The Mitsubishi Raider was produced from 2006 to 2009 as a mid-size pickup truck based on the Dodge Dakota platform. Two engine options were available: a 3.7L V6 and a 4.7L V8, with the V8 discontinued after the 2007 model year. Using the correct oil capacity, viscosity, and type is essential for maintaining engine performance and longevity.
This guide provides complete oil specifications for all Mitsubishi Raider model years, including capacities, recommended viscosity grades, and maintenance intervals.
Quick Navigation
2009 Mitsubishi Raider Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.7L PowerTech V6 SOHC |
| Oil Capacity (with Filter) | 5.0 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic or Synthetic Blend |
| Viscosity | SAE 5W-20 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 25 lb-ft (34 N·m) |
| Recommended Filters | Mopar 5281090AB, Mopar 5038041AA, K&N HP-1004, Denso |
The 2009 Mitsubishi Raider uses a 3.7L V6 engine that requires 5.0 quarts of SAE 5W-20 oil with filter replacement. This was the final production year for the Raider, with only the V6 engine available.
2008 Mitsubishi Raider Engine Oil Capacity
| Specification | Detail |
|---|---|
| Engine | 3.7L PowerTech V6 SOHC |
| Oil Capacity (with Filter) | 5.0 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic or Synthetic Blend |
| Viscosity | SAE 5W-20 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 25 lb-ft (34 N·m) |
| Recommended Filters | Mopar 5281090AB, Mopar 5038041AA, K&N HP-1004, Denso |
The 2008 Mitsubishi Raider was equipped exclusively with the 3.7L V6 engine requiring 5.0 quarts of SAE 5W-20 oil. The engine uses reduced-tension piston rings and 5W-20 oil to reduce friction and improve fuel economy.
2007 Mitsubishi Raider Engine Oil Capacity
3.7L V6 Engine
| Specification | Detail |
|---|---|
| Engine | 3.7L PowerTech V6 SOHC |
| Oil Capacity (with Filter) | 5.0 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic or Synthetic Blend |
| Viscosity | SAE 5W-20 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 25 lb-ft (34 N·m) |
| Recommended Filters | Mopar 5281090AB, Mopar 5038041AA, K&N HP-1004 |
The 2007 Mitsubishi Raider with the 3.7L V6 requires 5.0 quarts of SAE 5W-20 oil meeting Chrysler Material Standard MS-6395. This engine produces 210 horsepower at 5,200 rpm and features sequential multi-port fuel injection.
4.7L V8 Engine
| Specification | Detail |
|---|---|
| Engine | 4.7L PowerTech V8 SOHC |
| Oil Capacity (with Filter) | 5.9 quarts (5.6 liters) |
| Oil Capacity (without Filter) | 5.4 quarts (5.1 liters) |
| Recommended Oil Type | Full Synthetic or Synthetic Blend |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 25 lb-ft (34 N·m) |
| Recommended Filters | Mopar 5281090AB, Mopar 5038041AA |
The 2007 Mitsubishi Raider with the 4.7L V8 engine requires 5.9 quarts of SAE 5W-30 oil. This was the final year for the V8 engine option, which produced 230 horsepower at 4,600 rpm and 290 lb-ft of torque.
2006 Mitsubishi Raider Engine Oil Capacity
3.7L V6 Engine
| Specification | Detail |
|---|---|
| Engine | 3.7L PowerTech V6 SOHC |
| Oil Capacity (with Filter) | 5.0 quarts (4.7 liters) |
| Oil Capacity (without Filter) | 4.5 quarts (4.3 liters) |
| Recommended Oil Type | Full Synthetic or Synthetic Blend |
| Viscosity | SAE 5W-20 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 25 lb-ft (34 N·m) |
| Recommended Filters | Mopar 5281090AB, Mopar 5038041AA, K&N HP-1004 |
The 2006 Mitsubishi Raider debuted with a 3.7L V6 engine requiring 5.0 quarts of SAE 5W-20 oil. The engine features a cast iron block with aluminum cylinder heads and a 9.7:1 compression ratio.
4.7L V8 Engine
| Specification | Detail |
|---|---|
| Engine | 4.7L PowerTech V8 SOHC |
| Oil Capacity (with Filter) | 5.9 quarts (5.6 liters) |
| Oil Capacity (without Filter) | 5.4 quarts (5.1 liters) |
| Recommended Oil Type | Full Synthetic or Synthetic Blend |
| Viscosity | SAE 5W-30 |
| Oil Change Interval | Every 7,500 miles or 6 months |
| Oil Drain Plug Torque | 25 lb-ft (34 N·m) |
| Recommended Filters | Mopar 5281090AB, Mopar 5038041AA |
The 2006 Mitsubishi Raider with the 4.7L V8 holds 5.9 quarts of SAE 5W-30 oil when the filter is replaced. This V8 engine features a 90-degree configuration with cast iron block and produces 230 horsepower and 290 lb-ft of torque.
Oil Maintenance and Service Tips
Oil Change Intervals
The Mitsubishi Raider follows a maintenance schedule based on 7,500-mile or 6-month intervals, whichever comes first. Each service includes engine oil and oil filter replacement along with tire rotation. Under severe driving conditions such as frequent short trips, dusty environments, or towing heavy loads, oil changes should be performed more frequently at 3,000 to 5,000-mile intervals.
Checking Oil Level
Check engine oil level when the engine is cold and parked on level ground. Remove the dipstick, wipe it clean, reinsert it fully, then remove it again to read the level. The oil level should be between the minimum and maximum marks on the dipstick. Add oil in small amounts if the level is low, checking frequently to avoid overfilling.
Oil Type and Specifications
Use API-certified engine oil meeting Chrysler Material Standard MS-6395 for both the 3.7L V6 and 4.7L V8 engines. Full synthetic or synthetic blend oils provide superior protection and performance compared to conventional oils. The Raider’s oil filter includes a drip trough design to prevent oil from running onto chassis components during filter changes.
Drain Plug Torque
Always torque the oil drain plug to 25 lb-ft (34 N·m) to prevent leaks and avoid stripping the threads. Replace the drain plug washer or gasket at each oil change to ensure a proper seal. Use a calibrated torque wrench for accurate tightening specifications.
Frequently Asked Questions
What kind of oil does a Mitsubishi Raider use?
The Mitsubishi Raider uses API-certified engine oil meeting Chrysler Material Standard MS-6395. The 3.7L V6 engine requires SAE 5W-20 viscosity, while the 4.7L V8 uses SAE 5W-30. Full synthetic or synthetic blend oils are recommended for optimal engine protection and performance.
How much oil does a Mitsubishi Raider take?
The Mitsubishi Raider with a 3.7L V6 engine takes 5.0 quarts (4.7 liters) of oil with a new filter. Models equipped with the 4.7L V8 engine require 5.9 quarts (5.6 liters) of oil when the filter is replaced. Without a filter change, capacities are approximately 0.5 quarts less.
What is the recommended oil change interval for a Mitsubishi Raider?
The recommended oil change interval for the Mitsubishi Raider is every 7,500 miles or 6 months, whichever occurs first. Under severe driving conditions such as frequent short trips, dusty roads, or heavy towing, more frequent oil changes at 3,000 to 5,000-mile intervals are advisable.
What viscosity oil should I use in my Mitsubishi Raider?
Use SAE 5W-20 viscosity oil for the 3.7L V6 engine in all model years. The 4.7L V8 engine requires SAE 5W-30 viscosity oil. These viscosity grades provide the right balance of engine protection and fuel efficiency under normal operating temperatures.
Can I use synthetic oil in my Mitsubishi Raider?
Yes, synthetic oil is recommended for the Mitsubishi Raider and provides superior protection compared to conventional oil. Both the 3.7L V6 and 4.7L V8 engines benefit from full synthetic or synthetic blend oils that meet API certification and Chrysler MS-6395 specifications. Synthetic oil offers better high-temperature stability and cold-start protection.
What is the oil drain plug torque for a Mitsubishi Raider?
The oil drain plug torque specification for all Mitsubishi Raider models is 25 lb-ft (34 N·m). Always use a calibrated torque wrench to tighten the drain plug to the correct specification. Replace the drain plug washer or gasket at each oil change to prevent leaks.
Conclusion
The Mitsubishi Raider requires proper engine oil specifications to maintain reliable performance throughout its service life. The 3.7L V6 engine uses 5.0 quarts of SAE 5W-20 oil, while the 4.7L V8 requires 5.9 quarts of SAE 5W-30 oil when the filter is replaced. Following the manufacturer-approved oil change interval of 7,500 miles or 6 months helps protect internal engine components and ensures optimal lubrication. Using quality API-certified oil meeting Chrysler MS-6395 specifications and maintaining proper service intervals will maximize engine longevity and performance.
