The Mazda CX-5 has been produced from 2013 to present with multiple engine options across two generations. Using the correct oil capacity, viscosity, and type is essential for maintaining engine performance and longevity. This guide lists all model years with full oil specifications and maintenance recommendations.
Mazda CX-5 models require between 4.2 and 5.1 quarts of full synthetic oil depending on the engine configuration. The first generation (2013-2016) offered 2.0L and 2.5L naturally aspirated engines, while the second generation (2017-2025) features 2.5L naturally aspirated and turbocharged options
Quick Navigation
2025 Mazda CX-5 Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
The 2025 Mazda CX-5 uses a SKYACTIV-G 2.5L naturally aspirated engine that requires 4.8 quarts of full synthetic oil with filter replacement. Using SAE 0W-20 oil provides optimal protection and fuel efficiency under normal driving conditions.
2024 Mazda CX-5 Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
The 2024 Mazda CX-5 with the 2.5L engine requires 4.8 quarts of SAE 0W-20 full synthetic oil when changing the oil filter. This viscosity provides excellent cold start protection and maintains proper lubrication at operating temperature.
2023 Mazda CX-5 Engine Oil Capacity
Non-Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5T I4 Turbo |
| Oil Capacity (with Filter) | 5.1 qt (4.8 L) |
| Oil Capacity (without Filter) | 4.8 qt (4.5 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPY-14-302, Fram XG6607, Purolator PBL14612 |
The 2023 Mazda CX-5 requires different oil specifications based on engine type. The turbocharged 2.5T engine uses 5.1 quarts of SAE 5W-30 full synthetic oil, while the naturally aspirated 2.5L requires 4.8 quarts of SAE 0W-20.
2022 Mazda CX-5 Engine Oil Capacity
Non-Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5T I4 Turbo |
| Oil Capacity (with Filter) | 5.1 qt (4.8 L) |
| Oil Capacity (without Filter) | 4.8 qt (4.5 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPY-14-302, Fram XG6607, Purolator PBL14612 |
The 2022 Mazda CX-5 engine oil capacity is 5.1 quarts for the SKYACTIV-G 2.5T turbo engine and 4.8 quarts for the standard 2.5L engine. Both engines require API certified full synthetic oil.
2021 Mazda CX-5 Engine Oil Capacity
Non-Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5T I4 Turbo |
| Oil Capacity (with Filter) | 5.1 qt (4.8 L) |
| Oil Capacity (without Filter) | 4.8 qt (4.5 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPY-14-302, Fram XG6607, Purolator PBL14612 |
The 2021 Mazda CX-5 non-turbo engine holds 4.8 quarts of 0W-20 synthetic oil with filter, while the turbo variant requires 5.1 quarts of 5W-30 synthetic oil. The heavier viscosity for the turbo engine provides better protection under high heat and pressure.
2020 Mazda CX-5 Engine Oil Capacity
Non-Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5T I4 Turbo |
| Oil Capacity (with Filter) | 5.1 qt (4.8 L) |
| Oil Capacity (without Filter) | 4.8 qt (4.5 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPY-14-302, Fram XG6607, Purolator PBL14612 |
The 2020 Mazda CX-5 uses 4.8 quarts for the base 2.5L engine and 5.1 quarts for the 2.5T turbo engine. Full synthetic oil is required for both engine variants to meet manufacturer specifications.
2019 Mazda CX-5 Engine Oil Capacity
Non-Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
Turbo Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5T I4 Turbo |
| Oil Capacity (with Filter) | 5.1 qt (4.8 L) |
| Oil Capacity (without Filter) | 4.8 qt (4.5 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPY-14-302, Fram XG6607, Purolator PBL14612 |
The 2019 Mazda CX-5 marked the introduction of the turbocharged 2.5T engine requiring 5.1 quarts of 5W-30 oil. The naturally aspirated 2.5L continues with 4.8 quarts of 0W-20 synthetic oil.
2018 Mazda CX-5 Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
The 2018 Mazda CX-5 uses a single 2.5L engine option that requires 4.8 quarts of SAE 0W-20 full synthetic oil. This second-generation model requires API certified oil for proper engine protection.
2017 Mazda CX-5 Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
The 2017 Mazda CX-5 began the second generation with a 2.5L SKYACTIV-G engine requiring 4.8 quarts of 0W-20 synthetic oil. The oil drain plug torque specification is 23 to 30 lb-ft.
2016 Mazda CX-5 Engine Oil Capacity
2.5L Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
2.0L Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.0L I4 |
| Oil Capacity (with Filter) | 4.4 qt (4.2 L) |
| Oil Capacity (without Filter) | 4.2 qt (4.0 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
The 2016 Mazda CX-5 offers two engine options with different oil capacities. The 2.5L engine requires 4.8 quarts while the 2.0L engine needs 4.4 quarts of 0W-20 synthetic oil with filter replacement.
2015 Mazda CX-5 Engine Oil Capacity
2.5L Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
2.0L Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.0L I4 |
| Oil Capacity (with Filter) | 4.4 qt (4.2 L) |
| Oil Capacity (without Filter) | 4.2 qt (4.0 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
The 2015 Mazda CX-5 requires between 4.4 and 4.8 quarts of 0W-20 synthetic oil depending on engine size. Both engines use identical viscosity specifications for optimal fuel economy and protection.
2014 Mazda CX-5 Engine Oil Capacity
2.5L Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
2.0L Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.0L I4 |
| Oil Capacity (with Filter) | 4.4 qt (4.2 L) |
| Oil Capacity (without Filter) | 4.2 qt (4.0 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
The 2014 Mazda CX-5 with the 2.5L engine holds 4.8 quarts of oil, while the 2.0L version requires 4.4 quarts. Both engines use SAE 0W-20 full synthetic oil meeting API SN or higher specifications.
2013 Mazda CX-5 Engine Oil Capacity
2.5L Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.5L I4 |
| Oil Capacity (with Filter) | 4.8 qt (4.5 L) |
| Oil Capacity (without Filter) | 4.5 qt (4.2 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
2.0L Engine
| Specification | Detail |
|---|---|
| Engine | SKYACTIV-G 2.0L I4 |
| Oil Capacity (with Filter) | 4.4 qt (4.2 L) |
| Oil Capacity (without Filter) | 4.2 qt (4.0 L) |
| Recommended Oil Type | Full Synthetic |
| Viscosity | SAE 0W-20 |
| Oil Change Interval | Every 7,500 miles or 12 months |
| Oil Drain Plug Torque | 23-30 lb-ft (30-41 N·m) |
| Recommended Filters | 1WPE-14-302, Fram XG6607, Purolator PBL14612 |
The 2013 Mazda CX-5 launched with two SKYACTIV-G engine options requiring 4.4 or 4.8 quarts of 0W-20 synthetic oil. The first generation CX-5 established the oil capacity standards that continue through later model years.
Oil Maintenance and Service Tips
Checking Engine Oil Level
Check engine oil level when the engine is warm and the vehicle is on level ground. Remove the dipstick, wipe it clean, reinsert it fully, then check the level on the second reading. The oil level should be between the minimum and maximum marks.
Oil Change Intervals
Normal driving conditions require oil changes every 7,500 miles or 12 months, whichever comes first. Severe driving conditions include frequent short trips, extensive idling, dusty environments, trailer towing, and extreme temperatures. Under severe conditions, reduce the oil change interval to 5,000 miles or 6 months.
Selecting the Right Oil
Use only full synthetic oil that meets API SP, SN, or SM specifications and ILSAC GF-5 or GF-6A standards. The oil must display the API certification mark to ensure proper engine protection and warranty compliance. Mazda Genuine Oil is recommended but equivalent branded synthetics meeting specifications are acceptable.
Oil Filter Replacement
Replace the oil filter with every oil change using OEM or equivalent quality filters. For non-turbo engines, use filter part number 1WPE-14-302 or equivalents like Fram XG6607. For turbo engines, use part number 1WPY-14-302 or equivalent aftermarket filters. The oil filter should be hand-tightened after the gasket contacts the mounting surface.
Oil Drain Plug Service
The oil drain plug requires a 17mm socket and should be torqued to 23-30 lb-ft or 30-41 N·m. Replace the drain plug washer at each oil change to prevent leaks. The M14 washer is designed for single use and ensures proper sealing.
Frequently Asked Questions
What kind of oil does a Mazda CX-5 use?
All Mazda CX-5 models require full synthetic motor oil meeting API SP, SN, or SM specifications and ILSAC GF-5 or GF-6A standards. Non-turbo engines use SAE 0W-20 viscosity, while turbocharged engines require SAE 5W-30. Conventional or synthetic blend oils are not approved for SKYACTIV engines.
How much oil does a Mazda CX-5 take?
The Mazda CX-5 oil capacity ranges from 4.4 to 5.1 quarts depending on engine type. The 2.0L engine holds 4.4 quarts, the 2.5L naturally aspirated engine requires 4.8 quarts, and the 2.5T turbo engine needs 5.1 quarts with filter replacement. These capacities include the oil filter change.
What is the recommended oil type for a Mazda CX-5?
Mazda requires full synthetic oil for all CX-5 engines to provide adequate protection for high-compression SKYACTIV technology. The oil must meet API certification standards SP, SN, or SM and ILSAC requirements GF-5 or GF-6A. Mazda Genuine Oil is recommended but equivalent synthetic oils meeting these specifications are acceptable.
What is the oil change interval for a Mazda CX-5?
Under normal driving conditions, change the engine oil and filter every 7,500 miles or 12 months. For severe driving conditions including short trips, frequent idling, dusty roads, trailer towing, or extreme temperatures, reduce the interval to 5,000 miles or 6 months. Always reset the oil life monitor after each oil change.
Can I use 5W-30 oil in a non-turbo Mazda CX-5?
Non-turbo Mazda CX-5 engines are designed for SAE 0W-20 oil and should not use 5W-30 viscosity. The SKYACTIV-G engines have tight tolerances optimized for low-viscosity oil to improve fuel economy and cold-start protection. Using incorrect viscosity may affect fuel economy and engine protection. Only turbocharged CX-5 models require 5W-30 oil.
What oil filter fits a Mazda CX-5?
For non-turbo CX-5 models, use OEM filter 1WPE-14-302 or equivalent aftermarket filters like Fram XG6607 or Purolator PBL14612. Turbo models require filter 1WPY-14-302 or equivalent performance filters. The oil filter should be replaced at every oil change for optimal engine protection.
Conclusion
Maintaining the correct engine oil capacity, type, and viscosity is critical for Mazda CX-5 reliability and performance. Non-turbo models require 4.4 to 4.8 quarts of SAE 0W-20 full synthetic oil, while turbocharged versions need 5.1 quarts of SAE 5W-30. Always use oil meeting API SP, SN, or SM specifications and ILSAC GF-5 or GF-6A standards to ensure proper engine protection. Follow the recommended oil change interval of 7,500 miles under normal conditions or 5,000 miles under severe driving conditions. Using manufacturer-approved oil specifications and maintaining regular service intervals will maximize engine longevity and maintain optimal fuel efficiency.
