommended when trailer weight exceeds 2,500 kg or when the tow vehicle’s rear axle loading approaches its 2,040 kg rating. A weight-distributing hitch transfers tongue weight to the front axle, improving steering control and braking stability.
Hitch Receiver and Tow Ball
The Tasman uses a 50 mm tow ball with a maximum download rating of 350 kg. This is a Class IV hitch assembly integrated into the rear chassis crossmember. The tow ball mass must not exceed 350 kg under any loading condition. Tongue weight should represent 10 percent of total trailer weight for stable towing dynamics.
Axle Load Ratings
The front Gross Axle Weight Rating is 1,450 kg. The rear Gross Axle Weight Rating is 2,040 kg. These individual axle limits must be respected alongside GVM and GCM. Heavy tongue weights consume rear axle capacity directly.
Tire Load Ratings
Factory-fitted tires on the Tasman range from 17-inch to 18-inch depending on trim. Tyre pressures should be increased when towing heavy loads. Check the tyre placard located on the driver’s door jamb for recommended towing pressures. Under-inflated tyres generate excessive heat and increase the risk of tread separation under load.
Towing Mirrors
Extended towing mirrors may be required by law in some jurisdictions when trailer width exceeds vehicle width. The Tasman’s standard mirrors provide adequate rearward vision for trailers up to the vehicle’s width. Aftermarket clip-on or replacement towing mirrors should be fitted when towing wider caravans or enclosed trailers.
| Towing Setup Component | Standard Towing (up to 2,000 kg) | Heavy Towing (2,000–3,500 kg) |
|---|---|---|
| Trailer Brake Controller | Standard (ITBC) | Standard (ITBC) |
| Weight-Distributing Hitch | Optional but beneficial | Strongly recommended |
| Tyre Pressure Adjustment | Per placard | Per placard, check when loaded |
| Towing Mirrors | Standard if trailer within width | Required if trailer wider than vehicle |
| Transmission Cooler | Standard (factory) | Standard (factory) |
| Sway Control | Standard (Trailer Stability Assist) | Standard (Trailer Stability Assist) |
| Payload Monitoring | Critical | Critical (GCM 6,200 kg limit) |
Frequently Asked Questions
What is the maximum towing capacity of a Kia Tasman?
The maximum braked towing capacity of the Kia Tasman is 3,500 kg (7,716 lbs). The maximum unbraked towing capacity is 750 kg (1,653 lbs). These ratings apply to all model years and trim levels from 2025 onward, including S, SX, SX+, X-Line, and X-Pro variants.
How much can a Kia Tasman tow with the factory tow package?
The factory tow package is standard on every Kia Tasman. All models tow 3,500 kg braked and 750 kg unbraked. The package includes an integrated trailer brake controller, trailer stability assist, and a dedicated Tow Mode driving setting that adjusts transmission shift patterns under load.
Does 4WD affect the Kia Tasman towing capacity?
No. Both 2WD and 4WD variants share the same 3,500 kg braked towing capacity. The 4WD models have a slightly higher kerb weight, which reduces available payload within the 3,250 kg GVM, but the maximum trailer weight rating remains unchanged regardless of drivetrain configuration.
What is the Gross Combined Mass of the Kia Tasman?
The Gross Combined Mass (GCM) is 6,200 kg (13,669 lbs). This figure represents the maximum allowable combined weight of the loaded vehicle and the loaded trailer. Real-world towing capacity depends on vehicle payload. A fully loaded Tasman at 3,250 kg GVM leaves 2,950 kg available for trailer weight, which is below the 3,500 kg braked maximum.
What trailer weight is safe for a Kia Tasman without trailer brakes?
The maximum unbraked trailer weight is 750 kg (1,653 lbs). Trailers exceeding this weight must have a functional braking system. The integrated trailer brake controller is compatible with electric trailer brakes and provides proportional braking force when correctly calibrated.
Do I need a weight-distributing hitch for the Kia Tasman?
A weight-distributing hitch is not mandatory but is strongly recommended when trailer weight exceeds 2,500 kg or when the rear axle load approaches its 2,040 kg rating. Using a weight-distributing hitch transfers tongue weight to the front axle, which improves steering control, braking stability, and headlight aim.
What is the tow ball weight limit on a Kia Tasman?
The maximum tow ball download is 350 kg (772 lbs). This represents the maximum vertical load that can be applied to the tow ball. For stable towing, tongue weight should typically equal 10 percent of total trailer weight. The 350 kg limit corresponds directly to the 3,500 kg maximum trailer weight at the recommended 10 percent ratio.
Conclusion
The Kia Tasman delivers a consistent maximum braked towing capacity of 3,500 kg across all model years from 2025 through 2026. This rating applies universally to all trim levels, engine options, and drivetrain configurations. The standard inclusion of an integrated trailer brake controller, trailer stability assist, and a dedicated tow mode eliminates the need for optional towing packages.
Payload and GCM management requires attention. The 6,200 kg Gross Combined Mass means a fully loaded Tasman at its 3,250 kg GVM cannot simultaneously tow the full 3,500 kg. Fleet operators and private owners must calculate the trade-off between payload and trailer weight for each trip. The 350 kg tow ball limit, 2,040 kg rear axle rating, and 750 kg unbraked limit form additional constraints that must be respected.
Always verify towing specifications using the owner’s manual and the vehicle’s compliance plate before towing heavy loads. Manufacturer-rated limits exist to protect the engine, transmission, brakes, and chassis. Exceeding these limits compromises vehicle control and may void warranty coverage.
