The Lincoln Navigator L has been produced from 2007 to present as an extended-wheelbase variant of the standard Navigator. This guide provides complete engine oil capacity, viscosity, and type specifications for all Lincoln Navigator L model years. Using the correct oil specifications maintains engine performance and extends service life.
The Navigator L originally featured a 5.4L V8 engine through 2014, then transitioned to a 3.5L twin-turbocharged EcoBoost V6 from 2015 onward. Oil requirements vary by engine type and model year, with capacities ranging from 6.0 to 6.6 quarts and viscosity specifications including SAE 5W-20 and 5W-30.
Quick Navigation
2025 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Mobil 1 M1-110A |
The 2025 Lincoln Navigator L uses a 3.5L twin-turbocharged V6 that requires 6.0 quarts of full synthetic oil with filter. Using SAE 5W-30 oil provides optimal protection and fuel efficiency for modern turbocharged engines.
2024 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, K&N HP-1017 |
The 2024 Lincoln Navigator L features the same 3.5L EcoBoost engine requiring 6.0 quarts of SAE 5W-30 full synthetic oil. This specification meets Ford WSS-M2C946-A and WSS-M2C961-A1 standards for turbocharged applications.
2023 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Fram XG10575 |
The 2023 Lincoln Navigator L requires 6.0 quarts of SAE 5W-30 full synthetic oil for its twin-turbo V6. Regular oil changes at 7,500-mile intervals maintain turbocharger health and engine longevity.
2022 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Bosch 3330 |
The 2022 Lincoln Navigator L uses 6.0 quarts of SAE 5W-30 full synthetic oil meeting API SP and ILSAC GF-6A specifications. The EcoBoost engine requires high-quality synthetic oil for optimal turbocharger protection.
2021 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Purolator L25288 |
The 2021 Lincoln Navigator L requires 6.0 quarts of SAE 5W-30 full synthetic oil with filter. This viscosity provides proper flow characteristics for cold starts and high-temperature protection.
2020 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Mobil 1 M1-110A |
The 2020 Lincoln Navigator L uses 6.0 quarts of SAE 5W-30 full synthetic oil for its 3.5L twin-turbo engine. Synthetic oil provides superior protection against thermal breakdown in turbocharged applications.
2019 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, K&N HP-1017 |
The 2019 Lincoln Navigator L requires 6.0 quarts of SAE 5W-30 full synthetic oil. The EcoBoost engine demands synthetic oil to handle high operating temperatures generated by turbochargers.
2018 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Fram XG10575 |
The 2018 Lincoln Navigator L uses 6.0 quarts of SAE 5W-30 full synthetic oil for its redesigned 3.5L EcoBoost engine, producing 450 horsepower. This oil specification ensures adequate lubrication under high-performance conditions.
2017 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Bosch 3330 |
The 2017 Lincoln Navigator L requires 6.0 quarts of SAE 5W-30 full synthetic oil. Regular synthetic oil changes protect turbocharger bearings from excessive wear and heat damage.
2016 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Purolator L25288 |
The 2016 Lincoln Navigator L uses 6.0 quarts of SAE 5W-30 full synthetic oil meeting Ford specifications. This oil type provides optimal viscosity stability across wide temperature ranges.
2015 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.5L Twin-Turbo V6 EcoBoost |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 18 lb-ft (24 N·m) |
| Recommended Filters | Motorcraft FL500-S, ACDelco PF63, Mobil 1 M1-110A |
The 2015 Lincoln Navigator L requires 6.0 quarts of SAE 5W-30 full synthetic oil, marking the first year for the twin-turbo EcoBoost V6 in this model. The switch to 5W-30 from 5W-20 provides better high-temperature protection for turbocharged engines.
2014 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 5.4L V8 |
| Oil Capacity (with Filter) | 6.5 qt (6.1 L) |
| Oil Capacity (without Filter) | 6.0 qt (5.7 L) |
| Recommended Oil Type | Synthetic Blend |
| Viscosity | SAE 5W-20 |
| Oil Change Interval | Every 5,000 miles or 6 months |
| Oil Drain Plug Torque | 17 lb-ft (23 N·m) |
| Recommended Filters | Motorcraft FL820-S, Fram PH9688, Purolator L14459 |
The 2014 Lincoln Navigator L uses a 5.4L V8 engine requiring 6.5 quarts of SAE 5W-20 oil. This was the final year for the V8 engine before the EcoBoost transition.
2013 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 5.4L V8 |
| Oil Capacity (with Filter) | 6.5 qt (6.1 L) |
| Oil Capacity (without Filter) | 6.0 qt (5.7 L) |
| Recommended Oil Type | Synthetic Blend |
| Viscosity | SAE 5W-20 |
| Oil Change Interval | Every 5,000 miles or 6 months |
| Oil Drain Plug Torque | 17 lb-ft (23 N·m) |
| Recommended Filters | Motorcraft FL820-S, Fram PH9688, ACDelco PF61 |
The 2013 Lincoln Navigator L requires 6.5 quarts of SAE 5W-20 synthetic blend oil for its 5.4L V8. The 5W-20 viscosity improves fuel economy while providing adequate engine protection.
2012 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 5.4L V8 |
| Oil Capacity (with Filter) | 6.5 qt (6.1 L) |
| Oil Capacity (without Filter) | 6.0 qt (5.7 L) |
| Recommended Oil Type | Synthetic Blend |
| Viscosity | SAE 5W-20 |
| Oil Change Interval | Every 5,000 miles or 6 months |
| Oil Drain Plug Torque | 17 lb-ft (23 N·m) |
| Recommended Filters | Motorcraft FL820-S, Fram PH9688, Bosch 3323 |
The 2012 Lincoln Navigator L uses 6.5 quarts of SAE 5W-20 synthetic blend oil. This viscosity meets Ford specifications for improved cold-start performance and fuel efficiency.
2011 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 5.4L V8 |
| Oil Capacity (with Filter) | 6.6 qt (6.2 L) |
| Oil Capacity (without Filter) | 6.0 qt (5.7 L) |
| Recommended Oil Type | Synthetic Blend |
| Viscosity | SAE 5W-20 |
| Oil Change Interval | Every 5,000 miles or 6 months |
| Oil Drain Plug Torque | 17 lb-ft (23 N·m) |
| Recommended Filters | Motorcraft FL820-S, Fram PH9688, K&N HP-1010 |
The 2011 Lincoln Navigator L requires 6.6 quarts of SAE 5W-20 synthetic blend oil. This model year features slightly higher oil capacity than later 5.4L V8 versions.
2010 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 5.4L V8 |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Conventional/Synthetic Blend |
| Viscosity | SAE 5W-30 or 5W-20 |
| Oil Change Interval | Every 5,000 miles or 6 months |
| Oil Drain Plug Torque | 17 lb-ft (23 N·m) |
| Recommended Filters | Motorcraft FL820-S, Fram PH9688, Purolator L14459 |
The 2010 Lincoln Navigator L uses 6.0 quarts of oil, with viscosity transitioning from 5W-30 to 5W-20 during this model year. Either viscosity is acceptable for 2010 models.
2009 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 5.4L V8 |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Conventional/Synthetic Blend |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 5,000 miles or 6 months |
| Oil Drain Plug Torque | 17 lb-ft (23 N·m) |
| Recommended Filters | Motorcraft FL820-S, Fram PH9688, ACDelco PF61 |
The 2009 Lincoln Navigator L requires 6.0 quarts of SAE 5W-30 oil for its 5.4L V8 engine. This viscosity provides balanced protection across normal operating temperatures.
2008 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 5.4L V8 |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Conventional/Synthetic Blend |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 5,000 miles or 6 months |
| Oil Drain Plug Torque | 17 lb-ft (23 N·m) |
| Recommended Filters | Motorcraft FL820-S, Fram PH9688, Bosch 3323 |
The 2008 Lincoln Navigator L uses 6.0 quarts of SAE 5W-30 oil. Conventional or synthetic blend oil is acceptable for this naturally aspirated V8 application.
2007 Lincoln Navigator L Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 5.4L V8 |
| Oil Capacity (with Filter) | 6.0 qt (5.7 L) |
| Oil Capacity (without Filter) | 5.5 qt (5.2 L) |
| Recommended Oil Type | Conventional/Synthetic Blend |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 5,000 miles or 6 months |
| Oil Drain Plug Torque | 17 lb-ft (23 N·m) |
| Recommended Filters | Motorcraft FL820-S, Fram PH9688, Purolator L14459 |
The 2007 Lincoln Navigator L requires 6.0 quarts of SAE 5W-30 oil, marking the first year for the extended-wheelbase L variant. Regular oil changes using manufacturer-specified viscosity maintain engine reliability.
Oil Maintenance and Service Tips
Check engine oil levels every 1,000 miles or before long trips using the dipstick when the engine is cold and on level ground. Oil change intervals vary by engine type, with modern EcoBoost engines rated for 7,500 miles and older V8 models requiring changes every 5,000 miles. Severe driving conditions including towing, extreme temperatures, or frequent short trips require more frequent oil filter replacement.
Always use oil meeting Ford specifications, including WSS-M2C946-A for EcoBoost engines and WSS-M2C946-A for 5.4L V8 engines. Torque the oil drain plug properly to prevent pan damage and oil leaks, using 18 lb-ft for EcoBoost models and 17 lb-ft for V8 engines. Replace the oil filter gasket with each oil change to ensure proper sealing.
Frequently Asked Questions
What kind of oil does a Lincoln Navigator L use?
The Lincoln Navigator L uses SAE 5W-30 full synthetic oil for 2015-present EcoBoost models, while 2010-2014 models use SAE 5W-20 synthetic blend. Models from 2007-2010 use SAE 5W-30 conventional or synthetic blend oil.
How much oil does a Lincoln Navigator L take?
The Lincoln Navigator L takes 6.0 quarts of oil with filter for EcoBoost V6 models (2015-present) and 6.0 to 6.6 quarts for 5.4L V8 models (2007-2014). Always check the dipstick after filling to verify proper oil level.
What is the recommended oil type for a Lincoln Navigator L?
The recommended oil type is full synthetic for 2015-present turbocharged models, meeting Ford WSS-M2C946-A or WSS-M2C961-A1 specifications. Earlier V8 models can use conventional or synthetic blend oil meeting WSS-M2C946-A standards.
What is the oil change interval for a Lincoln Navigator L?
The oil change interval is 7,500 miles or 6 months for 2015-present EcoBoost models under normal driving conditions. Models with 5.4L V8 engines (2007-2014) require oil changes every 5,000 miles or 6 months.
Can I use 5W-20 oil in a Lincoln Navigator L with EcoBoost engine?
No, 2015-present Navigator L models with 3.5L EcoBoost engines require SAE 5W-30 oil specifically formulated for turbocharged applications. Using 5W-20 oil may not provide adequate high-temperature protection for turbochargers.
What oil filter fits a Lincoln Navigator L?
The Motorcraft FL500-S oil filter fits 2015-present EcoBoost models, while Motorcraft FL820-S fits 2007-2014 V8 models. Aftermarket equivalents include ACDelco PF63, Fram XG10575, and Mobil 1 M1-110A for EcoBoost engines.
Conclusion
The Lincoln Navigator L requires specific oil capacities and viscosities depending on engine type and model year. Models from 2015-present with 3.5L EcoBoost engines use 6.0 quarts of SAE 5W-30 full synthetic oil, while earlier V8 models require 6.0 to 6.6 quarts of 5W-20 or 5W-30 oil.
Using manufacturer-approved oil specifications and following recommended change intervals protects engine components and maintains warranty coverage. Always verify specifications in your owner’s manual and use quality oil filters meeting Ford standards for optimal engine protection.
