The Volkswagen Atlas is a three-row mid-size SUV produced by Volkswagen since the 2018 model year. It is assembled in Chattanooga, Tennessee, and is offered in both front-wheel drive (FWD) and 4MOTION all-wheel drive configurations. Towing capacity varies depending on model year, engine selection, drivetrain layout, and installed equipment packages.
This guide covers Volkswagen Atlas towing specifications from 2018 through 2026, including maximum trailer weight, payload limits, tongue weight, and hitch class requirements for each model year. Following manufacturer-rated towing limits helps protect the engine, transmission, and braking systems from excess mechanical stress during towing operations.
Quick Navigation
2026 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged Inline-4 (269 hp / 273 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,102 lbs (500 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,930 lbs (2,690 kg) |
| Gross Combined Weight Rating (GCWR) | 10,930 lbs (4,958 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional (Standard on AWD trims) |
The 2026 Volkswagen Atlas offers a maximum towing capacity of 5,000 lbs (2,268 kg) with the factory tow package and trailer brakes properly installed. The single 2.0L turbocharged engine powers all 2026 trim levels with 269 hp and 273 lb-ft of torque. Payload is rated at 1,102 lbs (500 kg) with a gross vehicle weight rating of 5,930 lbs (2,690 kg).
2025 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged Inline-4 (269 hp / 273 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,091 lbs (495 kg) |
| Gross Combined Weight Rating (GCWR) | 10,823 lbs (4,909 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Optional (Standard on AWD trims) |
The 2025 Volkswagen Atlas reaches a maximum towing capacity of 5,000 lbs (2,268 kg) across all trim levels when equipped with the required towing equipment. Without trailer brakes, the maximum permissible trailer weight drops to 1,650 lbs (748 kg). The 4MOTION AWD configuration includes a factory-installed trailer hitch on most trim levels.
2024 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbocharged Inline-4 (269 hp / 273 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,091 lbs (495 kg) |
| Gross Vehicle Weight Rating (GVWR) | 5,732 lbs (2,600 kg) |
| Gross Combined Weight Rating (GCWR) | 10,732 lbs (4,868 kg) |
| Tongue Weight Limit | 500 lbs (227 kg) |
| Hitch Class | Class III |
| Factory Tow Package | Standard on SE with Technology trim and above |
The 2024 Volkswagen Atlas received a full powertrain redesign, replacing the 3.6L VR6 with an upgraded 2.0L turbocharged four-cylinder engine producing 269 hp and 273 lb-ft of torque. This engine update enables all 2024 Atlas configurations to reach the 5,000 lbs (2,268 kg) maximum towing capacity, a rating that previously required the V6. The factory tow package is included as standard equipment on SE with Technology trim and all higher trim levels.
2023 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbo Inline-4 (235 hp / 258 lb-ft); 3.6L VR6 (276 hp / 266 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with VR6; 2,000 lbs (907 kg) with 4-cyl |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) with VR6 |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,080 lbs (490 kg) |
| Gross Combined Weight Rating (GCWR) | ~10,500 lbs (~4,763 kg) with VR6 |
| Tongue Weight Limit | 500 lbs (227 kg) with VR6; 200 lbs (91 kg) with 4-cyl |
| Hitch Class | Class III |
| Factory Tow Package | Optional (VR6 required for maximum towing) |
The 2023 Volkswagen Atlas maximum towing capacity of 5,000 lbs (2,268 kg) requires the 3.6L VR6 engine combined with the factory tow package. Atlas models equipped with only the 2.0L four-cylinder engine are limited to a 2,000 lbs (907 kg) trailer weight rating. Payload capacity for the 2023 model year is rated at 1,080 lbs (490 kg) regardless of engine choice.
2022 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbo Inline-4 (235 hp / 258 lb-ft); 3.6L VR6 (276 hp / 266 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with VR6; 2,000 lbs (907 kg) with 4-cyl |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) with VR6 |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,080 lbs (490 kg) |
| Gross Combined Weight Rating (GCWR) | ~10,500 lbs (~4,763 kg) with VR6 |
| Tongue Weight Limit | 500 lbs (227 kg) with VR6; 200 lbs (91 kg) with 4-cyl |
| Hitch Class | Class III |
| Factory Tow Package | Optional (VR6 required for maximum towing) |
The 2022 Volkswagen Atlas towing capacity reaches 5,000 lbs (2,268 kg) when the vehicle is equipped with the 3.6L VR6 engine, factory tow package, and a trailer with functioning brakes. The 2.0L four-cylinder variant is limited to 2,000 lbs (907 kg) and does not include a factory hitch option. Both FWD and 4MOTION AWD configurations are available with the VR6 engine on 2022 models.
2021 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbo Inline-4 (235 hp / 258 lb-ft); 3.6L VR6 (276 hp / 266 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with VR6; 2,000 lbs (907 kg) with 4-cyl |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) with VR6 |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,080 lbs (490 kg) |
| Gross Combined Weight Rating (GCWR) | ~10,500 lbs (~4,763 kg) with VR6 |
| Tongue Weight Limit | 500 lbs (227 kg) with VR6; 200 lbs (91 kg) with 4-cyl |
| Hitch Class | Class III |
| Factory Tow Package | Optional (VR6 required for maximum towing) |
The 2021 Volkswagen Atlas offers a maximum towing capacity of 5,000 lbs (2,268 kg) with the 3.6L VR6 engine and factory tow package. The four-cylinder configuration is limited to 2,000 lbs (907 kg) with no factory hitch available for that engine variant. Payload is rated at 1,080 lbs (490 kg) for the 2021 model year.
2020 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbo Inline-4 (235 hp / 258 lb-ft); 3.6L VR6 (276 hp / 266 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with VR6; 2,000 lbs (907 kg) with 4-cyl |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) with VR6 |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | ~1,080 lbs (~490 kg) |
| Gross Combined Weight Rating (GCWR) | ~10,500 lbs (~4,763 kg) with VR6 |
| Tongue Weight Limit | 500 lbs (227 kg) with VR6; 200 lbs (91 kg) with 4-cyl |
| Hitch Class | Class III |
| Factory Tow Package | Optional (VR6 required for maximum towing) |
The 2020 Volkswagen Atlas towing specifications match those of the 2019 model year with no change to the powertrain or towing ratings. The 3.6L VR6 engine with the factory tow package provides the full 5,000 lbs (2,268 kg) maximum trailer weight limit. Four-cylinder models remain limited to 2,000 lbs (907 kg) using an aftermarket Class III receiver.
2019 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbo Inline-4 (235 hp / 258 lb-ft); 3.6L VR6 (276 hp / 266 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with VR6; 2,000 lbs (907 kg) with 4-cyl |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) with VR6 |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | ~1,100 lbs (~499 kg) |
| Gross Combined Weight Rating (GCWR) | ~10,500 lbs (~4,763 kg) with VR6 |
| Tongue Weight Limit | 500 lbs (227 kg) with VR6; 200 lbs (91 kg) with 4-cyl |
| Hitch Class | Class III |
| Factory Tow Package | Optional (VR6 models only) |
The 2019 Volkswagen Atlas towing capacity of 5,000 lbs (2,268 kg) is only available with the 3.6L VR6 engine and a factory-installed tow package. Four-cylinder models from 2019 did not receive a factory hitch option, limiting those configurations to 2,000 lbs (907 kg) with an aftermarket receiver. The 3.6L VR6 paired with 4MOTION AWD provides the most capable towing configuration for the 2019 model year.
2018 Volkswagen Atlas Towing Capacity
| Specification | Detail |
|---|---|
| Engine Options | 2.0L Turbo Inline-4 (235 hp / 258 lb-ft); 3.6L VR6 (276 hp / 266 lb-ft) |
| Drivetrain | FWD / 4MOTION AWD |
| Maximum Towing Capacity | 5,000 lbs (2,268 kg) with VR6; 2,000 lbs (907 kg) with 4-cyl |
| Conventional Towing Capacity | 5,000 lbs (2,268 kg) with VR6 |
| Fifth-Wheel / Gooseneck Capacity | N/A |
| Maximum Payload Capacity | 1,414 lbs (641 kg) |
| Gross Combined Weight Rating (GCWR) | ~10,500 lbs (~4,763 kg) with VR6 |
| Tongue Weight Limit | 500 lbs (227 kg) with VR6; 200 lbs (91 kg) with 4-cyl |
| Hitch Class | Class III |
| Factory Tow Package | Optional (VR6 models only) |
The 2018 Volkswagen Atlas is the first model year of production, establishing the towing baseline for the nameplate at 5,000 lbs (2,268 kg) with the 3.6L VR6 engine. Payload capacity for the 2018 model year was rated at 1,414 lbs (641 kg), which is higher than most subsequent production years. Four-cylinder models in 2018 remained limited to 2,000 lbs (907 kg) using an aftermarket hitch, as no factory hitch was offered for that engine configuration.
Towing Equipment and Setup
Proper towing setup requires more than selecting the correct engine and hitch. Each component in the towing chain must meet or exceed the rated load requirements for the planned trailer weight.
Tow Package
The factory Volkswagen Atlas tow package includes trailer wiring harness connections and, on VR6 models (2018-2023) and AWD models (2024-2026), a factory-installed trailer hitch receiver. Four-cylinder Atlas models from 2018 to 2023 did not include a factory hitch option and require an aftermarket Class III receiver for any towing use. Aftermarket hitches, such as CURT Class III units rated at 6,000 lbs GTW and 900 lbs tongue weight, are compatible with the Atlas platform.
Trailer Brake Controller
Trailers weighing over 1,650 lbs require independent trailer brakes to meet the Volkswagen Atlas maximum towing limit of 5,000 lbs. A proportional brake controller, mounted inside the cab, synchronizes trailer brake pressure with tow vehicle deceleration. This component is legally required in many jurisdictions when trailer gross weight exceeds specific thresholds.
Weight-Distributing Hitch
A weight-distributing hitch is recommended when tongue weight approaches or exceeds 10 percent of the trailer’s gross weight. This equipment transfers tongue weight load from the rear axle of the Atlas to both axles, improving front axle steering response and reducing rear sag. Weight-distributing systems designed for 400-600 lbs tongue weight are appropriate for Atlas configurations towing near the 5,000 lbs limit.
Normal Towing vs. Heavy Towing Setup
| Component | Normal Towing (Under 2,000 lbs) | Heavy Towing (2,000-5,000 lbs) |
|---|---|---|
| Hitch Class | Class III | Class III |
| Trailer Brakes | Not required | Required |
| Weight-Distributing Hitch | Not required | Recommended above 3,500 lbs |
| Brake Controller | Not required | Required |
| Transmission Cooler | Factory sufficient | Factory sufficient on 2024+ |
| Sway Control | Not required | Recommended |
| Tow Package | Aftermarket hitch sufficient | Factory tow package required |
Transmission Cooler
The 2024-2026 Atlas with the upgraded 2.0L turbocharged engine includes improved thermal management suited for repeated towing operations. On earlier 2018-2023 V6 models, extended towing in hot conditions warrants monitoring transmission temperature through the vehicle’s onboard diagnostics. Supplemental transmission coolers can be added to earlier model years for high-frequency towing applications.
Tire Load Ratings
Tires must carry the combined weight of the vehicle, all passengers, cargo, and tongue weight simultaneously. The tire placard on the driver-side door jamb specifies the maximum load rating for the factory-installed tires. Replacement tires must meet or exceed the original load index rating specified by Volkswagen for the Atlas model year in question.
Trailer Sway Control
The 4MOTION AWD system on the Atlas includes electronic stability control that can help manage trailer sway through automatic individual wheel braking. Dedicated trailer sway control systems, integrated into aftermarket brake controllers, provide an additional layer of stability management for trailers approaching the 5,000 lbs limit. Both systems operate independently and are compatible when installed together.
Frequently Asked Questions
What is the maximum towing capacity of a Volkswagen Atlas?
The maximum towing capacity of the Volkswagen Atlas is 5,000 lbs (2,268 kg). This rating applies to all 2024-2026 model years and to 2018-2023 models equipped with the 3.6L VR6 engine. Achieving this limit requires the factory tow package and trailer brakes rated for the load.
How much can a Volkswagen Atlas tow with a tow package?
With the factory tow package properly installed, the Volkswagen Atlas can tow up to 5,000 lbs (2,268 kg) on properly equipped configurations. This figure requires a trailer equipped with its own braking system for loads exceeding 1,650 lbs (748 kg). The tow package on 2024-2026 models is standard on SE with Technology trim and above.
Does the 2.0L four-cylinder engine limit Volkswagen Atlas towing capacity?
On 2018-2023 model years, the 2.0L four-cylinder engine limits towing capacity to 2,000 lbs (907 kg). Starting with the 2024 model year, Volkswagen upgraded the 2.0L turbocharged engine to 269 hp and 273 lb-ft of torque, enabling it to match the former VR6 towing rating of 5,000 lbs (2,268 kg). Buyers of pre-2024 Atlas models must select the 3.6L VR6 to access the maximum towing limit.
What trailer weight is safe for a Volkswagen Atlas?
Safe trailer weight for the Volkswagen Atlas depends on model year and engine configuration. On 2024-2026 models with the factory tow package, any trailer up to 5,000 lbs (2,268 kg) gross weight falls within the rated limit. On 2018-2023 four-cylinder models, the safe maximum is 2,000 lbs (907 kg) with an aftermarket hitch.
Do I need a weight-distributing hitch for the Volkswagen Atlas?
A weight-distributing hitch is not required for trailers under approximately 3,500 lbs (1,587 kg) when tongue weight remains within the 500 lbs (227 kg) rated limit. For trailers approaching 5,000 lbs (2,268 kg), a weight-distributing hitch system helps maintain axle load balance and improve steering control. Systems rated for 400-600 lbs spring bar capacity are appropriate for Atlas towing configurations near the maximum limit.
What hitch class does the Volkswagen Atlas use?
The Volkswagen Atlas uses a Class III hitch receiver, which provides a standard 2-inch by 2-inch receiver opening. Class III hitches are rated for gross trailer weights up to 6,000 lbs and tongue weights up to 900 lbs, which exceeds the Atlas manufacturer-rated limits in both categories. Always follow the lowest-rated component in the towing chain as the effective towing limit.
Conclusion
The Volkswagen Atlas towing capacity ranges from 2,000 lbs (907 kg) on four-cylinder models from 2018-2023, to 5,000 lbs (2,268 kg) on V6-equipped models from that same generation and all configurations from the redesigned 2024-2026 generation. The most significant factor affecting towing capacity across all model years is engine selection on pre-2024 units and tow package equipment level on all years.
The 2024 redesign eliminated the V6 option in favor of a higher-output 2.0L turbocharged engine, simplifying the configuration decision for buyers who require maximum towing capacity. Payload, GVWR, and tongue weight limits vary modestly across model years and must be considered alongside trailer weight when calculating the total towing load.
Always verify towing specifications using the vehicle’s owner’s manual and door jamb placard before towing heavy loads.
