Lincoln MKX Towing Capacity (All Years 2007-2018)

The Lincoln MKX is a mid-size luxury crossover SUV produced from the 2007 through 2018 model years. Based on the Ford CD3 platform shared with the Ford Edge, the MKX was offered in front-wheel drive and all-wheel drive configurations across two distinct generations. The nameplate was replaced by the Lincoln Nautilus for the 2019 model year.

Towing capacity varies depending on engine choice, drivetrain, and the presence of the optional Class II Trailer Tow Package. This guide provides year-by-year towing specifications, including maximum trailer weight, payload limits, and hitch requirements. Following manufacturer-rated limits protects the engine, transmission, and braking systems from premature wear and failure.

2018 Lincoln MKX Towing Capacity

The 2018 Lincoln MKX offers a maximum towing capacity of 3,500 pounds when equipped with the optional Class II Trailer Tow Package. The tow package includes a frame-mounted receiver hitch, a four-pin and seven-pin wiring harness, trailer sway control, an upgraded radiator, and upgraded cooling fans. Models without the tow package are limited to 2,000 pounds. The trailer frontal area must not exceed 30 square feet with the tow package or 20 square feet without it.

2017 Lincoln MKX Towing Capacity

The 2017 MKX shares its towing specifications with the 2018 model year. The 2.7-liter EcoBoost engine produces 335 horsepower and 380 pound-feet of torque but does not increase the maximum trailer weight rating beyond 3,500 pounds. All trims require the Class II Trailer Tow Package to achieve the full 3,500-pound rating.

2016 Lincoln MKX Towing Capacity

The 2016 MKX introduced the second-generation model with a redesigned body structure and updated powertrains. The maximum towing capacity remains 3,500 pounds with the Class II Trailer Tow Package. Curb weight ranges from 4,168 pounds for FWD models to 4,387 pounds for AWD models. Gross vehicle weight rating is 5,440 pounds for FWD and 5,620 pounds for AWD configurations.

2015 Lincoln MKX Towing Capacity

The 2015 MKX is the final year of the first-generation body style, which underwent a significant refresh in 2011. The sole engine is the 3.7-liter Ti-VCT V6 producing 305 horsepower and 280 pound-feet of torque. Towing capacity with the Class II Trailer Tow Package is 3,500 pounds. The standard rating without the tow package is 2,000 pounds.

2014 Lincoln MKX Towing Capacity

The 2014 Lincoln MKX maintains the 3,500-pound maximum towing capacity when equipped with the factory tow package. Gross vehicle weight rating is 5,457 pounds. The six-speed SelectShift automatic transmission includes a manual shift mode. Staying within the rated towing limits protects the transmission from overheating during extended grade climbing.

2013 Lincoln MKX Towing Capacity

The 2013 MKX towing capacity is 3,500 pounds with the trailer towing package. Vehicles equipped with 22-inch wheels are limited to a 2,000-pound trailer weight regardless of other equipment. The owner’s manual specifies that trailer frontal area must not exceed 30 square feet. Electric trailer brakes are required for trailers over a specified weight in certain states.

2012 Lincoln MKX Towing Capacity

The 2012 MKX offers a maximum towing capacity of 3,500 pounds with the Class II trailer tow package. The owner’s manual lists four separate GCWR ratings based on drivetrain and tow package status. The trailer tow connector is located under the rear bumper on the driver side. Tongue weight must equal 10 to 15 percent of the total trailer weight for stable towing.

2011 Lincoln MKX Towing Capacity

The 2011 Lincoln MKX received a significant refresh with a new 3.7-liter Ti-VCT V6 engine producing 305 horsepower and 280 pound-feet of torque, replacing the previous 3.5-liter unit. Maximum towing capacity remains 3,500 pounds with the Class II Trailer Tow Package. Vehicles with 22-inch wheels from the factory have their trailer weight rating reduced to 2,000 pounds. The six-speed SelectShift automatic transmission includes paddle activation for manual gear selection.

2010 Lincoln MKX Towing Capacity

The 2010 MKX uses the 3.5-liter Duratec V6 producing 265 horsepower and 250 pound-feet of torque. The optional Class II Trailer Tow Package enables a maximum towing capacity of 3,500 pounds. Without the tow package, the rating is 2,000 pounds. The tow package includes a Class II frame-mounted receiver hitch, a larger radiator, upgraded cooling fans, and a wiring harness with a four-pin connector.

2009 Lincoln MKX Towing Capacity

The 2009 MKX received a mid-cycle exterior and interior refresh. Towing specifications remain unchanged from the 2008 model year. Maximum towing capacity is 3,500 pounds with the Class II Trailer Tow Package. Curb weight for the AWD model is approximately 4,400 pounds, and gross vehicle weight rating is 5,370 pounds. The transmission cooler is integrated into the larger radiator included with the tow package.

2008 Lincoln MKX Towing Capacity

The 2008 Lincoln MKX carries over the same powertrain and towing specifications from the debut model year. Maximum towing capacity is 3,500 pounds with the Class II Trailer Tow Package. The owner’s manual warns that towing beyond the maximum recommended gross trailer weight can result in engine damage, transmission damage, and structural damage.

2007 Lincoln MKX Towing Capacity

The 2007 Lincoln MKX is the first model year of the nameplate. Maximum towing capacity is 3,500 pounds when equipped with the Class II Trailer Tow Package. The base towing limit without the tow package is 2,000 pounds. The owner’s manual specifies that towing a trailer over 3,500 pounds requires a weight-distributing hitch. Payload capacity is 1,010 pounds, the highest of any MKX model year.

Towing Equipment and Setup Requirements

Factory Tow Package

The Class II Trailer Tow Package was optional on all MKX model years. This package includes a frame-mounted Class II receiver hitch, a four-pin and seven-pin wiring harness, an upgraded radiator, upgraded cooling fans, and trailer sway control integration through the stability control system. The standard towing preparation without the package limits trailer weight to 2,000 pounds. Verifying the presence of the tow package before purchasing a used MKX is essential for owners planning to tow near the maximum rating.

Trailer Brake Controller

The MKX trailer tow connector includes a circuit for electric trailer brakes on vehicles equipped with the tow package. A trailer brake controller is required when towing trailers with electric brakes. Certain states mandate electric trailer brakes for trailers exceeding a specified weight threshold. The owner’s manual directs owners to check state regulations for these requirements.

Weight-Distributing Hitch

A weight-distributing hitch is recommended for trailer loads approaching the 3,500-pound maximum. The 2007 owner’s manual specifically states that towing a trailer over 3,500 pounds requires a weight-distributing hitch. This equipment transfers tongue weight from the rear axle to the front axle and trailer axles, improving steering control and braking stability.

Transmission Cooler

The Class II Trailer Tow Package includes an upgraded radiator that provides additional transmission fluid cooling. The standard cooling system may not provide adequate heat rejection for extended towing near the maximum trailer weight rating. Vehicles without the tow package rely on a smaller radiator and are limited to 2,000 pounds.

Tire Load Ratings

Tires must be inflated to the pressures specified on the vehicle placard when towing. Standard tire sizes vary by model year and trim level. Vehicles equipped with 22-inch wheels have a reduced trailer weight limit of 2,000 pounds due to lower tire load capacity. Owners should verify tire load ratings before towing heavy trailers.

Trailer Sway Control

The MKX integrates trailer sway control into the AdvanceTrac stability control system when equipped with the factory tow package. If the system detects trailer sway, it applies individual wheel brakes and reduces engine power to help stabilize the vehicle and trailer. The driver information display shows a “TRAILER SWAY REDUCE SPEED” message when activation occurs.

Normal Towing vs. Heavy Towing Setup

Frequently Asked Questions

What is the maximum towing capacity of a Lincoln MKX?

The maximum towing capacity of a Lincoln MKX is 3,500 pounds when equipped with the optional Class II Trailer Tow Package. Without the tow package, all model years are limited to 2,000 pounds. This rating applies to both FWD and AWD configurations and does not vary by engine choice.

How much can a Lincoln MKX tow with a tow package?

A Lincoln MKX equipped with the factory Class II Trailer Tow Package can tow up to 3,500 pounds. The tow package includes a frame-mounted receiver hitch, upgraded radiator, upgraded cooling fans, a wiring harness, and trailer sway control. All model years from 2007 through 2018 share this maximum rating.

Does AWD affect Lincoln MKX towing capacity?

AWD does not reduce the Lincoln MKX maximum towing capacity. Both FWD and AWD models are rated at 3,500 pounds with the Class II Trailer Tow Package. The AWD GCWR is slightly higher at 8,440 pounds compared to 8,270 pounds for FWD configurations due to the increased vehicle weight.

What trailer weight is safe for a Lincoln MKX without the tow package?

A Lincoln MKX without the Class II Trailer Tow Package is limited to a maximum trailer weight of 2,000 pounds. The standard cooling system, smaller radiator, and absence of a frame-mounted receiver hitch restrict towing capability. Adding aftermarket equipment does not increase the manufacturer-rated limit.

Do I need a weight-distributing hitch for a Lincoln MKX?

A weight-distributing hitch is recommended for trailer loads approaching the 3,500-pound maximum. The 2007 owner’s manual specifies that trailers over 3,500 pounds require a weight-distributing hitch. Using one improves steering control, braking stability, and front axle load distribution.

What engines are available in the Lincoln MKX and do they change towing capacity?

The Lincoln MKX used a 3.5L Duratec V6 from 2007 to 2010, a 3.7L Ti-VCT V6 from 2011 to 2018, and an optional 2.7L EcoBoost V6 twin-turbo from 2016 to 2018. None of these engine options change the maximum towing capacity. All engines are rated at 3,500 pounds with the Class II Trailer Tow Package.

What is the tongue weight limit on a Lincoln MKX?

The tongue weight limit is 200 pounds for the standard towing configuration and 350 pounds with the Class II Trailer Tow Package. Tongue weight should equal 10 to 15 percent of the total trailer weight. Exceeding the tongue weight limit can cause rear suspension sag, reduced steering control, and trailer instability.

Conclusion

The Lincoln MKX towing capacity ranges from 2,000 pounds to 3,500 pounds across all model years from 2007 through 2018. The lower rating applies to vehicles without the Class II Trailer Tow Package. The higher rating requires the factory tow package, which includes a frame-mounted hitch, upgraded cooling components, and trailer sway control integration.

Engine output varies across production years. The 2007 through 2010 models use a 3.5-liter Duratec V6 producing 265 horsepower and 250 pound-feet of torque. The 2011 through 2018 models use a 3.7-liter Ti-VCT V6 producing 305 horsepower and 280 pound-feet of torque. The 2016 through 2018 models also offered an optional 2.7-liter EcoBoost V6 twin-turbo producing 335 horsepower and 380 pound-feet of torque. None of these engine configurations change the maximum trailer weight rating.

Payload capacity ranges from 900 pounds to 1,010 pounds depending on model year and configuration. Tongue weight is limited to 350 pounds with the tow package. GCWR varies by drivetrain, with AWD models rated at 8,440 pounds and FWD models at 8,270 pounds when equipped with the tow package. Vehicles with 22-inch wheels have a reduced trailer weight limit of 2,000 pounds regardless of other equipment.

Always verify specifications using the owner’s manual before towing heavy loads.
