The Toyota 4Runner is a body-on-frame mid-size SUV that has been in continuous production since 1984. It has been offered across six generations with multiple engine options, drivetrain configurations, and trim levels.
This guide covers Toyota 4Runner towing capacity by model year, including maximum trailer weight, payload limits, tongue weight, and hitch requirements. Following manufacturer-rated towing limits protects the engine, transmission, braking system, and drivetrain from premature wear and failure.
Quick Navigation
2025 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.4L Turbocharged I-4 (i-FORCE); 2.4L Turbo + 48-hp Electric Motor (i-FORCE MAX Hybrid) |
| Drivetrain | 2WD / 4WD (Part-Time) |
| Maximum Towing Capacity | 6,000 lbs (2,722 kg) |
| Conventional Towing Capacity | 6,000 lbs (2,722 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,150 lbs (522 kg) (varies by trim) |
| Gross Vehicle Weight Rating (GVWR) | 6,005 lbs (2WD SR5) to 6,505 lbs (4WD TRD Off-Road) (2,724–2,951 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 11,000 lbs (4,990 kg) |
| Tongue Weight Limit | 600 lbs (272 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; trailer wiring standard |
The 2025 Toyota 4Runner offers a maximum towing capacity of 6,000 lbs when properly equipped with the i-FORCE turbocharged 2.4L engine and 8-speed automatic transmission. The i-FORCE MAX Hybrid variant delivers 326 system horsepower and 465 lb-ft of torque, providing enhanced pulling performance on grades and at launch. The TRD Pro trim is rated at 5,800 lbs due to added suspension components and curb weight.
2024 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,550 lbs (703 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2024 Toyota 4Runner delivers a maximum towing capacity of 5,000 lbs using the 4.0L V-6 engine across all trim levels. This was the final model year of the 5th generation, equipped with a 5-speed automatic transmission and part-time or full-time 4WD system. Maximum payload capacity of 1,550 lbs is among the highest in the 5th generation lineup.
2023 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs (680 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2023 Toyota 4Runner carries a maximum towing capacity of 5,000 lbs across all trim configurations with the 4.0L V-6 engine. Towing specifications remain consistent with the 2022 and 2021 model years. Proper tongue weight management and trailer brake controllers are recommended for loads above 3,000 lbs.
2022 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs (680 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2022 Toyota 4Runner maintains the 5,000 lb maximum towing capacity consistent throughout the 5th generation from 2017 onward. The single 4.0L V-6 engine configuration does not vary trailer weight limits by trim level in this model year. Unbraked trailer towing is limited to 1,500 lbs; braked trailer towing reaches the full 5,000 lb rating.
2021 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs (680 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2021 Toyota 4Runner towing capacity holds at 5,000 lbs, consistent with the current 5th generation standard. The 4.0L V-6 paired with a 5-speed automatic provides adequate torque for towing small to mid-size trailers. Tongue weight should be maintained between 10 and 15 percent of gross trailer weight for stability.
2020 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,495 lbs (678 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2020 Toyota 4Runner towing capacity is rated at 5,000 lbs with the 4.0L V-6 engine. Curb weight for the 2020 model is 4,805 lbs, making GCWR management critical when approaching maximum trailer weight. All 2020 4Runner trim levels share the same maximum trailer weight limit regardless of drivetrain selection.
2019 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,495 lbs (678 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2019 Toyota 4Runner towing capacity is rated at 5,000 lbs across all trim configurations. The body-on-frame construction and solid rear axle provide structural support for towing applications. Trailer sway control and tow/haul mode are available to improve stability during towing.
2018 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,495 lbs (678 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2018 Toyota 4Runner offers a maximum towing capacity of 5,000 lbs with the 4.0L V-6 engine and factory hitch receiver. Specifications for the 2018 model are consistent with the 2017 through 2020 model years within the 5th generation. Exceeding the rated tongue weight limit of 500 lbs can cause handling instability and hitch damage.
2017 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,495 lbs (678 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2017 Toyota 4Runner towing capacity is 5,000 lbs, establishing the uniform rating maintained through the 2024 model year for the 5th generation. All trim levels, including TRD Pro, SR5, and Limited, share the same maximum trailer weight rating in 2017. The 4.0L V-6 with dual variable valve timing provides consistent torque output across the RPM range for towing applications.
2016 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) — SR5 and Limited 2WD; 4,900 lbs (2,223 kg) — Trail and TRD; 4,700 lbs (2,132 kg) — Limited 4WD |
| Conventional Towing Capacity | Up to 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,435 lbs (651 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,200 lbs (4,627 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2016 Toyota 4Runner maximum towing capacity varies by trim level, ranging from 4,700 lbs on the Limited 4WD to 5,000 lbs on SR5 and Limited 2WD configurations. Trail and TRD trim variants are rated at 4,900 lbs due to added suspension equipment and curb weight differences. Confirming the specific trim’s capacity before towing is important in this model year because ratings are not uniform across configurations.
2015 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 4,700 lbs (2,132 kg) |
| Conventional Towing Capacity | 4,700 lbs (2,132 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,435 lbs (651 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 470 lbs (213 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2015 Toyota 4Runner carries a maximum towing capacity of 4,700 lbs, which is 300 lbs lower than the 2013 model year. This rating applies uniformly across all 2015 trim levels. The 2015 and 2014 model years share the same 4,700 lb towing limit within the 5th generation.
2014 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 4,700 lbs (2,132 kg) |
| Conventional Towing Capacity | 4,700 lbs (2,132 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,435 lbs (651 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,000 lbs (4,536 kg) |
| Tongue Weight Limit | 470 lbs (213 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2014 Toyota 4Runner maximum towing capacity is rated at 4,700 lbs with the 4.0L V-6 and factory hitch receiver. This represents a reduction from the 5,000 lb rating of the 2013 model year. The tow package includes the receiver hitch, 7-pin trailer wiring, and transmission cooler on equipped vehicles.
2013 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs (680 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2013 Toyota 4Runner towing capacity is rated at 5,000 lbs, restored from the lower ratings seen in later 5th generation years. The 4.0L V-6 engine with 278 lb-ft of torque provides sufficient pulling power for boats, utility trailers, and small campers within this limit. Staying below the tongue weight limit of 500 lbs is necessary to maintain directional stability.
2012 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs (680 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2012 Toyota 4Runner maximum towing capacity is 5,000 lbs, consistent with the early 5th generation ratings from 2010 through 2013. The 5th generation 4Runner introduced in 2010 shifted exclusively to the 4.0L V-6, removing the higher V-8 option from earlier years. Operators should verify the specific owner’s manual for tongue weight limits per trim level.
2011 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque) |
| Drivetrain | 2WD / 4WD (Part-Time) / Full-Time 4WD (available) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs (680 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2011 Toyota 4Runner is rated at 5,000 lbs maximum towing capacity using the 4.0L V-6 engine. This is the second full model year of the 5th generation, which dropped the V-8 option available in the 4th generation. The reduced maximum towing capacity compared to V-8 4th generation models reflects the switch to a V-6-only powertrain in this generation.
2010 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.0L V-6 (270 hp, 278 lb-ft torque); 2.7L I-4 (available on base trims) |
| Drivetrain | 2WD / 4WD (Part-Time) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,500 lbs (680 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,300 lbs (2,858 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 10,300 lbs (4,672 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard receiver hitch; 4-pin and 7-pin wiring standard |
The 2010 Toyota 4Runner marks the first year of the 5th generation and offered both a 4.0L V-6 and a 2.7L I-4 in certain configurations. Maximum towing capacity with the V-6 engine is 5,000 lbs; the I-4 variant carries a lower rating and should be verified in the owner’s manual. The 5th generation did not carry over the 4.7L V-8 available in the 4th generation.
2009 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.7L V-8 (235–260 hp); 4.0L V-6 (245 hp, 283 lb-ft torque) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 7,300 lbs (3,311 kg) — V-8 2WD; 7,000 lbs (3,175 kg) — V-8 4WD; 5,000 lbs (2,268 kg) — V-6 |
| Conventional Towing Capacity | Up to 7,300 lbs (3,311 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,475 lbs (669 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,005 lbs (2,724 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 13,000 lbs (5,897 kg) — V-8 |
| Tongue Weight Limit | 730 lbs (331 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2009 Toyota 4Runner with the 4.7L V-8 engine delivers a maximum towing capacity of 7,300 lbs in 2WD configuration, the highest rating in the 5th generation era of testing. V-6-equipped models in 2009 are limited to 5,000 lbs maximum trailer weight. The 4th generation V-8 4Runner models from 2004 to 2009 hold the all-time record for 4Runner towing capacity.
2008 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.7L V-8 (235–260 hp); 4.0L V-6 (236 hp, 266 lb-ft torque) |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 7,300 lbs (3,311 kg) — V-8 2WD; 7,000 lbs (3,175 kg) — V-8 4WD; 5,000 lbs (2,268 kg) — V-6 |
| Conventional Towing Capacity | Up to 7,300 lbs (3,311 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,475 lbs (669 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,005 lbs (2,724 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 13,000 lbs (5,897 kg) — V-8 |
| Tongue Weight Limit | 730 lbs (331 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2008 Toyota 4Runner V-8 2WD model carries a maximum trailer weight of 7,300 lbs, while 4WD V-8 models are rated at 7,000 lbs. V-6 models retain the 5,000 lb conventional towing limit. Engine and drivetrain selection has a direct impact on towing capacity in 4th generation models.
2007 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.7L V-8 (260 hp, 306 lb-ft torque); 4.0L V-6 |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 7,300 lbs (3,311 kg) — V-8 2WD; 7,000 lbs (3,175 kg) — V-8 4WD; 5,000 lbs (2,268 kg) — V-6 |
| Conventional Towing Capacity | Up to 7,300 lbs (3,311 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,475 lbs (669 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,005 lbs (2,724 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 13,000 lbs (5,897 kg) — V-8 |
| Tongue Weight Limit | 730 lbs (331 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2007 Toyota 4Runner V-8 in Limited 2WD configuration carries a maximum towing capacity of 7,300 lbs with 260 hp and 306 lb-ft of torque. The 4WD V-8 variant is rated at 7,000 lbs, reflecting drivetrain weight differences. V-6 models in 2007 are limited to 5,000 lbs regardless of drivetrain configuration.
2006 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.7L V-8 (260 hp, 306 lb-ft torque); 4.0L V-6 |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 7,300 lbs (3,311 kg) — V-8 2WD; 7,000 lbs (3,175 kg) — V-8 4WD; 5,000 lbs (2,268 kg) — V-6 |
| Conventional Towing Capacity | Up to 7,300 lbs (3,311 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,475 lbs (669 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,005 lbs (2,724 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 13,000 lbs (5,897 kg) — V-8 |
| Tongue Weight Limit | 730 lbs (331 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2006 Toyota 4Runner with the 4.7L V-8 engine provides a maximum towing capacity of 7,300 lbs in 2WD form, matching the 2005 and 2007 ratings. The 4WD version of the V-8 4Runner in 2006 is limited to 7,000 lbs due to added drivetrain weight. V-6-equipped models maintain a 5,000 lb trailer weight limit in this model year.
2005 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.7L V-8 (270 hp, 330 lb-ft torque); 4.0L V-6 |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 7,300 lbs (3,311 kg) — V-8 2WD; 7,000 lbs (3,175 kg) — V-8 4WD; 5,000 lbs (2,268 kg) — V-6 |
| Conventional Towing Capacity | Up to 7,300 lbs (3,311 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,450 lbs (658 kg) |
| Gross Vehicle Weight Rating (GVWR) | 6,005 lbs (2,724 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 13,000 lbs (5,897 kg) — V-8 |
| Tongue Weight Limit | 730 lbs (331 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2005 Toyota 4Runner V-8 produces the highest torque output of the 4th generation at 330 lb-ft, supporting the 7,300 lb towing capacity in 2WD configuration. The 4WD V-8 variant carries a 7,000 lb maximum trailer weight rating. V-6 configurations are limited to 5,000 lbs.
2004 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.7L V-8 (235 hp, 320 lb-ft torque); 4.0L V-6 |
| Drivetrain | 2WD / 4WD |
| Maximum Towing Capacity | 7,300 lbs (3,311 kg) — V-8 2WD; 7,000 lbs (3,175 kg) — V-8 4WD |
| Conventional Towing Capacity | Up to 7,300 lbs (3,311 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | Approx. 1,195 lbs (542 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,710 lbs (2,590 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 12,700 lbs (5,761 kg) — V-8 |
| Tongue Weight Limit | 730 lbs (331 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2004 Toyota 4Runner is the first model year of the 4th generation, introducing the 4.7L V-8 engine and achieving a 7,300 lb maximum towing capacity in 2WD. The 4WD V-8 variant is rated at 7,000 lbs. The GVWR of 5,710 lbs in 2004 is lower than later 4th generation years due to production differences in the first model year.
2003 Toyota 4Runner Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 4.7L V-8; 4.0L V-6 |
| Drivetrain | 4WD (Full-Time) |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,100 lbs (499 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,510 lbs (2,499 kg) |
| Gross Combined Weight Rating (GCWR) | Approx. 9,500 lbs (4,309 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional |
The 2003 Toyota 4Runner is the final model year of the 3rd generation and is rated at 5,000 lbs maximum towing capacity. Maximum payload capacity is 1,100 lbs, lower than the subsequent 4th generation models. Despite offering the 4.7L V-8 engine in this year, the towing limit did not reach the 7,300 lb level introduced in the 2004 4th generation redesign.
Towing Equipment and Setup
Proper towing equipment is essential for safe operation within rated limits. Using an undersized hitch, worn wiring, or absent trailer brakes can result in trailer separation, brake fade, or loss of vehicle control. The following components directly affect towing performance and safety.
Tow Package
The factory tow package on the Toyota 4Runner includes the receiver hitch, 4-pin and 7-pin trailer wiring harness, and, on select years, an integrated transmission cooler. Vehicles without a tow package may lack the wiring or structural reinforcement needed for maximum-rated towing. Installing an aftermarket hitch on a 4Runner should follow SAE J684 standards for the applicable hitch class.
Trailer Brake Controller
A brake controller is required when towing trailers equipped with electric brakes. Trailers over 3,000 lbs typically require independent brakes to maintain safe stopping distances. The Toyota 4Runner is compatible with aftermarket brake controllers installed through the trailer wiring connector.
Weight-Distributing Hitch
A weight-distributing hitch redistributes tongue weight across the tow vehicle and trailer axles. This reduces front axle lift on the 4Runner, improves steering response, and lowers trailer sway risk. Weight-distributing systems are recommended when tongue weight exceeds 500 lbs or when towing near the maximum trailer weight limit.
Transmission Cooler
Towing at or near maximum trailer weight generates additional heat in the transmission fluid. A supplemental or factory transmission cooler extends fluid service life and reduces shift irregularities during sustained towing. Some Toyota 4Runner tow packages include a factory auxiliary cooler on select model years.
Tire Load Ratings
Trailer tires must match or exceed the rated load capacity for the trailer’s gross weight. Underinflated or overloaded trailer tires are a leading cause of blowouts and trailer sway incidents. The tow vehicle’s tires must also meet or exceed the load index required for the combined GCWR.
Trailer Sway Control
Trailer sway occurs when the trailer oscillates side-to-side due to speed, crosswind, or improper weight distribution. The Toyota 4Runner’s vehicle stability control system can reduce sway risk, but a weight-distributing hitch with sway control bars provides an additional mechanical countermeasure. Maintaining tongue weight between 10 and 15 percent of gross trailer weight reduces sway risk.
Normal vs. Heavy Towing Setup
| Component | Normal Towing (under 3,000 lbs) | Heavy Towing (3,000–5,000+ lbs) |
|---|---|---|
| Hitch Class | Class III receiver | Class III with proper ball rating |
| Trailer Brakes | Not typically required | Required above 3,000 lbs |
| Weight-Distributing Hitch | Not required | Recommended |
| Transmission Cooler | Factory cooler adequate | Supplemental cooler recommended |
| Brake Controller | Not required | Required for electric trailer brakes |
| Tire Pressure | Standard inflation | Check load index; inflate to spec |
Frequently Asked Questions
What is the maximum towing capacity of a Toyota 4Runner?
The maximum towing capacity of a Toyota 4Runner is 7,300 lbs, achieved on 4th generation (2004–2009) models equipped with the 4.7L V-8 engine in 2WD configuration. Current 5th generation models (2010–2024) are limited to 5,000 lbs maximum towing capacity with the 4.0L V-6. The 2025 6th generation model increased the limit to 6,000 lbs with the turbocharged 2.4L engine.
How much can a Toyota 4Runner tow with a tow package?
A properly equipped Toyota 4Runner with the factory tow package can tow up to the manufacturer-rated maximum for that model year. The tow package provides the receiver hitch, trailer wiring, and in some configurations, an auxiliary transmission cooler. Without this equipment, trailer weight limits may need to be reduced to protect the drivetrain.
Does 4WD affect Toyota 4Runner towing capacity?
On 4th generation models (2004–2009), 4WD configuration reduces maximum towing capacity by approximately 300 lbs compared to 2WD models with the same engine. In 5th generation models (2010–2024), Toyota rates all configurations at the same 5,000 lb limit regardless of drivetrain. Operators should verify towing capacity in the owner’s manual specific to their drivetrain and trim.
What trailer weight is safe for a Toyota 4Runner?
A safe trailer weight is at or below the manufacturer-rated maximum towing capacity for the specific model year and configuration. Industry practice recommends staying 20 to 30 percent below the maximum towing capacity to reduce drivetrain stress during sustained towing. Total trailer weight, including cargo and water weight on campers, must account for all added weight.
Do I need a weight-distributing hitch for a Toyota 4Runner?
A weight-distributing hitch is recommended when tongue weight exceeds 500 lbs or when towing trailers in the 3,500 to 5,000 lb range. The Class III hitch on the 4Runner accommodates standard 2-inch receiver ball mounts. Always verify that the ball mount and hitch ball are rated for the intended gross trailer weight before towing.
What hitch class does the Toyota 4Runner use?
The Toyota 4Runner uses a Class III trailer hitch receiver across all modern generations. Class III hitches accommodate a 2-inch by 2-inch receiver and are rated for up to 5,000 lbs gross trailer weight and 500 lbs tongue weight. The factory-installed hitch on current models meets these ratings and complies with SAE J684 standards.
Conclusion
Toyota 4Runner towing capacity ranges from 2,500 lbs on early 1st generation models to 7,300 lbs on 4th generation V-8 2WD configurations. Current 5th generation models (2010–2024) are uniformly rated at 5,000 lbs with the 4.0L V-6, while the 2025 6th generation model increased the limit to 6,000 lbs using the turbocharged 2.4L i-FORCE engine. Engine selection, drivetrain configuration, and factory tow package all directly affect the maximum trailer weight rating for a given model year. Towing without proper equipment, including a rated hitch, trailer brakes, and tongue weight management, can exceed system limits even below the published towing capacity.
