The Lincoln Nautilus is a mid-size luxury crossover SUV that entered production for the 2019 model year, replacing the Lincoln MKX. It was redesigned on an all-new platform for the 2024 model year and remains in production through the current 2026 model year. All Nautilus models utilize unibody construction and are available with either front-wheel drive or all-wheel drive.
This guide provides year-by-year towing specifications for the Lincoln Nautilus, including maximum trailer weight, payload limits, and hitch requirements. Staying within manufacturer-rated towing limits helps protect the engine, transmission, and braking systems. The Nautilus spans two distinct generations, and towing capacity varies significantly between them and by equipment level.
Quick Navigation
2026 Lincoln Nautilus Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (250 hp, 275 lb-ft); 2.0L Turbo Hybrid I-4 (310 hp) |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity | 1,750 lbs (794 kg) |
| Conventional Towing Capacity | 1,750 lbs (794 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | N/A (refer to door jamb sticker) |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 175 lbs (79 kg) dead weight hitch |
| Hitch Class | Class I (dealer-installed) |
| Factory Tow Package | Dealer-installed Class I Trailer Tow Package (optional) |
The 2026 Lincoln Nautilus offers a maximum towing capacity of 1,750 lbs when equipped with the dealer-installed Class I Trailer Tow Package. Lincoln does not offer factory-installed towing hardware on this generation. The available 2.0L hybrid powertrain does not increase towing capacity. All 2024-and-newer Nautilus models share the same towing rating regardless of engine choice.
2025 Lincoln Nautilus Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (250 hp, 275 lb-ft); 2.0L Turbo Hybrid I-4 (310 hp) |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity | 1,750 lbs (794 kg) |
| Conventional Towing Capacity | 1,750 lbs (794 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | N/A (refer to door jamb sticker) |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 175 lbs (79 kg) dead weight hitch |
| Hitch Class | Class I (dealer-installed) |
| Factory Tow Package | Dealer-installed Class I Trailer Tow Package (optional) |
The 2025 Lincoln Nautilus maintains the 1,750 lb maximum towing capacity established with the 2024 redesign. The Class I Trailer Tow Package equips the vehicle with the necessary hardware to safely tow up to its maximum weight. The trailer tow package includes a trailer hitch receiver and wiring harness, along with integrated trailer sway control.
2024 Lincoln Nautilus Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (250 hp, 275 lb-ft) |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity | 1,750 lbs (794 kg) |
| Conventional Towing Capacity | 1,750 lbs (794 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | N/A (refer to door jamb sticker) |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 175 lbs (79 kg) dead weight hitch |
| Hitch Class | Class I (dealer-installed) |
| Factory Tow Package | Dealer-installed Class I Trailer Tow Package (optional) |
The 2024 Lincoln Nautilus introduces the second-generation platform with a lower maximum towing capacity of 1,750 lbs compared to the outgoing generation. The redesign brought a larger 20-gallon fuel tank and a curb weight ranging from 4,349 lbs to approximately 4,565 lbs. The Class I Trailer Tow Package requires dealer installation and enables the vehicle to tow lightweight loads such as small utility trailers, motorcycle carriers, or bike racks.
2023 Lincoln Nautilus Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (250 hp, 280 lb-ft); 2.7L Twin-Turbo V6 (335 hp, 380 lb-ft) |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) without tow package; 3,500 lbs (1,588 kg) with tow package |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 895 lbs (406 kg) to 1,435 lbs (651 kg) depending on configuration |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs (91 kg) dead weight hitch; 350 lbs (159 kg) with Class II tow package |
| Hitch Class | Class II (with Trailer Tow Package) |
| Factory Tow Package | Optional Class II Trailer Tow Package (53G) and required Cargo Utility Package (51U) |
The 2023 Lincoln Nautilus offers a maximum towing capacity of 3,500 lbs when properly equipped with the factory Class II Trailer Tow Package and the required Cargo Utility Package. Without the tow package, the base towing limit is 2,000 lbs. Both the 2.0L I-4 and 2.7L V6 engines achieve the same maximum rating with the trailer tow package installed.
2022 Lincoln Nautilus Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (250 hp, 280 lb-ft); 2.7L Twin-Turbo V6 (335 hp, 380 lb-ft) |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) without tow package; 3,500 lbs (1,588 kg) with tow package |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 895 lbs (406 kg) to 1,540 lbs (698 kg) depending on configuration |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs (91 kg) dead weight hitch; 350 lbs (159 kg) with Class II tow package |
| Hitch Class | Class II (with Trailer Tow Package) |
| Factory Tow Package | Optional Class II Trailer Tow Package (53G) and required Cargo Utility Package (51U) |
The 2022 Lincoln Nautilus continues with the first-generation platform and its 3,500 lb maximum towing capacity when equipped with the Class II Trailer Tow Package and Cargo Utility Package. The tow package includes a trailer hitch, trailer sway control, and a wiring harness. Base curb weight is approximately 4,165 lbs for FWD models and 4,305 lbs for AWD models.
2021 Lincoln Nautilus Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (250 hp, 280 lb-ft); 2.7L Twin-Turbo V6 (335 hp, 380 lb-ft) |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) without tow package; 3,500 lbs (1,588 kg) with tow package |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 895 lbs (406 kg) to 1,540 lbs (698 kg) depending on configuration |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs (91 kg) dead weight hitch; 350 lbs (159 kg) with Class II tow package |
| Hitch Class | Class II (with Trailer Tow Package) |
| Factory Tow Package | Optional Class II Trailer Tow Package (53G) and required Cargo Utility Package (51U) |
The 2021 Lincoln Nautilus received a mid-cycle refresh that included updated exterior styling and an interior redesign featuring a larger 13.2-inch display. Maximum towing capacity remained unchanged at 3,500 lbs with the required optional packages. The Class II Trailer Tow Package (53G) must be paired with the Cargo Utility Package (51U) to achieve the maximum trailer weight rating.
2020 Lincoln Nautilus Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (250 hp, 280 lb-ft); 2.7L Twin-Turbo V6 (335 hp, 380 lb-ft) |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) without tow package; 3,500 lbs (1,588 kg) with tow package |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 895 lbs (406 kg) to 1,540 lbs (698 kg) depending on configuration |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs (91 kg) dead weight hitch; 350 lbs (159 kg) with Class II tow package |
| Hitch Class | Class II (with Trailer Tow Package) |
| Factory Tow Package | Optional Class II Trailer Tow Package and required Cargo Utility Package |
The 2020 Lincoln Nautilus provides a maximum towing capacity of 3,500 lbs when equipped with the available Class II Trailer Tow Package and Cargo Utility Package. The 2.7L twin-turbo V6 produces 380 lb-ft of torque at 3,250 rpm, providing strong low-end pulling power for trailer towing. The 2.0L turbocharged four-cylinder engine achieves the same maximum tow rating despite its lower torque output of 280 lb-ft.
2019 Lincoln Nautilus Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged I-4 (250 hp, 280 lb-ft); 2.7L Twin-Turbo V6 (335 hp, 380 lb-ft) |
| Drivetrain | FWD / AWD |
| Maximum Towing Capacity | 3,500 lbs (1,588 kg) |
| Conventional Towing Capacity | 2,000 lbs (907 kg) without tow package; 3,500 lbs (1,588 kg) with tow package |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 895 lbs (406 kg) to 1,540 lbs (698 kg) depending on configuration |
| Gross Combined Weight Rating (GCWR) | Consult owner’s manual |
| Tongue Weight Limit | 200 lbs (91 kg) dead weight hitch; 350 lbs (159 kg) with Class II tow package |
| Hitch Class | Class II (with Trailer Tow Package) |
| Factory Tow Package | Optional Class II Trailer Tow Package and required Cargo Utility Package |
The 2019 Lincoln Nautilus launched as the replacement for the Lincoln MKX. Maximum towing capacity is 3,500 lbs when properly equipped with the available Class II Trailer Tow Package and Cargo Utility Package. The base towing limit without these packages is 2,000 lbs. Both engine options achieve the same maximum towing capacity when paired with the factory tow package.
Towing Equipment and Setup Tips
The Lincoln Nautilus requires specific towing equipment depending on the generation and target trailer weight. First-generation models (2019-2023) use a Class II Trailer Tow Package that includes a hitch receiver, wiring harness, and integrated trailer sway control. The Cargo Utility Package is a required co-requisite for the Class II tow package on these models. Second-generation models (2024 and newer) use a dealer-installed Class I Trailer Tow Package.
Trailer brakes are not mandatory for the Nautilus at its rated capacities, as the 3,500 lb maximum on first-generation models and the 1,750 lb maximum on second-generation models fall below the typical threshold where most jurisdictions require separate trailer braking systems. However, a trailer brake controller is recommended if towing near the maximum rated trailer weight. Aftermarket brake controllers are compatible with the Nautilus wiring harness.
A weight-distributing hitch is not required for the Lincoln Nautilus. The vehicle’s unibody construction and relatively low towing capacity make a standard ball mount with the appropriate hitch receiver the correct setup. For 2024 and newer models, the maximum tongue weight is 175 lbs with a dead weight hitch. For 2019-2023 models, the maximum tongue weight is 200 lbs dead weight and 350 lbs with the Class II tow package.
A transmission cooler is factory-equipped on all Nautilus models. The 8-speed automatic transmission includes an integrated oil cooler that manages heat during towing. Owners who tow frequently in hot climates or mountainous terrain should monitor transmission fluid temperature and follow the severe-service maintenance schedule specified in the owner’s manual.
Tire load ratings must be verified before towing. Factory tires are P-metric all-season radials. Tire pressure should be increased to the maximum load specification printed on the vehicle placard when towing near the upper limits. For first-generation models, the factory tire size is typically 245/60R18 or 255/55R20. For second-generation models, sizes range from 19 to 22 inches depending on trim.
Trailer sway control is integrated into the vehicle stability control system on Nautilus models equipped with the Class II Trailer Tow Package. This system detects trailer oscillation and applies selective braking to help regain stability. The feature is included with the factory tow package on 2019-2023 models and with the Class I Trailer Tow Package on 2024 and newer models.
| Equipment | Normal Towing Setup | Maximum Towing Setup (First Generation) |
|---|---|---|
| Hitch Type | Standard ball mount on receiver | Standard ball mount on Class II receiver |
| Tongue Weight | 200 lbs (91 kg) max dead weight | 350 lbs (159 kg) max with Class II package |
| Trailer Brakes | Not required at rated capacities | Recommended near maximum trailer weight |
| Sway Control | Integrated with tow package | Integrated with tow package |
| Transmission Cooling | Factory oil cooler | Factory oil cooler |
| Tire Pressure | Standard | Maximum load specification |
Frequently Asked Questions
What is the maximum towing capacity of a Lincoln Nautilus?
The maximum towing capacity of a Lincoln Nautilus depends on the model year. First-generation models from 2019 through 2023 can tow up to 3,500 lbs when equipped with the Class II Trailer Tow Package and Cargo Utility Package. Second-generation models from 2024 through 2026 have a maximum towing capacity of 1,750 lbs when equipped with the dealer-installed Class I Trailer Tow Package.
How much can a Lincoln Nautilus tow with a tow package?
With the Class II Trailer Tow Package and Cargo Utility Package, 2019-2023 Lincoln Nautilus models can tow up to 3,500 lbs. Without these packages, the base towing limit is 2,000 lbs. For 2024 and newer Nautilus models, the Class I Trailer Tow Package enables towing up to 1,750 lbs.
Does AWD affect Lincoln Nautilus towing capacity?
AWD does not increase the maximum towing capacity of the Lincoln Nautilus. Both FWD and AWD configurations share the same towing ratings. The AWD system provides additional traction for towing on wet or loose surfaces but does not change the vehicle’s structural towing limits.
What trailer weight is safe for a Lincoln Nautilus?
For 2019-2023 models, the safe maximum trailer weight is 3,500 lbs with the required tow package and 2,000 lbs without it. For 2024 and newer models, the safe maximum is 1,750 lbs. Trailer weight must account for passengers, cargo, and tongue weight to avoid exceeding the gross vehicle weight rating or gross combined weight rating.
Do I need a weight-distributing hitch for a Lincoln Nautilus?
A weight-distributing hitch is not required for the Lincoln Nautilus at any model year or towing configuration. The vehicle’s maximum towing capacity and tongue weight limits are compatible with a standard ball mount on the factory or dealer-installed hitch receiver.
What is the tongue weight limit for a Lincoln Nautilus?
The tongue weight limit for 2019-2023 Nautilus models is 200 lbs with a dead weight hitch and 350 lbs with the Class II tow package. For 2024 and newer models, the tongue weight limit is 175 lbs with a dead weight hitch. Tongue weight should be approximately 10 percent of the loaded trailer weight.
Conclusion
The Lincoln Nautilus towing capacity ranges from 1,750 lbs to 3,500 lbs depending on the model year. First-generation models from 2019 through 2023 offer a maximum towing capacity of 3,500 lbs when equipped with the Class II Trailer Tow Package and the required Cargo Utility Package. Without these packages, the base limit is 2,000 lbs. Second-generation models from 2024 through 2026 are rated at a maximum of 1,750 lbs with the dealer-installed Class I Trailer Tow Package.
Engine configuration does not affect towing capacity. Both the 2.0L turbocharged I-4 and the 2.7L twin-turbo V6 in first-generation models achieve the same 3,500 lb maximum with the required tow package. The 2024 and newer hybrid powertrain shares the 1,750 lb rating with the standard gasoline engine. The Nautilus is a unibody crossover designed for light-duty towing applications such as small utility trailers, personal watercraft, motorcycles, or recreational gear.
Always verify the towing specifications for your specific vehicle using the owner’s manual and the door jamb label before towing any trailer load. The gross combined weight rating must not be exceeded, and tongue weight must be accounted for within the vehicle’s payload capacity.
