The Lexus GX 460 is a body-on-frame mid-size luxury SUV built on the Toyota Land Cruiser Prado platform. It was produced from 2010 through 2023, powered by a 4.6-liter V8 engine paired with full-time four-wheel drive across every model year.
This guide covers year-by-year towing specifications for the Lexus GX 460, including maximum trailer weight, payload capacity, tongue weight limits, and hitch class requirements. Towing capacity remains consistent at 6,500 lbs across all production years and trim levels, though payload ratings vary slightly by configuration.
Quick Navigation
2023 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295-1,472 lbs (587-668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2023 Lexus GX 460 offers a maximum towing capacity of 6,500 lbs (2,950 kg) across all four trim levels: standard, Premium, Black Line Special Edition, and Luxury. A weight-distributing hitch is required by Lexus when the trailer load exceeds 5,000 lbs. Staying within the rated limits preserves transmission cooling capacity and maintains predictable braking behavior.
2022 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295-1,472 lbs (587-668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2022 Lexus GX 460 carries a maximum towing capacity of 6,500 lbs (2,950 kg) across the base, Premium, and Luxury trims. The standard full-time 4WD system and 6-speed automatic transmission deliver consistent torque distribution during towing. Trailer sway control is standard equipment on all 2022 configurations.
2021 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295 lbs (587 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2021 Lexus GX 460 supports a maximum trailer weight of 6,500 lbs (2,950 kg) when a weight-distributing hitch is used. Dead weight hitch towing is limited to 5,000 lbs (2,268 kg), with a tongue weight limit of 500 lbs (227 kg) in that configuration. Curb weight for the 2021 base model is approximately 5,130 lbs (2,327 kg).
2020 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295-1,472 lbs (587-668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2020 Lexus GX 460 maintains the same maximum towing capacity of 6,500 lbs (2,950 kg) shared across all model years. The GVWR of 6,600 lbs limits total vehicle payload, making it important to account for passenger and cargo weight before calculating remaining trailer load capacity. All trim levels are rated identically for maximum trailer weight.
2019 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295-1,472 lbs (587-668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2019 Lexus GX 460 is rated for a maximum trailer weight of 6,500 lbs (2,950 kg) using a weight-distributing hitch. The dead weight hitch configuration caps trailer weight at 5,000 lbs (2,268 kg) with a maximum tongue weight of 500 lbs (227 kg). The Kinetic Dynamic Suspension System standard on this generation aids stability under loaded conditions.
2018 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295-1,472 lbs (587-668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2018 Lexus GX 460 supports a maximum towing capacity of 6,500 lbs (2,950 kg) across all trim levels. Lexus requires a trailer sway control device on any trailer weighing over 2,000 lbs (907 kg) for this model year. The 4.6L V8 engine provides 329 lb-ft of torque, delivering adequate pulling force within rated limits.
2017 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295-1,472 lbs (587-668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2017 Lexus GX 460 carries a uniform maximum towing capacity of 6,500 lbs (2,950 kg) regardless of trim selection. Gross Vehicle Weight Rating is set at 6,600 lbs (2,994 kg), which constrains on-board payload when towing near the maximum trailer weight. Proper weight distribution between the tow vehicle and trailer improves braking performance and lateral stability.
2016 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295-1,401 lbs (587-635 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2016 Lexus GX 460 is rated at a maximum towing capacity of 6,500 lbs (2,950 kg) for all trim configurations. Payload capacity on the Luxury trim reaches approximately 1,401 lbs (635 kg) with a curb weight of 5,199 lbs (2,358 kg). The transmission-oil cooler available through the Off-Road Package supports sustained towing performance in demanding conditions.
2015 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,472 lbs (668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2015 Lexus GX 460 supports a maximum trailer weight of 6,500 lbs (2,950 kg) and carries a documented payload capacity of 1,472 lbs (668 kg). Curb weight for the 2015 model is listed at approximately 5,128 lbs (2,326 kg). The 6-speed electronically controlled automatic transmission manages torque delivery reliably within rated towing limits.
2014 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,472 lbs (668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2014 Lexus GX 460 delivers a maximum towing capacity of 6,500 lbs (2,950 kg) across all trim levels. Payload capacity for the 2014 model year is documented at 1,472 lbs (668 kg). The body-on-frame construction shared with the Toyota Land Cruiser Prado provides a stable base for towing at the rated maximum.
2013 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295-1,472 lbs (587-668 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2013 Lexus GX 460 maintains the same maximum towing capacity of 6,500 lbs (2,950 kg) as all other production years. Full-time 4WD is standard, and the center limited-slip differential contributes to traction consistency when towing on mixed surfaces. Using trailer brakes allows the vehicle to approach the maximum rated trailer weight safely.
2012 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295 lbs (587 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2012 Lexus GX 460 offers a maximum towing capacity of 6,500 lbs (2,950 kg) across all trim configurations. The hi-lo gear transfer case provides additional drivetrain control in low-speed towing or recovery situations. Tongue weight must not exceed 500 lbs (227 kg) when using a dead weight hitch setup on this model year.
2011 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295 lbs (587 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2011 Lexus GX 460 supports a maximum trailer weight of 6,500 lbs (2,950 kg) when equipped with a weight-distributing hitch. The 4.6L V8 replaced the prior-generation 4.7L unit, offering improved fuel economy while retaining the same towing capacity. Unbraked towing is limited to 1,000 lbs (454 kg) on all GX 460 model years.
2010 Lexus GX 460 Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.6L V8 (1UR-FE), 301 hp, 329 lb-ft torque |
| Drivetrain | Full-time 4WD |
| Maximum Towing Capacity | 6,500 lbs (2,950 kg) |
| Conventional Towing Capacity (Dead Weight Hitch) | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,295 lbs (587 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,600 lbs (2,994 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) dead weight hitch; 650 lbs (295 kg) with WDH |
| Hitch Class | Class III (2-inch receiver) |
| Factory Tow Package | Optional (Receiver Hitch + Trailer Ball) |
The 2010 Lexus GX 460 was the first model year of the second generation, rated at a maximum towing capacity of 6,500 lbs (2,950 kg). Curb weight for the 2010 model is documented at approximately 5,305 lbs (2,406 kg), with a maximum payload of 1,295 lbs (587 kg). The 6-speed automatic transmission introduced in this generation represented a fuel and performance improvement over the prior GX 470.
Towing Equipment and Setup Tips
Proper towing equipment is essential for operating a Lexus GX 460 at or near its maximum trailer weight rating. Using undersized or improperly installed components increases trailer sway risk and reduces braking effectiveness.
Tow Package
The Lexus GX 460 does not include a factory-installed tow hitch as standard equipment on most trims. A receiver hitch and trailer ball must be purchased separately or as dealer-installed options. Lexus sells these as individual components rather than a combined tow package.
Weight-Distributing Hitch
Lexus requires a weight-distributing hitch (WDH) when trailer weight exceeds 5,000 lbs (2,268 kg). A WDH redistributes tongue weight across all axles, reducing nose dive on the tow vehicle and improving steering response. The maximum tongue weight increases from 500 lbs (227 kg) to 650 lbs (295 kg) when a weight-distributing hitch is used.
Trailer Sway Control
Lexus specifies that a trailer sway control device must be used on any trailer weighing over 2,000 lbs (907 kg). Trailer sway control applies selective braking to individual wheels to counteract trailer oscillation. Trailer Sway Control (TSC) is integrated as standard equipment on all GX 460 model years.
Trailer Brakes
The maximum unbraked towing capacity for the Lexus GX 460 is 1,000 lbs (454 kg). Any trailer exceeding that weight requires a functioning trailer brake system. A brake controller must be installed in the tow vehicle to activate the trailer’s electric brakes.
Transmission Cooler
A transmission-oil cooler is available as part of the Off-Road Package on the GX 460 Luxury trim. Sustained towing at high ambient temperatures or on grades can elevate transmission fluid temperatures beyond the normal operating range. A cooler reduces long-term transmission wear during repeated towing use.
Tire Load Ratings
Verify that tire load ratings support the combined weight of the vehicle at its GVWR before towing. Underinflated or overloaded tires reduce lateral stability and increase stopping distances when towing heavy loads.
Normal Towing vs. Heavy Towing Setup
| Component | Normal Towing (Under 5,000 lbs) | Heavy Towing (5,000-6,500 lbs) |
|---|---|---|
| Hitch Type | Dead weight Class III | Weight-distributing hitch required |
| Tongue Weight Limit | 500 lbs (227 kg) | 650 lbs (295 kg) |
| Trailer Sway Control | Required above 2,000 lbs | Required |
| Trailer Brakes | Required above 1,000 lbs | Required |
| Transmission Cooler | Recommended | Strongly recommended |
Frequently Asked Questions
What is the maximum towing capacity of a Lexus GX 460?
The maximum towing capacity of the Lexus GX 460 is 6,500 lbs (2,950 kg). This rating applies to all model years from 2010 through 2023 and all trim levels. Reaching this limit requires a properly rated weight-distributing hitch.
How much can a Lexus GX 460 tow with a standard dead weight hitch?
With a dead weight hitch, the Lexus GX 460 is limited to 5,000 lbs (2,268 kg) of trailer weight. The tongue weight limit in this configuration is 500 lbs (227 kg). Exceeding 5,000 lbs requires switching to a weight-distributing hitch setup.
Does 4WD affect Lexus GX 460 towing capacity?
The Lexus GX 460 uses full-time 4WD as the only drivetrain configuration across all years. Towing capacity is rated at 6,500 lbs for this drivetrain in every model year. There is no 2WD variant, so all published towing specifications reflect the full-time 4WD system.
What trailer weight is safe for a Lexus GX 460?
The manufacturer-rated maximum trailer weight is 6,500 lbs (2,950 kg) with a weight-distributing hitch. Staying below the rated maximum preserves braking control, transmission integrity, and suspension geometry. For sustained use, operating at 80 percent or less of the maximum rating reduces drivetrain stress.
Do I need a weight-distributing hitch for a Lexus GX 460?
A weight-distributing hitch is required by Lexus whenever the trailer weight exceeds 5,000 lbs (2,268 kg). For loads between 1,000 lbs (454 kg) and 5,000 lbs (2,268 kg), a standard Class III dead weight hitch is sufficient. Trailers over 2,000 lbs (907 kg) also require a separate trailer sway control device per Lexus specifications.
What hitch class does the Lexus GX 460 use?
The Lexus GX 460 is compatible with a Class III hitch featuring a 2-inch receiver. A Class III rating supports gross trailer weights up to 6,000-8,000 lbs depending on vehicle configuration. Frame-mounted hitch installation is required, as the GX 460 bumper is not rated for bumper towing.
Conclusion
The Lexus GX 460 maintains a consistent maximum towing capacity of 6,500 lbs (2,950 kg) across all 14 model years from 2010 through 2023. Unbraked towing is limited to 1,000 lbs (454 kg), and trailers exceeding 5,000 lbs (2,268 kg) require a weight-distributing hitch by manufacturer specification. The 4.6L V8 engine and full-time 4WD drivetrain are the only powertrain configuration available, meaning towing limits do not vary by engine or drivetrain selection.
Payload capacity ranges from approximately 1,295 lbs to 1,472 lbs (587-668 kg) depending on model year and trim level, and this figure directly affects how much trailer weight the vehicle can safely manage. The optional transmission-oil cooler and standard trailer sway control system support consistent performance at or near the rated towing limit.
