The Ram 1500 is a full-size, half-ton pickup truck produced by Ram Trucks, a division of Stellantis. It has been offered under the Dodge Ram and Ram nameplates continuously from 2002 through the current model year, in Regular Cab, Quad Cab, and Crew Cab body styles.
Towing capacity varies depending on engine choice, drivetrain configuration, axle ratio, cab style, and installed equipment packages. This guide covers Ram 1500 towing specifications by model year, including maximum trailer weight, payload capacity, GCWR, tongue weight limits, and hitch class requirements. Following manufacturer-rated towing limits helps protect the engine, transmission, brakes, and frame from overload damage.
Quick Navigation
2025 Ram 1500 Towing Capacity
The 2025 model year introduced a revised engine lineup, replacing the 5.7L HEMI V-8 with twin-turbocharged inline-six options.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6; 3.0L Hurricane I-6 (twin-turbo); 3.0L Hurricane I-6 High-Output (twin-turbo) |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 11,550 lbs (5,239 kg) |
| Conventional Towing Capacity | Up to 11,550 lbs (5,239 kg) with 3.0L Hurricane I-6 |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 2,370 lbs (1,075 kg) with 3.6L V-6 |
| Gross Combined Weight Rating (GCWR) | Up to 17,000 lbs (7,711 kg) est. when properly equipped |
| Tongue Weight Limit | Up to 1,155 lbs (524 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2025 Ram 1500 reaches its maximum towing capacity of 11,550 lbs when equipped with the standard-output 3.0L Hurricane I-6 engine and proper tow package. The High-Output version of the same engine produces 540 horsepower but is rated for up to 9,920 lbs of towing due to different calibration priorities. The 3.6L Pentastar V-6 delivers the highest payload at 2,370 lbs but is limited to 8,110 lbs of trailer weight.
2024 Ram 1500 Towing Capacity
The 2024 model was the last year to offer the 5.7L HEMI V-8 as a primary engine option, producing a maximum towing capacity of 12,750 lbs.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6; 5.7L HEMI V-8; 6.2L Supercharged HEMI V-8 (TRX) |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 12,750 lbs (5,783 kg) |
| Conventional Towing Capacity | Up to 12,750 lbs (5,783 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 2,370 lbs (1,075 kg) with 3.6L V-6 |
| Gross Combined Weight Rating (GCWR) | Up to 18,200 lbs (8,255 kg) est. when properly equipped |
| Tongue Weight Limit | Up to 1,275 lbs (578 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2024 Ram 1500 equipped with the 5.7L HEMI V-8 and factory tow package achieves the rated maximum of 12,750 lbs. The 3.6L Pentastar V-6 is limited to 8,110 lbs of towing in its standard configuration. The 6.2L Supercharged HEMI V-8, used in the Ram TRX, is not recommended for conventional towing by the manufacturer.
2023 Ram 1500 Towing Capacity
The 2023 Ram 1500 carries over the same powertrain and towing ratings from the prior generation, maintaining the 12,750 lb maximum.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6 with eTorque; 5.7L HEMI V-8; 5.7L HEMI V-8 with eTorque |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 12,750 lbs (5,783 kg) |
| Conventional Towing Capacity | Up to 12,750 lbs (5,783 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 2,300 lbs (1,043 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 18,200 lbs (8,255 kg) est. |
| Tongue Weight Limit | Up to 1,275 lbs (578 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2023 Ram 1500 with the 5.7L HEMI V-8 and eTorque mild-hybrid system achieves up to 12,750 lbs when properly configured with the factory tow package. The eTorque system adds torque-fill assistance that benefits launch and low-speed trailer control. Configurations with smaller axle ratios or larger wheel/tire packages will produce lower towing ratings.
2022 Ram 1500 Towing Capacity
The 2022 Ram 1500 shares its platform and towing ratings with the fifth-generation DS body introduced in 2019.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6 with eTorque; 5.7L HEMI V-8; 5.7L HEMI V-8 with eTorque; 3.0L EcoDiesel V-6 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 12,750 lbs (5,783 kg) |
| Conventional Towing Capacity | Up to 12,750 lbs (5,783 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 2,300 lbs (1,043 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 18,200 lbs (8,255 kg) est. |
| Tongue Weight Limit | Up to 1,275 lbs (578 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2022 Ram 1500 can tow a maximum of 12,750 lbs with the 5.7L HEMI V-8 and tow package installed. The 3.0L EcoDiesel V-6 option provides competitive diesel torque output suitable for sustained trailer towing at highway speeds. Rear axle ratio selection between 3.21, 3.55, and 3.92 directly determines the final towing capacity figure for each configuration.
2021 Ram 1500 Towing Capacity
The 2021 Ram 1500 continues on the fifth-generation platform with the same maximum towing rating of 12,750 lbs.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6 with eTorque; 5.7L HEMI V-8; 5.7L HEMI V-8 with eTorque; 3.0L EcoDiesel V-6 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 12,750 lbs (5,783 kg) |
| Conventional Towing Capacity | Up to 12,750 lbs (5,783 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 2,300 lbs (1,043 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 18,200 lbs (8,255 kg) est. |
| Tongue Weight Limit | Up to 1,275 lbs (578 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2021 Ram 1500 with the 5.7L HEMI V-8 eTorque and factory tow package produces the maximum trailer weight rating of 12,750 lbs in 4×2 Quad Cab configuration. The 3.6L V-6 eTorque upgrade provides towing in the 7,730 lb range with a 2,100 lb payload limit. Selecting 4×4 drivetrain reduces the maximum towing capacity by several hundred pounds due to added driveline weight.
2020 Ram 1500 Towing Capacity
The 2020 Ram 1500 is structurally identical to the 2019 fifth-generation refresh and carries the same maximum towing figures.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6 with eTorque; 5.7L HEMI V-8; 5.7L HEMI V-8 with eTorque; 3.0L EcoDiesel V-6 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 12,750 lbs (5,783 kg) |
| Conventional Towing Capacity | Up to 12,750 lbs (5,783 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 2,100 lbs (953 kg) with 3.6L V-6 |
| Gross Combined Weight Rating (GCWR) | Up to 18,200 lbs (8,255 kg) est. |
| Tongue Weight Limit | Up to 1,275 lbs (578 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2020 Ram 1500 towing capacity reaches 12,750 lbs when the 5.7L HEMI V-8 with eTorque is paired with a premium axle ratio and factory tow package. The top 4×2 Tradesman Quad Cab configuration in 2020 delivers this maximum figure and is among the most capable configurations in this generation. All payload and trailer weight ratings are mutually exclusive, meaning combined cargo plus trailer tongue weight must not exceed GVWR.
2019 Ram 1500 Towing Capacity
The 2019 model year introduced the fifth-generation Ram 1500, replacing the fourth-generation DS body with an all-new platform.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6 with eTorque; 5.7L HEMI V-8; 5.7L HEMI V-8 with eTorque; 3.0L EcoDiesel V-6 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 12,750 lbs (5,783 kg) |
| Conventional Towing Capacity | Up to 12,750 lbs (5,783 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 2,100 lbs (953 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 18,200 lbs (8,255 kg) est. |
| Tongue Weight Limit | Up to 1,275 lbs (578 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2019 Ram 1500 marks a generational jump in towing capability, raising the maximum from the prior generation’s 10,640 lbs to 12,750 lbs. The introduction of eTorque mild-hybrid technology on both the V-6 and V-8 engines improved low-speed torque output relevant to trailer launch and grade climbing. Configurations without the premium axle ratio or tow package produce significantly lower ratings.
2018 Ram 1500 Towing Capacity
The 2018 Ram 1500 is the last model year of the fourth-generation DS platform before the complete redesign for 2019.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6; 5.7L HEMI V-8; 3.0L EcoDiesel V-6 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,640 lbs (4,826 kg) |
| Conventional Towing Capacity | Up to 10,640 lbs (4,826 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,900 lbs (862 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,750 lbs (6,691 kg) with EcoDiesel |
| Tongue Weight Limit | Up to 1,064 lbs (482 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2018 Ram 1500 achieves its maximum towing limit of 10,640 lbs with the 5.7L HEMI V-8, Regular Cab Long Bed, 2WD, and 3.92 axle ratio. The 3.0L EcoDiesel V-6 reaches up to 9,210 lbs in specific 2WD Regular Cab Long Bed configurations with a GCWR of 14,750 lbs. Crew Cab and 4WD configurations produce lower maximum figures than Regular Cab 2WD setups.
2017 Ram 1500 Towing Capacity
The 2017 Ram 1500 carries the same powertrain and towing ratings as the 2018 model year with minor trim differences.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6; 5.7L HEMI V-8; 3.0L EcoDiesel V-6 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,640 lbs (4,826 kg) |
| Conventional Towing Capacity | Up to 10,640 lbs (4,826 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,880 lbs (853 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,750 lbs (6,691 kg) est. with EcoDiesel |
| Tongue Weight Limit | Up to 1,064 lbs (482 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2017 Ram 1500 maximum towing capacity of 10,640 lbs is achieved with the 5.7L HEMI V-8 in Regular Cab Long Bed 2WD with 3.92 axle ratio. The EcoDiesel V-6 continues to be available for buyers requiring consistent torque output on long grades with heavy trailers. Wheel size and tire load rating directly affect the final rated trailer weight for each specific build.
2016 Ram 1500 Towing Capacity
The 2016 Ram 1500 is part of the fourth-generation DS platform, offering three engine options and a maximum towing limit of 10,390 lbs.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6; 5.7L HEMI V-8; 3.0L EcoDiesel V-6 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,390 lbs (4,713 kg) |
| Conventional Towing Capacity | Up to 10,390 lbs (4,713 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,870 lbs (848 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,550 lbs (6,600 kg) est. |
| Tongue Weight Limit | Up to 1,039 lbs (471 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2016 Ram 1500 reaches a maximum of 10,390 lbs in Quad Cab 2WD configuration with the 5.7L HEMI V-8 and 3.92 axle ratio. The 3.0L EcoDiesel provides a GCWR of 14,550 lbs in specific configurations, which limits the maximum trailer weight when combined with a heavier truck weight. Ratings decrease with larger cab sizes, 4WD drivetrain, and lower axle ratios.
2015 Ram 1500 Towing Capacity
The 2015 Ram 1500 continues on the fourth-generation platform with three engine choices and a maximum tow rating of 10,650 lbs.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6; 5.7L HEMI V-8; 3.0L EcoDiesel V-6 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,650 lbs (4,831 kg) |
| Conventional Towing Capacity | Up to 10,650 lbs (4,831 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,910 lbs (867 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,550 lbs (6,600 kg) est. |
| Tongue Weight Limit | Up to 1,065 lbs (483 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2015 Ram 1500 maximum towing capacity of 10,650 lbs is achievable with the 5.7L HEMI V-8 in a Regular Cab Long Bed 2WD with 6-speed automatic and 3.92 axle ratio. The 3.0L EcoDiesel V-6 was available in long bed configurations and reaches up to 9,200 lbs in 2WD. The 3.6L V-6 in short bed configurations is limited to around 7,480 lbs maximum in optimized setups.
2014 Ram 1500 Towing Capacity
The 2014 Ram 1500 introduced the 3.0L EcoDiesel V-6 to the lineup, providing a diesel towing option in the half-ton segment for the first time in this generation.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6; 5.7L HEMI V-8; 3.0L EcoDiesel V-6 (new) |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,450 lbs (4,740 kg) |
| Conventional Towing Capacity | Up to 10,450 lbs (4,740 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,880 lbs (853 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,550 lbs (6,600 kg) est. |
| Tongue Weight Limit | Up to 1,045 lbs (474 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2014 Ram 1500 achieves 10,450 lbs of maximum towing with the 5.7L HEMI V-8, 8-speed automatic, Regular Cab Long Bed, 2WD, and 3.92 axle ratio. The new 3.0L EcoDiesel V-6 in Regular Cab Long Bed 2WD configuration was capable of up to 9,200 lbs with the 3.92 axle ratio. The 3.6L V-6 maxes out at approximately 7,400 lbs in the most favorable configuration.
2013 Ram 1500 Towing Capacity
The 2013 Ram 1500 introduced the 8-speed automatic transmission on the 3.6L V-6 and updated the powertrain across the lineup for improved towing performance.
| Specification | Detail |
|---|---|
| Engine Options | 3.6L Pentastar V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,450 lbs (4,740 kg) |
| Conventional Towing Capacity | Up to 10,450 lbs (4,740 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,840 lbs (835 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,550 lbs (6,600 kg) est. |
| Tongue Weight Limit | Up to 1,045 lbs (474 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2013 Ram 1500 with the 5.7L HEMI V-8, 6-speed automatic, Regular Cab Long Bed, 2WD, and 3.92 axle ratio achieves a maximum towing capacity of 10,450 lbs. The 4.7L V-8 reaches 7,700 lbs in specific Regular Cab 2WD configurations. The 3.6L V-6 paired with the 8-speed automatic and 3.55 axle reaches up to 6,500 lbs in optimal conditions.
2012 Ram 1500 Towing Capacity
The 2012 Ram 1500 is a continuation of the third-generation DS body, sharing its powertrain with the 2011 model with minimal changes.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,450 lbs (4,740 kg) |
| Conventional Towing Capacity | Up to 10,450 lbs (4,740 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,800 lbs (816 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,400 lbs (6,532 kg) est. |
| Tongue Weight Limit | Up to 1,045 lbs (474 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2012 Ram 1500 with the 5.7L HEMI V-8, 5-speed automatic, Regular Cab Long Bed, 2WD, and 3.92 axle ratio achieves up to 10,450 lbs maximum towing capacity. The 4.7L V-8 with 5-speed automatic reaches 7,600 lbs in Regular Cab short bed 2WD. The 3.7L V-6 is limited to approximately 3,750 lbs due to its lower torque output.
2011 Ram 1500 Towing Capacity
The 2011 Ram 1500 continues on the DS platform with powertrains carried over from 2010, with minor calibration updates.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,450 lbs (4,740 kg) |
| Conventional Towing Capacity | Up to 10,450 lbs (4,740 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,780 lbs (807 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,400 lbs (6,532 kg) est. |
| Tongue Weight Limit | Up to 1,045 lbs (474 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2011 Ram 1500 maximum towing capacity of 10,450 lbs is produced by the 5.7L HEMI V-8 in Regular Cab Long Bed 2WD with the 3.92 axle ratio. The 4.7L V-8 with the 5-speed automatic in Regular Cab short bed 2WD reaches up to 7,600 lbs. The R/T model, while carrying the 5.7L V-8, is rated for only 5,000 lbs due to its performance-oriented 4.10 axle ratio setup.
2010 Ram 1500 Towing Capacity
The 2010 Ram 1500 is the second model year after the brand separated from Dodge, rebranding as Ram Trucks.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 10,450 lbs (4,740 kg) |
| Conventional Towing Capacity | Up to 10,450 lbs (4,740 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,750 lbs (794 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 14,400 lbs (6,532 kg) est. |
| Tongue Weight Limit | Up to 1,045 lbs (474 kg) |
| Hitch Class | Class IV |
| Factory Tow Package | Optional |
The 2010 Ram 1500 achieves a maximum tow rating of 10,450 lbs with the 5.7L HEMI V-8 in Regular Cab Long Bed 2WD with 3.92 axle ratio. The 4.7L V-8 with 5-speed automatic reaches 7,650 lbs in Regular Cab short bed 2WD with a 3.92 axle. The base 3.7L V-6 with the 4-speed automatic produces a maximum of only 3,800 lbs, which is suitable for light utility trailers only.
2009 Ram 1500 Towing Capacity
The 2009 Dodge Ram 1500 is the third-generation DS body, the last year branded as a Dodge before the Ram nameplate became independent.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 9,100 lbs (4,128 kg) |
| Conventional Towing Capacity | Up to 9,100 lbs (4,128 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,430 lbs (649 kg) |
| Gross Combined Weight Rating (GCWR) | Up to 13,500 lbs (6,124 kg) est. |
| Tongue Weight Limit | Up to 910 lbs (413 kg) |
| Hitch Class | Class III / IV |
| Factory Tow Package | Optional |
The 2009 Dodge Ram 1500 reaches its maximum towing capacity of 9,100 lbs with the 5.7L HEMI V-8, 5-speed automatic, Regular Cab short bed 2WD, and 3.92 axle ratio. The 4.7L V-8 in the same cab/drivetrain configuration reaches 7,650 lbs. The 3.7L V-6 produces a maximum of 3,800 lbs and is not suitable for trailers heavier than a small utility or boat trailer.
2008 Dodge Ram 1500 Towing Capacity
The 2008 Dodge Ram 1500 is a second-generation DS body with carryover powertrains from the 2007 model year.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 7,900 lbs (3,583 kg) |
| Conventional Towing Capacity | Up to 7,900 lbs (3,583 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,700 lbs (771 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 12,700 lbs (5,760 kg) est. |
| Tongue Weight Limit | Up to 790 lbs (358 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2008 Dodge Ram 1500 towing capacity ranges from 5,050 lbs to 7,900 lbs depending on engine and configuration. The 5.7L HEMI V-8 delivers the highest figures in the lineup for this model year. Payload capacity in this generation was more restricted compared to later redesigns, at an estimated maximum of 1,700 lbs.
2007 Dodge Ram 1500 Towing Capacity
The 2007 Dodge Ram 1500 represents the third-generation body style with no major powertrain changes from 2006.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 7,600 lbs (3,447 kg) |
| Conventional Towing Capacity | Up to 7,600 lbs (3,447 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,680 lbs (762 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 12,500 lbs (5,670 kg) est. |
| Tongue Weight Limit | Up to 760 lbs (345 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2007 Dodge Ram 1500 towing capacity ranges from 2,900 lbs with the base V-6 to 7,600 lbs with the 5.7L HEMI V-8 in the most capable configuration. The base 3.7L V-6 with a manual transmission produces the lowest figures in the lineup. Properly equipped 5.7L HEMI configurations with 4-speed or 5-speed automatics and higher axle ratios produce the maximum towing capacity.
2006 Dodge Ram 1500 Towing Capacity
The 2006 Dodge Ram 1500 continues the second-generation DR/DH platform with incremental updates.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 6,750 lbs (3,062 kg) |
| Conventional Towing Capacity | Up to 6,750 lbs (3,062 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,650 lbs (748 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 12,000 lbs (5,443 kg) est. |
| Tongue Weight Limit | Up to 675 lbs (306 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2006 Dodge Ram 1500 maximum towing capacity of 6,750 lbs is reached with the 5.7L HEMI V-8 in the most favorable configuration. The base 3.7L V-6 in this model year produces a minimum towing figure of approximately 2,900 lbs, appropriate only for very light trailers. Trailer brakes are strongly recommended for any load over 3,000 lbs in this generation.
2005 Dodge Ram 1500 Towing Capacity
The 2005 Dodge Ram 1500 is an early model within the second-generation DR/DH body introduced in 2002, featuring limited towing ratings compared to later variants.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 4,350 lbs (1,973 kg) |
| Conventional Towing Capacity | Up to 4,350 lbs (1,973 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,620 lbs (735 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 10,000 lbs (4,536 kg) est. |
| Tongue Weight Limit | Up to 435 lbs (197 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2005 Dodge Ram 1500 towing capacity ranges from 3,400 lbs to 4,350 lbs depending on engine and configuration. These figures are lower than later generations due to different platform and rating methodology standards in use at that time. Always confirm 2005 specifications against the specific vehicle’s door placard and owner’s manual.
2004 Dodge Ram 1500 Towing Capacity
The 2004 Dodge Ram 1500 belongs to the second-generation DR/DH body platform with manufacturer towing ratings consistent with early 2000s half-ton standards.
| Specification | Detail |
|---|---|
| Engine Options | 3.7L V-6; 4.7L V-8; 5.7L HEMI V-8 |
| Drivetrain | 2WD (4×2) or 4WD (4×4) |
| Maximum Towing Capacity | 4,750 lbs (2,155 kg) |
| Conventional Towing Capacity | Up to 4,750 lbs (2,155 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,600 lbs (726 kg) est. |
| Gross Combined Weight Rating (GCWR) | Up to 10,000 lbs (4,536 kg) est. |
| Tongue Weight Limit | Up to 475 lbs (215 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2004 Dodge Ram 1500 towing capacity ranges from 2,950 lbs to 4,750 lbs across all available configurations. The introduction of the 5.7L HEMI V-8 in the 2003 model year carried over for 2004, enabling the upper towing limits within this range. These ratings follow older SAE J2807 predecessor standards and are not directly comparable to modern ratings without accounting for methodology differences.
Towing Equipment and Setup Tips
Proper towing equipment is as important as the vehicle’s rated towing capacity. Using the correct hitch class, tow package, and supplemental systems protects the truck and trailer during all towing conditions.
Factory Tow Package
The factory tow package on the Ram 1500 typically includes a Class IV receiver hitch, trailer brake controller wiring, upgraded cooling, and a 7-pin trailer connector. Without the factory tow package, the maximum towing capacity is reduced, and certain equipment such as the trailer brake controller may not be installed. Installing the tow package is the single most effective step for achieving maximum trailer weight ratings.
Trailer Brake Controller
A trailer brake controller is required by law in most jurisdictions when the trailer exceeds 3,000 lbs gross weight. The integrated trailer brake controller in Ram 1500 models with the tow package allows automatic proportional braking between the truck and trailer. Operating a loaded trailer without functional trailer brakes increases stopping distance and creates an overload condition on the truck’s braking system.
Weight-Distributing Hitch
A weight-distributing hitch is recommended when tongue weight exceeds 10 to 15 percent of the trailer gross weight, or when trailer weight approaches the upper range of the truck’s towing capacity. This hitch type uses spring bars to redistribute tongue load across all axles of the tow vehicle. The result is reduced rear sag, improved steering, and better braking balance throughout the tow rig.
Transmission Cooler and Tire Load Ratings
An auxiliary transmission cooler helps maintain transmission fluid temperature during extended towing in high-temperature conditions or mountainous terrain. Most Ram 1500 tow packages include an integrated transmission cooler. Tire load ratings must also match or exceed the actual load per axle. Tires rated for standard passenger loads are not sufficient for trailer towing near maximum capacity.
Trailer Sway Control
Trailer sway control is available on Ram 1500 models equipped with the tow package and Electronic Stability Control. The system detects lateral trailer oscillation and applies selective braking to reduce sway. Towing without trailer sway damping at high trailer weight percentages increases the risk of loss of control.
Normal vs. Heavy Towing Setup
| Feature | Standard Towing Setup | Heavy Towing Setup |
|---|---|---|
| Hitch Class | Class III (up to 8,000 lbs) | Class IV (up to 14,000 lbs) |
| Trailer Brakes | Recommended above 3,000 lbs | Required |
| Weight Distribution | Not required | Required near max capacity |
| Transmission Cooler | Factory cooler sufficient | Auxiliary cooler recommended |
| Sway Control | Optional | Strongly recommended |
| Tire Load Rating | Standard LT-rated tires | LT tires rated for actual load |
Frequently Asked Questions
What is the maximum towing capacity of a Ram 1500?
The maximum towing capacity of the Ram 1500 varies by generation. The fifth-generation (2019-2024) reached 12,750 lbs with the 5.7L HEMI V-8 and factory tow package. The 2025 model year maximum is 11,550 lbs using the new 3.0L Hurricane I-6 engine.
How much can a Ram 1500 tow with a tow package?
A Ram 1500 equipped with the factory tow package can tow up to 12,750 lbs on 2019-2024 models and up to 11,550 lbs on 2025 models when matched with the correct engine and drivetrain. Without the tow package, towing capacity and safety-related equipment such as the trailer brake controller are reduced or absent.
Does 4WD affect Ram 1500 towing capacity?
Yes. Four-wheel drive configurations typically produce lower maximum towing figures than equivalent 2WD configurations. This is because 4WD systems add weight to the vehicle, reducing the available payload and affecting the GCWR calculation. Differences range from approximately 200 to 500 lbs depending on the model year and configuration.
What trailer weight is safe for a Ram 1500?
A trailer weight at or below the manufacturer-rated maximum towing capacity for the specific vehicle configuration is the defined safe limit. Loading to 100 percent of the rated capacity reduces safety margins. Many towing references recommend staying at or below 80 percent of the rated maximum towing capacity for regular use, especially in hilly or high-temperature conditions.
Do I need a weight-distributing hitch for a Ram 1500?
A weight-distributing hitch is not required for all Ram 1500 towing applications. It is recommended when trailer tongue weight causes rear axle sag, when towing near the upper limit of capacity, or when the trailer gross weight consistently exceeds approximately 6,000 to 7,000 lbs. The owner’s manual provides guidance on when weight distribution equipment is required for specific configurations.
What hitch class does the Ram 1500 use?
The Ram 1500 uses a Class IV receiver hitch in configurations equipped with the factory tow package, supporting a 2-inch receiver and up to 14,000 lbs gross trailer weight depending on the hitch receiver’s published rating. Base configurations without the tow package may come with a lighter Class III receiver. Hitch class selection must match both the truck’s rated towing capacity and the trailer tongue weight.
Conclusion
The Ram 1500 towing capacity ranges from approximately 3,000 lbs in early 2000s base configurations to a maximum of 12,750 lbs in properly equipped 2019-2024 models. Engine selection is the primary driver of towing capacity, with the 5.7L HEMI V-8 and, more recently, the 3.0L Hurricane I-6 providing the highest trailer weight ratings. Drivetrain, axle ratio, cab style, bed length, and installed equipment packages all affect the final towing limit for any specific vehicle.
Manufacturer-published specifications are the definitive source for towing limits. Ratings vary by individual vehicle configuration, and no generalized figure applies to every build. Always verify specifications using the owner’s manual and the vehicle’s door placard before towing heavy loads.
